Horizon Fitness - S400 - 2008
Repair Parts for Horizon Fitness S400 GM208
Brand: Horizon Fitness
Category: Home Gym
Type: Strength Systems
Model Name: S400
Version: 2008
Exploded Diagrams
"Used Only" - contact us if interested in used or refurbished parts. Send us mail:
X-
Views
| Image | Catalog # | MPN | Part List Key | Quantity On Model | Part Description | Notes | Available Used | Model Compatibility List | New price |
|---|---|---|---|---|---|---|---|---|---|
 |
700299 | 000893-B | H13 | End Cap;Handlebar | No | Model Compatibility List | $1.90 / Each |
||
 |
700454 | 001410-A | G26 | End Cover;Elliptical;40x80 | No | Model Compatibility List | $3.64 / Each |
||
 |
700467 | 001440-AA | T11 | Seat Adjustment Knob | No | Model Compatibility List | $9.10 / Each Out Of Stock |
||
 |
700518 | 001522-B | T10 | Stopper Block;Rubber | No | Model Compatibility List | $3.64 / Each |
||
 |
700519 | 001523-E | G53 | Rubber Stop;CAM | No | Model Compatibility List | $3.64 / Each |
||
 |
701434 | 004481-Z | Z33 | Screw;Hex Socket;Round;M8x1.25Px45L | No | Model Compatibility List | $2.00 / Each |
||
 |
701475 | 004522-AD | Z26 | Screw;Hex Socket;Round;M10x1.5Px25L;Zinc | No | Model Compatibility List | $5.46 / Each |
||
 |
701500 | 004536-ZAB | Z21 | Screw;Hex Socket;Round;M8x1.25Px15L;Zinc | No | Model Compatibility List | $2.68 / Each |
||
 |
701608 | 004628-A | Z12 | Screw;Umbrella Cross Tapped;;M5x0.8Px15L | No | Model Compatibility List | $2.00 / Each |
||
 |
701778 | 004794-ZAB | Z15 | Screw;Hex Socket;BH;M12x1.75Px25L;Zinc; | No | Model Compatibility List | $2.94 / Each |
||
 |
701897 | 004926-00 | Z10 | Nut;Nylon;M8x1.25P | No | Model Compatibility List | $2.00 / Each |
||
 |
701914 | 004943-00 | Z06 | Nut;Nylon;M10x1.5P;Cr Plate; | No | Model Compatibility List | $2.00 / Each |
||
 |
702058 | 005085-AC | Z14 | Washer;Flat;5.2x10.0x1.5T | No | Model Compatibility List | $1.56 / Each |
||
 |
702103 | 005132-AB | Z16 | Washer;Flat;13.0x26.0x2.5t;Zinc; | No | Model Compatibility List | $0.34 / Each |
||
 |
702248 | 005375-AB | F21 | Clamp;E-Shaped Ring;E-19 | No | Model Compatibility List | $0.21 / Each |
||
 |
702256 | 005388-00 | Z41 | Wrench;13/17mm;150L | No | Model Compatibility List | $4.00 / Each |
||
 |
702261 | 005406-00 | Z39 | Screwdriver;Phillip;6x100L | No | Model Compatibility List | $4.03 / Each |
||
| 702263 | 005411-Z | Z37 | Wrench;L-Type;4mm | No | Model Compatibility List | $4.00 / Each |
|||
 |
702264 | 005412-00 | Z38 | Wrench;L-Type;5mm;With Screwdriver | No | Model Compatibility List | $2.00 / Each |
||
 |
702265 | 005418-00 | KIT | Wrench;L-Type;6mm | No | Model Compatibility List | $1.85 / Each |
||
 |
704000 | 020087-A | Z17 | Screw;Hex Socket;Round;M10x1.5Px85L | No | Model Compatibility List | $2.68 / Each |
||
 |
704005 | 020098-AB | Z02 | Screw;Hex Socket;Round;M10x1.5Px70L;Zinc | No | Model Compatibility List | $8.37 / Each |
||
 |
704026 | 020115-AC | G36 | Screw;Hex Socket;Round;M10x1.5Px95L;Zinc | No | Model Compatibility List | $2.03 / Each |
||
 |
704107 | 020256-00 | C14 | Screw;Oval Hex Socket;M5x.8Px10L;Black Zinc | No | Model Compatibility List | $4.00 / Each |
||
 |
704284 | 022231-A | C13 | Pad Frame Stabilizer | No | Model Compatibility List | $1.79 / Each |
||
 |
704997 | 028632-AC | H17 | Screw;Hex Socket;Round;M10x1.5Px45L(Toot | No | Model Compatibility List | $3.61 / Each |
||
 |
705014 | 029160-AA | E03 | End Cap;Handlebar | No | Model Compatibility List | $1.79 / Each |
||
 |
705325 | 040842-A | Z36 | Wrench;Hex;L-Type;M8x120L; | No | Model Compatibility List | $5.12 / Each |
||
 |
705405 | 049066-AA | T15 | Cap;25x50x3.0t;MS100;MS100-D27A | No | Model Compatibility List | $2.29 / Each |
||
 |
706171 | 059814-AX | KIT | Decal;Console;Horizon Logo | No | Model Compatibility List | $8.87 / Each |
||
 |
706604 | 063763-AA | T12 | Cap Bottom | No | Model Compatibility List | $3.82 / Each |
||
 |
707217 | 1000091243 | AM1 | Pedal Set;Painting;GM204 | No | Model Compatibility List | $239.30 / Each |
||
| 707941 | 1000097123 | Z28 | Steel Rope;4;Exrta-Work;Steel Rope Head; | No | Model Compatibility List | $64.19 / Each |
|||
 |
721052 | 1000380094 | Z31 | Karabiner Spring Snap;;9(45mmx90mm);Sta | No | Model Compatibility List | $24.91 / Each |
||
 |
725207 | 102717 | AK04 | Top Plate Set | No | Model Compatibility List | $104.23 / Each |
||
 |
725258 | 103298 | H15 | Bushing;Pivot Block;Pedal Arm | No | Model Compatibility List | $11.96 / Each |
||
| 725280 | 005048 | Z09 | FLAT WASHER | No | Model Compatibility List | $0.00 / Each Out Of Stock |
|||
 |
725707 | 075018 | B03 | Support Plate | No | Model Compatibility List | $1.59 / Each |
||
 |
725708 | 075040 | Z35 | Steel Rope2;CSG3;GM200-S400 | No | Model Compatibility List | $44.93 / Each |
||
 |
725709 | 075042 | H31 | Steel Rope;CSG3;GM200-SXS5.7 | No | Model Compatibility List | $10.30 / Each |
||
 |
725710 | 075047 | F06 | Fix Base;U Type;CSG3;GM200 | No | Model Compatibility List | $2.31 / Each |
||
 |
725712 | 075104 | K19 | Cap;ADJ Tube;;CSG3;GM200-S400 | No | Model Compatibility List | $0.70 / Each |
||
 |
725714 | 075118 | G37 | Sleeve;20#;GM204 | No | Model Compatibility List | $5.98 / Each |
||
 |
725715 | 075121 | J03 | Leg Pad | No | Model Compatibility List | $12.27 / Each |
||
 |
725893 | 077785 | Q04 | Fixing Plate;U;GM204 | No | Model Compatibility List | $1.61 / Each |
||
 |
725894 | 077791 | AG4 | ADJ Set;Swivel Arm;Painting;GM204-SXS5.7 | No | Model Compatibility List | $182.34 / Each |
||
 |
725895 | 077793 | G27 | Cover;Sticker;F;GM204-SXS5.7 | No | Model Compatibility List | $14.20 / Each |
||
 |
725896 | 077797 | K02 | weight plate;10P;GM204 | No | Model Compatibility List | $33.77 / Each |
||
 |
725897 | 077798 | K03 | Guide Rail;Cr Plate;GM204 | No | Model Compatibility List | $25.77 / Each Out Of Stock |
||
 |
725898 | 077804 | K08 | ADJ Pin;weight plate;GM204-S400 | No | Model Compatibility List | $14.01 / Each |
||
 |
725899 | 077805 | K09 | Sleeve;D;weight plate;GM204 | No | Model Compatibility List | $2.29 / Each |
||
 |
725900 | 077806 | K10 | stop;weight plate;GM204 | No | Model Compatibility List | $1.72 / Each |
||
 |
725901 | 077807 | K11 | Supt block;weight plate;GM204 | No | Model Compatibility List | $7.70 / Each |
||
 |
725902 | 077808 | K12 | Sleeve;U;weight plate;GM204 | No | Model Compatibility List | $5.59 / Each |
||
 |
726465 | 081981 | H14 | Mandrel;GM204 | No | Model Compatibility List | $6.40 / Each |
||
 |
726472 | 082135 | M06 | Screw;Round Hex Socket;M8x1.25Px60L-15L;Zinc | No | Model Compatibility List | $1.33 / Each |
||
 |
726476 | 082141 | Z03 | Screw;Round Hex Socket;M10x1.5Px60L;Zinc | No | Model Compatibility List | $1.46 / Each |
||
 |
726477 | 082142 | Z04 | Screw;Round Hex Socket;M10x1.5Px65L;Zinc | No | Model Compatibility List | $5.12 / Each |
||
 |
726478 | 082147 | T16 | Screw;Round Hex Socket;M10x1.5Px35L;Zinc | No | Model Compatibility List | $2.34 / Each |
||
 |
726479 | 082148 | Z13 | Screw;Round Hex Socket;M8x1.25Px20L;Zinc | No | Model Compatibility List | $0.23 / Each |
||
 |
726480 | 082149 | Z19 | Screw;Round Hex Socket;M8x1.25Px90L;Zinc | No | Model Compatibility List | $2.34 / Each |
||
 |
726481 | 082150 | Z20 | Screw;Round Hex Socket;M5x0.8Px10L;Zinc | No | Model Compatibility List | $0.23 / Each |
||
 |
726537 | 082638 | F24 | Dual floating pulley bracket | No | Model Compatibility List | $6.79 / Each |
||
 |
726603 | 083370 | AT3 | Seat Adjustment Bar | No | Model Compatibility List | $98.15 / Each |
||
 |
726723 | 084373 | G21 | Pin;Radial Arm | No | Model Compatibility List | $15.34 / Each |
||
 |
726800 | 084905 | F17 | Washer;Flat;10.2X22X2.0T | No | Model Compatibility List | $0.36 / Each |
||
 |
726801 | 084906 | M07 | Washer;Flat8.4X15.5X1.6T | No | Model Compatibility List | $1.85 / Each |
||
 |
726864 | 085685 | C22 | Screw;Hex; Zn Plate;M10x1.5Px60L; | No | Model Compatibility List | $1.79 / Each |
||
 |
726867 | 085722 | H26 | Cap;60.0x3.0t | No | Model Compatibility List | $1.38 / Each |
||
 |
726898 | 085920 | F14 | Pulley;90.2;Market;GM204 | No | Model Compatibility List | $14.79 / Each |
||
 |
726944 | 086156 | E04 | Grip;Pulldown ;Foam;GM208-SXS5.7 | No | Model Compatibility List | $7.20 / Each |
||
 |
726972 | 086280 | KIT | Decal;Weight Plate;LBS;GM204 | No | Model Compatibility List | $38.74 / Each |
||
 |
726973 | 086285 | KIT | Owners Manual | No | Model Compatibility List | $17.65 / Each |
||
 |
726980 | 086432 | H12 | Cap;50.8x2.0T Market;GM204 | No | Model Compatibility List | $1.61 / Each |
||
 |
726982 | 086452 | Z11 | Screw;Hex Socket;Round;M10x1.5Px30L | No | Model Compatibility List | $1.56 / Each |
||
 |
727092 | 087183 | V13 | Decal;Swivel Arm;Left | No | Model Compatibility List | $6.40 / Each |
||
 |
727093 | 087184 | V14 | Decal;Swivel Arm;Right | No | Model Compatibility List | $6.40 / Each |
||
| 727187 | 087578 | J01 | Back Pad;Blue Silver;GM208 | No | Model Compatibility List | $90.25 / Each |
|||
 |
727224 | 087885 | Z37 | Ankle Strap | No | Model Compatibility List | $23.45 / Each |
||
 |
727226 | 087953 | V18 | Flip Book | No | Model Compatibility List | $97.47 / Each |
||
 |
727230 | 087977 | H29 | Screw;Hex Socket;Round;;M10x1.5Px30L | No | Model Compatibility List | $2.24 / Each |
||
 |
727239 | 088030 | G31 | Handle | No | Model Compatibility List | $14.01 / Each |
||
 |
727304 | 088461 | J04 | Sleeve;Back Pad;Blue;GM208-US | No | Model Compatibility List | $12.97 / Each |
||
 |
727330 | 088574 | Z25 | Cable;14.8x2685;GM208-S400 | No | Model Compatibility List | $55.35 / Each |
||
 |
727350 | 088742 | K14 | Sleeve;Weight;plate;GM204 | No | Model Compatibility List | $1.01 / Each |
||
 |
728189 | 093513 | AG1 | Disassembly CON Set;F:Painting;S400 | No | Model Compatibility List | $265.43 / Each |
||
 |
728795 | 097446 | Q03 | Fix Plate;F;Cover;GM208-US | No | Model Compatibility List | $15.73 / Each |
||
 |
972298 | 005411-Z | Z37 | Allen Wrench Key 4mm | No | Model Compatibility List | $15.99 / Each Out Of Stock |
||
|
|
|||||||||
