HEALTH RIDER - CROSSTRAINER 1050 T

Exploded Diagrams

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry used@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Motors
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Belt Related
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
100128 116059 100128 90 ADJUSTMENT BRACKET No Model Compatibility List $2.29 / Each

2,3,4,5,6
104838 100396 104838 # LUBE, GREASE No Model Compatibility List $6.19 / Each

1,15
113842 100081 113842 43 ROLLER MAGNET Yes Model Compatibility List $2.75 / Each

8
119199 101018 119199 56 DRIVE BELT Yes Model Compatibility List $68.07 / Each

10,15
119894 100086 119894 # 4MM ALLEN WRENCH No Model Compatibility List $1.58 / Each

2
012111 100663 012111 60 M6 NUT Yes Model Compatibility List $3.31 / Each

2
012142 101429 012142 59 M6 LOCKNUT No Model Compatibility List $1.98 / Each

2
121519 101359 121519 70 M10 SPLIT WASHER No Model Compatibility List $4.44 / Each

2
131090 100079 131090 69 RSW CLAMP Yes Model Compatibility List $0.46 / Each

4,5,6
013222 101860 013222 84 M4 X 12MM GROUND SCREW No Model Compatibility List $2.75 / Each

2
120989 134544 105 M3 X 8MM SCREW No Model Compatibility List $0.45 / Each

2
013497 117099 013497 64 M4 X 5MM SCREW No Model Compatibility List $2.57 / Each

2
013550 102106 013550 73 M5 X 16MM BOLT No Model Compatibility List $1.60 / Each

2
139703 100657 139703 40 BEARING Yes Model Compatibility List $27.76 / Each

1
014003 101370 014003 58 M6 WASHER No Model Compatibility List $1.55 / Each

2
014061 101800 014061 38 M10 WASHER No Model Compatibility List $1.51 / Each

2
143334 120003 143334 78 REED SWITCH BRACKET No Model Compatibility List $28.03 / Each

2,3,4,5,6
143742 100654 143742 21 LARGE SNAP RING Yes Model Compatibility List $1.84 / Each

2
148710 100540 148710 29 M10 LOCKNUT No Model Compatibility List $2.67 / Each

2
150327 100690 150327 61 M5 NYLON LOCKNUT No Model Compatibility List $1.17 / Each

2
154848 101799 154848 67 M4 X 52MM SCREW No Model Compatibility List $1.23 / Each

2
158332 100386 158332 # JACK Yes Model Compatibility List $7.66 / Each

4,5,6
164675 101707 164675 77 REED SWITCH/WIRE Yes Model Compatibility List $24.11 / Each

4,5,6
100706 165288 # IFIT SPLITTER No Model Compatibility List $11.26 / Each

1
100485 165831 # CHEST PULSE STRAP No Model Compatibility List $14.07 / Each

12,13,14
175287 120292 175287 6 LEFT SIDE SHIELD No Model Compatibility List $132.44 / Each

3
175575 119994 175575 35 REAR STABLIZER ENDCAP Yes Model Compatibility List $25.50 / Each

4,5,6,9
120302 175577 30 UPRIGHT BUSHING No Model Compatibility List $17.67 / Each

8,3
175584 119992 175584 31 LEFT FRONT ENDCAP No Model Compatibility List $16.36 / Each

9,4,5,6
175585 120000 175585 68 RIGHT FRONT ENDCAP No Model Compatibility List $18.56 / Each

4,5,6,9
175586 119855 175586 13 LEFT PEDAL Yes Model Compatibility List $99.14 / Each

8,9
175587 119856 175587 12 RIGHT PEDAL Yes Model Compatibility List $103.91 / Each

8,9
115027 175592 28 FRONT PEDAL ARM BUSHING No Model Compatibility List $37.39 / Each

8,9,3
120365 175915 85 RESISTANCE CABLE No Model Compatibility List $7.19 / Each

4,5,6,10
177035 101781 177035 42 FLYWHEEL BEARING No Model Compatibility List $63.94 / Each

8
104931 179002 62 M5 X 12MM SCREW No Model Compatibility List $4.44 / Each

2
180005 119993 180005 34 M10 X 112MM CARRIAGE BOLT No Model Compatibility List $10.60 / Each

2
180010 119999 180010 65 M5 X 33MM SCREW No Model Compatibility List $8.22 / Each

2
180013 119990 180013 20 ADJUSTMENT CARRIAGE BOLT M10-1.5X30MM Yes Model Compatibility List $7.49 / Each

2
180527 119862 180527 15 PEDAL KNOB Yes Model Compatibility List $21.00 / Each
8,9
181502 120308 181502 48 RIGHT CRANK ARM Yes Model Compatibility List $143.80 / Each
3,8
119865 183631 19 M6 X 33.5MM BOLT No Model Compatibility List $5.20 / Each

2
100691 183633 107 M5 WASHER No Model Compatibility List $0.23 / Each

2
119851 183634 49 M6 X 25MM SCREW No Model Compatibility List $2.08 / Each

2
183659 120305 183659 44 FLYWHEEL AXLE No Model Compatibility List $14.69 / Each

8
184369 106040 184369 66 M4 X 16MM SCREW No Model Compatibility List $1.57 / Each

2
120931 184847 83 FLEX BRACKET SPACER No Model Compatibility List $3.08 / Each

2,3,4,5,6
120925 184848 41 FLYWHEEL W/BRNGS No Model Compatibility List $133.72 / Each

8
193223 100647 193223 55 RESISTANCE MOTOR Yes Model Compatibility List $106.74 / Each

10
120303 197038 33 M6 X 72MM BUTTON SCREW No Model Compatibility List $2.32 / Each

2
120943 197039 57 M8 X 33MM BUTTON SCREW No Model Compatibility List $1.29 / Each

2
197726 106030 197726 27 M10 X 78MM BUTTON BOLT Yes Model Compatibility List $7.34 / Each

2
120306 198000 53 M8.5MM SMALL WASHER No Model Compatibility List $0.52 / Each

2
101798 198005 51 M6 X 18MM BUTTON BOLT No Model Compatibility List $1.63 / Each

2
120919 198531 3 FRONT STABILIZER No Model Compatibility List $60.38 / Each

1
120920 198555 4 REAR STABILIZER No Model Compatibility List $60.38 / Each

1
120926 198559 52 C-MAGNET BRACKET No Model Compatibility List $24.55 / Each

2,8,3,4,5,6
101340 199493 71 M6 X 16MM BUTTON SCREW No Model Compatibility List $1.54 / Each

2
120984 200838 86 UPPER WIRE HARNESS No Model Compatibility List $49.59 / Each

4,5,6
120957 202422 80 SIDESHIELD COVER No Model Compatibility List $38.81 / Each

9,3
120979 203521 # INTERACTIVE MEDIA CD No Model Compatibility List $46.05 / Each

4,5,6
204230 120945 204230 89 M8 X 22MM BUTTON SCREW No Model Compatibility List $2.55 / Each

2
120304 206933 36 LEFT CRANK ARM No Model Compatibility List $99.00 / Each

8,3
114194 207680 63 M10 X 87MM BOLT No Model Compatibility List $4.11 / Each

2
120988 207783 102 LEFT INNER HANDLEBAR COVR No Model Compatibility List $6.69 / Each

11
120929 208404 79 HANDLEBAR LEG No Model Compatibility List $87.17 / Each

11
212033 120959 212033 91 HANDLEBAR ENDCAP No Model Compatibility List $4.88 / Each

9,11
100699 212055 22 M8 X 25MM PATCH SCREW No Model Compatibility List $1.80 / Each

2
212500 113421 212500 50 M8-1.25 X 45MM Button Head Screw Yes Model Compatibility List $3.83 / Each

2
212598 120301 212598 25 HANDLEBAR SPACER Yes Model Compatibility List $12.62 / Each

2,9,11
212601 120300 212601 23 HANDLEBAR CAP Yes Model Compatibility List $6.71 / Each
Out Of Stock
9,11
115266 212821 92 PIVOT AXLE No Model Compatibility List $55.66 / Each

8
213148 100797 213148 94 WAVE WASHER No Model Compatibility List $1.65 / Each

2
120956 216445 17 FRONT SPRING BRACKET No Model Compatibility List $17.93 / Each

2,3,4,5,6
120953 216491 8 PEDAL DISC No Model Compatibility List $137.25 / Each

8,9
120958 216535 82 RIGHT SPRING BRACKET No Model Compatibility List $32.34 / Each

2,3,4,5,6
120955 216536 16 LEFT SPRING BRACKET No Model Compatibility List $32.34 / Each

2,3,4,5,6
220047 112958 220047 93 M3 X 12MM SCREW No Model Compatibility List $2.13 / Each

2
224431 116072 224431 75 EYEBOLT M6 No Model Compatibility List $2.97 / Each

2
120991 228811 # USER'S MANUAL, UK No Model Compatibility List $0.00 / Each
Out Of Stock
1
120992 228812 # USER'S MANUAL, FRENCH No Model Compatibility List $0.00 / Each
Out Of Stock
1
120993 228813 # USER'S MANUAL, GERMAN No Model Compatibility List $0.00 / Each
Out Of Stock
1
120994 228814 # USER'S MANUAL, ITALIAN No Model Compatibility List $0.00 / Each
Out Of Stock
1
120995 228815 # USER'S MANUAL, SPANISH No Model Compatibility List $0.00 / Each
Out Of Stock
1
120996 228816 # USER'S MANUAL, DUTCH No Model Compatibility List $0.00 / Each
Out Of Stock
1
120986 228818 88 SPRING BRACKET SPACER No Model Compatibility List $2.31 / Each

2,3,4,5,6
120980 229154 2 UPRIGHT No Model Compatibility List $110.68 / Each

3
120981 229236 9 LEFT HANDLEBAR No Model Compatibility List $92.29 / Each

11
120982 229237 10 RIGHT HANDLEBAR No Model Compatibility List $92.29 / Each

11
120997 229238 # EURPEAN HARDWARE KIT No Model Compatibility List $51.76 / Each

1
120987 229386 96 WATER BOTTLE HOLDER No Model Compatibility List $17.12 / Each

1
120990 229391 106 POWER BRACKET No Model Compatibility List $5.91 / Each

2,3,4,5,6
120985 229414 87 LOWER WIRE HARNESS No Model Compatibility List $6.94 / Each

4,5,6
120983 229415 74 POWER CORD No Model Compatibility List $7.19 / Each

4,5,6
234898 120312 234898 76 SPRING Yes Model Compatibility List $12.03 / Each

2
100778 235321 108 M8 WASHER No Model Compatibility List $1.61 / Each

2
249938 100677 249938 47 FLANGE SCREW No Model Compatibility List $47.34 / Each

2
256295 101392 256295 24 LIFT BUSHING No Model Compatibility List $4.64 / Each

8,10
100823 258868 # DECAL, GENERAL WARNING No Model Compatibility List $0.24 / Each

7,3
045008 100604 045008 # 5MM ALLEN WRENCH No Model Compatibility List $3.85 / Each

2
045021 100541 045021 # 6MM ALLEN WRENCH No Model Compatibility List $5.28 / Each

2
212604 1019375 212604 26 2 Inner Handlebar Cover Yes Model Compatibility List $12.99 / Each

9
View Drawing
