FreeMotion
Brand: FreeMotion
Category: Biceps/Triceps
Type: Strength Systems
Model Number: GZFM60023
Model Name:
Exploded Diagrams
"Used Only" - contact us if interested in used or refurbished parts. Send us mail:
X-
Views
| Image | Catalog # | MPN | Part List Key | Quantity On Model | Part Description | Notes | Available Used | Model Compatibility List | New price |
|---|---|---|---|---|---|---|---|---|---|
| 108063 | 212128 | # | DECAL, 8" BLK/RED STACKED | No | Model Compatibility List | $16.98 / Each |
|||
| 108065 | 212132 | # | DECAL, 14" BLK/RED HORZ | No | Model Compatibility List | $15.60 / Each |
|||
| 107436 | 331959 | 49 | CABLE CLIP | No | Model Compatibility List | $58.98 / Each |
|||
| 108073 | GZ0087 | 56 | BUNGEE CORD | No | Model Compatibility List | $2.29 / Each |
|||
| 108050 | GZ1001 | 25 | WEIGHT BUMPER | No | Model Compatibility List | $13.34 / Each |
|||
| 105889 | GZ1003-01 | 15 | TENSION PULLEY | No | Model Compatibility List | $21.41 / Each |
|||
| 103286 | GZ1007 | 43 | 3/8" NYLON LOCKNUT | No | Model Compatibility List | $0.33 / Each |
|||
| 107427 | GZ1009-01 | 54 | 1/2" X 1" SCKT HEAD SCREW | No | Model Compatibility List | $3.03 / Each |
|||
| 103569 | GZ1009-04 | 45 | 1/2" X 4.5" BOLT | No | Model Compatibility List | $13.88 / Each |
|||
 |
103247 | GZ1011-01 | 20 | 1 | Yes | Model Compatibility List | $16.93 / Each |
||
| 107943 | GZ1011-02 | 37 | PIVOT PULLEY BEARING | No | Model Compatibility List | $11.86 / Each |
|||
| 103285 | GZ1012-07 | 50 | 3/8" X 1/2" BUTTON SCREW | No | Model Compatibility List | $1.60 / Each |
|||
| 103287 | GZ1013-02 | 42 | 3/8" X 1.75" BOLT | No | Model Compatibility List | $3.37 / Each |
|||
| 103291 | GZ1013-04 | 47 | 3/8" X 2" BOLT | No | Model Compatibility List | $2.81 / Each |
|||
| 103292 | GZ1014-01 | 51 | 3/8" X 1" NON-PATCH BOLT | No | Model Compatibility List | $2.67 / Each |
|||
| 103335 | GZ1014-05 | 10 | 3/8" X 2.25" NON-PCH BOLT | No | Model Compatibility List | $3.28 / Each |
|||
| 107424 | GZ1018-01 | 8 | RETAINER RING | No | Model Compatibility List | $1.73 / Each |
|||
| 108059 | GZ1018-03 | 34 | 1 1/8" RETAINER RING | No | Model Compatibility List | $5.01 / Each |
|||
| 103479 | GZ1020 | 31 | GUIDE BUSHINGOD | No | Model Compatibility List | $11.91 / Each |
|||
| 103288 | GZ1021-01 | 5 | RIVET | No | Model Compatibility List | $0.94 / Each |
|||
| 108055 | GZ1024 | 48 | TOP WEIGHT BUSHING | No | Model Compatibility List | $13.71 / Each |
|||
| 103460 | GZ1047 | 39 | 1/4" X 3/8" SET SCREW | No | Model Compatibility List | $0.81 / Each |
|||
| 101282 | GZ1049 | 19 | WAVE WASHER | No | Model Compatibility List | $7.72 / Each |
|||
| 101290 | GZ1050 | 9 | AXLE WASHER | No | Model Compatibility List | $3.34 / Each |
|||
| 108052 | GZ1062 | 40 | RUBBER COVER | No | Model Compatibility List | $6.04 / Each |
|||
| 108075 | GZ1066 | 58 | #10 X 1/2" SCREW | No | Model Compatibility List | $0.41 / Each |
|||
| 103262 | GZ1069 | 53 | PULLEY WASHER | No | Model Compatibility List | $1.37 / Each |
|||
| 108054 | GZ1070 | 35 | EYEBOLT | No | Model Compatibility List | $5.86 / Each |
|||
| 108074 | GZ1071 | 59 | BUNGEE CLIP | No | Model Compatibility List | $2.59 / Each |
|||
| 106100 | GZ1075 | 36 | 3/8" LOCKNUT | No | Model Compatibility List | $0.64 / Each |
|||
| 103299 | GZ1081 | 57 | WIRE TIE | No | Model Compatibility List | $0.15 / Each |
|||
| 103478 | GZ1084 | 33 | GUIDE ROD NUT | No | Model Compatibility List | $0.88 / Each |
|||
| 103481 | GZ1085 | 44 | GUIDE WASHER | No | Model Compatibility List | $0.63 / Each |
|||
| 107733 | GZ1097 | 55 | 1/4" X 1.25" ROLL PIN | No | Model Compatibility List | $1.13 / Each |
|||
| 103504 | GZ1193 | 17 | PULLEY BUMPER | No | Model Compatibility List | $0.00 / Each Out Of Stock |
|||
| 103269 | GZ1504 | # | SHORT TRIM | No | Model Compatibility List | $2.72 / Each |
|||
| 103275 | GZ1517 | 22 | TOWER FOOT | No | Model Compatibility List | $12.19 / Each |
|||
| 108051 | GZ1656 | 26 | WEIGHT PIN | No | Model Compatibility List | $73.57 / Each |
|||
| 108089 | GZ3052-03 | 41 | CABLE | No | Model Compatibility List | $107.01 / Each |
|||
| 108061 | GZ3053 | 21 | TRUNNION | No | Model Compatibility List | $44.01 / Each |
|||
| 108057 | GZ3072-01 | 28 | SMALL WEIGHT | No | Model Compatibility List | $89.14 / Each |
|||
| 108040 | GZ3072-02 | 27 | LARGE WEIGHT | No | Model Compatibility List | $113.75 / Each |
|||
| 103506 | GZ3091 | 13 | DOUBLE CABLE GUARD | No | Model Compatibility List | $17.04 / Each |
|||
| 103261 | GZ3102 | 14 | CABLE GUARD | No | Model Compatibility List | $14.82 / Each |
|||
| 108047 | GZ3192-01 | 52 | LEFT TOWER COVER | No | Model Compatibility List | $82.53 / Each |
|||
| 108046 | GZ3192-02 | 46 | RIGHT TOWER COVER | No | Model Compatibility List | $86.40 / Each |
|||
| 108086 | GZ3194-01 | 23 | LEFT ARM COVER | No | Model Compatibility List | $91.41 / Each |
|||
| 108087 | GZ3194-02 | 24 | RIGHT ARM COVER | No | Model Compatibility List | $94.04 / Each |
|||
| 108085 | GZ3196 | 16 | SEAT FRAME COVER | No | Model Compatibility List | $0.00 / Each Out Of Stock |
|||
| 108053 | GZ3238 | 38 | ALUMINUM COUPLER | No | Model Compatibility List | $92.89 / Each |
|||
| 107420 | GZ3248-01 | 30 | WEIGHT GUIDE | No | Model Compatibility List | $103.38 / Each |
|||
| 108084 | GZ3251-01 | 12 | LEFT STABILIZER COVER | No | Model Compatibility List | $0.00 / Each Out Of Stock |
|||
| 108083 | GZ3251-02 | 11 | RIGHT STABILIZER COVER | No | Model Compatibility List | $0.00 / Each Out Of Stock |
|||
| 108069 | GZ4504 | 29 | TOP WEIGHT ASSY | No | Model Compatibility List | $331.04 / Each |
|||
| 108076 | GZ4509 | # | COUPLER ASSY | No | Model Compatibility List | $83.28 / Each |
|||
| 108077 | GZ4546 | # | BUNGEE CORD KIT | No | Model Compatibility List | $9.59 / Each |
|||
| 108037 | GZ4549-01 | 2 | ACCESS COVER | No | Model Compatibility List | $123.13 / Each |
|||
| 108039 | GZ5001-01 | 18 | SWIVEL ARM | No | Model Compatibility List | $148.44 / Each |
|||
| 108080 | GZ5008 | 3 | SEAT FRAME | No | Model Compatibility List | $0.00 / Each Out Of Stock |
|||
| 108081 | GZ5029 | 6 | LEFT STABILIZER | No | Model Compatibility List | $0.00 / Each Out Of Stock |
|||
| 108082 | GZ5030 | 7 | RIGHT STABILIZER | No | Model Compatibility List | $0.00 / Each Out Of Stock |
|||
| 108079 | GZ5077 | 1 | TOWER | No | Model Compatibility List | $0.00 / Each Out Of Stock |
|||
| 103364 | GZ5108-01 | 4 | BENCH PAD | No | Model Compatibility List | $0.00 / Each Out Of Stock |
|||
| 108088 | GZ5109-03 | 32 | HANDLE W/STRAP | No | Model Compatibility List | $41.95 / Each |
|||
| 103305 | GZ7003 | # | 10 POINT WARNING DECAL | No | Model Compatibility List | $9.26 / Each |
|||
| 103306 | GZ7004 | # | INTERNAL WARNING DECAL | No | Model Compatibility List | $9.48 / Each |
|||
| 103307 | GZ7005 | # | CAUTION MOVING PART DECAL | No | Model Compatibility List | $3.34 / Each |
|||
| 103310 | GZ7006 | # | CAUTION "DO NOT USE"DECAL | No | Model Compatibility List | $3.34 / Each |
|||
| 103308 | GZ7026 | # | SELECTOR PIN INSERT DECAL | No | Model Compatibility List | $3.96 / Each |
|||
| 108064 | GZ7054-01 | # | CHEST PLACARD | No | Model Compatibility List | $0.00 / Each Out Of Stock |
|||
| 108090 | GZ7215 | # | USER'S MANUAL | No | Model Compatibility List | $17.30 / Each |
|||
|
| |||||||||
