FreeMotion - XTE REAR DRIVE

Exploded Diagrams

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Rotating Parts
  • Cover/trim
  • Wire/cables
  • Motor
  • Crank/flywheel
  • Pulley
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
014033 1020703 014033 36 1 M6 Flat Washer (Used) Yes Model Compatibility List $2.02 / Each

1
286547 1000461 286547 0 1 Roller Wheel Yes Model Compatibility List $59.99 / Each

1
255072 1002802 255072 29 1 Pulley Yes Model Compatibility List $77.97 / Each

37,3
139703 1003396 139703 33 1 Bearing Sealed Yes Model Compatibility List $24.46 / Each

1,8
237631 1003996 237631 60 1 Foot Leveler Yes Model Compatibility List $6.69 / Each

1,3
214070 1003998 214070 105 1 Screw M8 X 16MM No Model Compatibility List $1.06 / Each

1,2
237612 1004200 237612 0 1 M8 X 16MM Patch Screw No Model Compatibility List $11.99 / Each

1
014174 1004202 014174 0 1 M8 Split Washer No Model Compatibility List $11.99 / Each

1
243375 1004487 243375 0 1 Retainer Small No Model Compatibility List $11.99 / Each

1
256446 1004787 256446 108 1 M8 Locking Nut No Model Compatibility List $0.69 / Each

1,2
148710 1005195 148710 53 1 M10 Locknut No Model Compatibility List $1.57 / Each

1,2
250420 100524 250420 31A 1 Screw M10-1.5 x 20mm No Model Compatibility List $2.09 / Each

1,3,2
363093 1006636 363093 0 1 Idler Bracket Assembly Yes Model Compatibility List $67.99 / Each

1
279645 1006637 279645 0 1 Motor Bracket No Model Compatibility List $18.99 / Each

28
287117 1007315 287117 0 1 Axle Crank Yes Model Compatibility List $88.99 / Each
Out Of Stock
35
287117 1007998 287117 0 1 Axle Crank W/Hub Plate Yes Model Compatibility List $88.99 / Each

35
289884 1008001 289884 0 1 Pedal Crank Arm Yes Model Compatibility List $120.99 / Each

35
287202 1008244 287202 0 1 Wave Washer No Model Compatibility List $9.99 / Each

1
113842 1009452 113842 137 1 Magnet Yes Model Compatibility List $1.10 / Each

1,3,8
243374 1009932 243374 0 1 Retainer Snap Ring Yes Model Compatibility List $12.99 / Each

1
281150 101010 281150 61 1 Idler Bolt Yes Model Compatibility List $3.36 / Each

1,2
243374 101063 243374 0 1 Idler Snap Ring Yes Model Compatibility List $17.99 / Each

1
286660 1010933 286660 0 1 Large Axle Cover Yes Model Compatibility List $13.99 / Each

18
289866 101142 289866 0 1 Stabilizer Cap Yes Model Compatibility List $61.99 / Each

1
287135 101157 287135 0 1 Small Axle Cover Yes Model Compatibility List $15.00 / Each

18
247275 101165 247275 0 1 Latch Bracket Spring Yes Model Compatibility List $22.99 / Each

1
237611 101177 237611 0 1 Screw M8 X 28mm Yes Model Compatibility List $19.99 / Each

1
013162 1011778 013162 0 1 Clamp Screw Yes Model Compatibility List $11.99 / Each

1
014033 1011790 014033 0 1 Idler Washer M6 Yes Model Compatibility List $12.99 / Each

1
131090 1011798 131090 114 1 Reed Switch Cable Retainer Clamp Yes Model Compatibility List $0.46 / Each

19,3
208163 1011833 208163 84 1 Idler Screw Yes Model Compatibility List $1.20 / Each

1,2
252438 101184 252438 0 1 Screw M10 X 95mm Yes Model Compatibility List $31.99 / Each

1
363093 1011844 363093 0 1 Idler Bracket Assembly Yes Model Compatibility List $68.99 / Each

1
208817 101187 208817 5B 1 Screw M4 X 16mm No Model Compatibility List $0.46 / Each

1,2
View Drawing
