Horizon Fitness - T500 - 2008-2009

Repair Parts for Horizon Fitness T500 TM307

Brand: Horizon Fitness

Category: Folding

Type: Folding Treadmill

Model Name: T500

Version: 2008-2009

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Motors
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Belt Related
  • Switch
  • Motor
  • Sensors
  • Controllers and Circuits
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
L 700022 000037-CC L06 Wheel;Nylon No Model Compatibility List $3.82 / Each

8
Q 700216 000696-AA Q20 Foam Tape,Double Sided;320x40x2.0T No Model Compatibility List $1.77 / Each

1
B 700245 000767-D B57 Elastomer;Orange;20x44L Yes Model Compatibility List $19.21 / Each

1
B 700246 000768-D B58 Elastomer;Blue;20x44L Yes Model Compatibility List $18.64 / Each

1
G 700323 000960-AA G03 End Cap;Upper Vertical Handlebar Yes Model Compatibility List $3.89 / Each

9,11
L 700402 001251-F L10 Rail Lock;Fixing Washer;Side Rail Yes Model Compatibility List $7.90 / Each

2,9
H 700418 001299-B H05 Cover;Elevation Frame;PVC No Model Compatibility List $9.57 / Each

9,3,10
N 700570 001679-00 N29 Tie Strap;Adhesive;Nylon;66;HC-101;W No Model Compatibility List $2.81 / Each

2
N 700700 001952-00 N10 Fixing Plate;Reed Switch No Model Compatibility List $1.90 / Each

3,4,5,6
P 700741 002108-C P30 Console Cable;Mast;1500L(5557 SERIES+2.5-12P) Yes Model Compatibility List $40.92 / Each

4,5,6,7
P 700746 002124-B P08 Connecting Cable;Socket/Breaker;60;16AWG Black No Model Compatibility List $3.82 / Each

4,5,6
700755 002169-A P07 Power Cord;16AWG Yes Model Compatibility List $60.22 / Each

4,5,6
700773 002248-D P14 Speed Sensor Wire;1000mm(Reed Switch+2.5-2P) Yes Model Compatibility List $18.15 / Each

4,5,6
P 700847 002508-A P20 Power Wire;Control Board;550;16AWG;Black No Model Compatibility List $1.90 / Each

7,4,5,6
P 700848 002509-A P21 Power Wire;Control Board;550;16AWG;White Yes Model Compatibility List $1.90 / Each

7,4,5,6
N 700893 002671-A N72 Audio Wire;Three-D Earphone Yes Model Compatibility List $9.99 / Each

7,4,5,6,12,13,14
701013 003326-00 P02 Power Switch;Large;RF-1004 Yes Model Compatibility List $32.71 / Each

4,5,6
701020 003346-00 P04 Circuit Breaker;12A;125V/250V Yes Model Compatibility List $30.11 / Each

4,5,6
701026 003363-00 P11 Power Socket;100-600-60(O TYPE END);16AWG Yes Model Compatibility List $9.57 / Each

9,4,5,6
M 701033 003386-A M17 Ferrite Core;T31x16x19-C No Model Compatibility List $13.26 / Each

1
R 701044 003415-00 R11 Magnet;Front Roller;10X3T No Model Compatibility List $1.90 / Each

8
P 701328 004381-00 P17 Screw;Oval Head;M5x0.8Px25L No Model Compatibility List $2.00 / Each

2
P 701364 004415-Z P13 Screw;M3x0.5Px10L;Power Socket No Model Compatibility List $1.79 / Each

2,4,5,6
L 701375 004425-B L11 Screw;Phillip;Sink;Tapped;5x15L; No Model Compatibility List $2.00 / Each

2
R 701401 004454-00 R08 Screw;Round;Hex Socket;M5X0.8PX15L No Model Compatibility List $1.79 / Each

2
B 701408 004462-00 B62 Screw;Round;Hex Socket;M6x1.0Px15L;Chromed No Model Compatibility List $2.00 / Each

7,2,12,13,14
M 701432 004480-Z M46 Screw;Hex Socket;Round;M8x1.25Px30L Yes Model Compatibility List $7.20 / Each

2
R 701445 004488-00 R09 Screw;Hex Socket;Round;M8x1.25Px55L;BED; Yes Model Compatibility List $2.00 / Each

2
M 701454 004502-00 M06 Screw;Hex Socket;Round;5/16-18UNCx16L;Ad No Model Compatibility List $2.00 / Each

2
M 701476 004523-00 M45 Screw;Hex Socket;Round;M8x1.25Px40L;Adhe No Model Compatibility List $2.00 / Each

2
B 701530 004562-00 B36 Bolt;Deck;M8x1.25Px35L Yes Model Compatibility List $5.85 / Each

2
H 701534 004565-00 H50 Screw;Hex Socket;Sink;M8x1.25Px12L No Model Compatibility List $2.00 / Each

2
M 701559 004590-Z M14 Bolt;Incline Motor Bottom;W3/8X57L(WHORL:14L) Yes Model Compatibility List $1.79 / Each

2,10
M 701562 004595-00 M10 Screw;Hex;3/8-16UNC-42L/Tooth14L; No Model Compatibility List $2.00 / Each

2
N 701581 004614-AB N59 Screw;Phillip;Umbrella;Tapped;3x10L;Black No Model Compatibility List $2.00 / Each

2,4,5,6
N 701586 004617-00 N19 Screw;Console Case;Oval Tapping;4x15L No Model Compatibility List $2.00 / Each

7,2,12,13,14
M 701591 004620-00 M19 Screw;Self Tapping;4x12L No Model Compatibility List $2.00 / Each

2,12,13,14
Q 701612 004631-00 Q32 Screw;Phillip;BH;Tapped;4x25L No Model Compatibility List $2.00 / Each

2
Z 701683 004714-AD Z14 Screw;Hex Socket;BH;M6x1.0Px15L;Adhere No Model Compatibility List $2.00 / Each

2
701699 004724-00 H25 Bolt;M8x1.25Px15L Yes Model Compatibility List $2.00 / Each

2
Z 701827 004847-AB Z11 Set Screw;M10X1.5PX12L Yes Model Compatibility List $6.99 / Each

2
Z 701841 004859-00 Z09 Screw;Umbrella Hex Scoket;M8x1.25Px20L No Model Compatibility List $2.00 / Each

2
Q 701847 004864-00 Q30 Screw;4x12L No Model Compatibility List $2.00 / Each

2
Q 701849 004867-A Q31 Screw;Phillip;Big BH;Tapped;4x15L No Model Compatibility List $2.00 / Each

2
P 701858 004880-00 P16 Nut;Zero Switch Cable;M3x0.5Px3H No Model Compatibility List $2.00 / Each

2,4,5,6
P 701866 004889-00 P19 Nut;Hex;M5x0.8P;Nickel No Model Compatibility List $2.00 / Each

2
R 701876 004903-Z R10 Nut;Hex;M5x0.8Px4H No Model Compatibility List $2.00 / Each

2
M 701897 004926-00 M08 Nut;Nylon;M8x1.25P No Model Compatibility List $2.00 / Each

2
M 701908 004934-00 M12 Nut;Nylon;3/8'-16UNC No Model Compatibility List $1.59 / Each

2
L 701912 004941-00 L08 Nut;Nylon;M10x1.5P No Model Compatibility List $2.00 / Each

2
B 701939 004975-00 B59 Insert Nut;Brass;ALS7-8125-3.8(0.5-3.8) No Model Compatibility List $1.90 / Each

2
M 701964 005005-00 M25 Washer;Spring;Lock;8.2x15.4x2.0t No Model Compatibility List $1.59 / Each

2
B 701975 005013-00 B63 Washer;Spring;6.0x10.0x1.5t No Model Compatibility List $2.00 / Each

2
R 702007 005044-00 R06 Washer;Flat8.3x16x1.3T;Black Zinc No Model Compatibility List $2.00 / Each

2,4,5,6
Z 702011 005047-00 Z07 Washer;Flat;8.2x20x1.8T;Black Zinc No Model Compatibility List $2.00 / Each

2,4,5,6
L 702030 005062-00 L07 Washer;Flat;10.2x19x2.0T;Chromed No Model Compatibility List $1.59 / Each

7,2,12,13,14
B 702063 005091-00 B40 Washer;Flat;4.2X10.0X1.2T;BAN No Model Compatibility List $2.00 / Each

2
M 702121 005146-A M13 Washer;Flat;10.5x20x2.0T;Black Zinc No Model Compatibility List $2.00 / Each

2,4,5,6
H 702160 005196-00 H27 Washer;Teflon;10.5x20.0x1.0T No Model Compatibility List $1.59 / Each

2
H 702161 005198-00 H29 Washer;Teflon;15.9x28.4x1.0T No Model Compatibility List $2.00 / Each

2
C 702169 005210-A C26 Washer;Teflon;20.3x25x1.0T No Model Compatibility List $2.00 / Each

2
H 702171 005212-A H28 Washer;Teflon;12.2x18x1.0T No Model Compatibility List $2.00 / Each

2
H 702186 005229-00 H20 Washer;Wavy;20.5x29.0x1.5T;Nylon No Model Compatibility List $2.00 / Each

2,4,5,6
H 702189 005232-A H22 Washer;Wavy;12.7x18x0.3T No Model Compatibility List $2.00 / Each

2,4,5,6
Q 702217 005330-00 Q17 Tinnamen Nut Yes Model Compatibility List $1.59 / Each

2
Z 702257 005393-00 Z02 Wrench;T-Type;6mm No Model Compatibility List $10.24 / Each

2
Z 702258 005394-00 Z01 Wrench;T-Type;8mm No Model Compatibility List $10.01 / Each

2
Z 702259 005395-00 Z03 Wrench;T-Type;5mm No Model Compatibility List $10.01 / Each

2
Z 702263 005411-Z Z05 Wrench;L-Type;4mm No Model Compatibility List $4.00 / Each

2
V 702347 006340-AX V51 Short Foot Grip;Left Front Side Rail; No Model Compatibility List $3.54 / Each

9,3,11
V 702348 006341-AX V50 Long Foot Grip,Left Front Side Rail; No Model Compatibility List $8.87 / Each

9,3,11
V 702349 006342-AX V52 Long Foot Grip,Right Front Side Rail; No Model Compatibility List $9.57 / Each

9,3,11
V 702350 006343-AX V53 Short Foot Grip-Right Front Side Rail; No Model Compatibility List $3.82 / Each

9,3,11
702446 007384-E B25 Fixing Plate;Motor Control Board No Model Compatibility List $9.59 / Each

7,3,10
B 702450 007490-C B52 Fix Plate;Speed Sensor No Model Compatibility List $1.90 / Each

3
H 702556 008625-C H19 Bolt;Incline Support;M8x1.25Px32L No Model Compatibility List $2.00 / Each

2,3,10
H 702558 008628-B H14 Bolt;Special;Support Tube Base;M8x1.25Px54L No Model Compatibility List $4.00 / Each

2,3
B 702762 009562-AX B56 Air Shock;85-90KG(125L) Yes Model Compatibility List $34.27 / Each

1
Z 702798 010680-00 Z08 Washer;Spring;Support Tube;M8X1.25PX16L No Model Compatibility List $2.00 / Each

2,3
703439 014670-E AR1 Front Roller Set No Model Compatibility List $126.26 / Each

8
N 703916 019316-A N62 Safety Key Reed Switch Yes Model Compatibility List $9.57 / Each

4,5,6
R 704033 020121-A R04 Bolt;Rear Roller;Hex Socket;M8x1.25Px70L;Chromed Yes Model Compatibility List $4.00 / Each

7,2,8,12,13,14
N 704091 020214-A N58 Screw;Phillip;Round;3x18L No Model Compatibility List $1.85 / Each

2
H 704215 020487-ZA H21 Washer;Flat;10.5x18x2.5T No Model Compatibility List $2.00 / Each

2
Z 704229 020668-00 Z04 Wrench;Hex;L-Type;#10mmx170L; No Model Compatibility List $4.00 / Each

2
Q 705013 029150-AA Q22 Tape;Foam;Double Sided;50.0X200.0X2.0T No Model Compatibility List $1.77 / Each

1
705041 032671-HF M03 Motor Control Board;Digital Drive;1.75/2.0HP Yes Model Compatibility List $453.52 / Each

7,10
N 705181 039042-A N64 Pulse Sensor Set Yes Model Compatibility List $18.28 / Each

12,13,14
M 705182 039043-00 M02 Elevation Motor Set;110V/80mm(225/3.96-4Pin) Yes Model Compatibility List $331.29 / Each

10,12,13,14
N 705285 040613-B N63 Ground Wire;250 No Model Compatibility List $1.90 / Each

4,5,6
H 705488 049292-A H23 Washer;Flat;Teflon;8.1x20x1.0t; No Model Compatibility List $2.00 / Each

2
V 705707 055269-AX V03 Decal;Faceplate No Model Compatibility List $3.82 / Each

7,3,4,5,6
M 705857 056374-AA M07 Rubber Pad;Drive Motor;Shockproof No Model Compatibility List $9.57 / Each

10,12,13,14
M 706218 060295-CA M04 Digital Speed Sensor Yes Model Compatibility List $42.02 / Each

1
P 706349 061300-A P06 Console Cable;Upper;550L Yes Model Compatibility List $31.33 / Each

4,5,6,7
Z 706838 066044-A Z21 Washer;Flat;20.2x27.0x2.5T;Black Zinc No Model Compatibility List $2.00 / Each

2,4,5,6
M 707591 1000093557 M05 Drive Motor Bracket Yes Model Compatibility List $25.97 / Each

2,3,4,5,6,10
709031 1000108437 AR2 Roller Set;Rear;TM116 Yes Model Compatibility List $191.62 / Each

8
R 709102 1000109577 R03 Drive Belt;Poly-V;170-J8 Yes Model Compatibility List $60.22 / Each

15,10
709278 1000111822 M01 Motor set;Semi-Assy;;BLACK C;2.25HP/90V; Yes Model Compatibility List $648.70 / Each

4,5,6,10
End Cap, Support Tube 725355 070422 F05 End Cap, Support Tube No Model Compatibility List $3.82 / Each

9,3
Upper Control Board (UCB) 725424 071095 N60 Upper Control Board (UCB) No Model Compatibility List $229.97 / Each

7
Fix Axle; Console Mast 725471 071757 B30 Fix Axle; Console Mast No Model Compatibility List $19.32 / Each

7,8
Swivel Axle 725481 071830 H18 Swivel Axle No Model Compatibility List $15.76 / Each

8
Spring; Foot Lock Latch 725500 072019 H30 Spring; Foot Lock Latch No Model Compatibility List $4.00 / Each

2,9,3
Foam Grip; Handlebar 725599 074053 G02 Foam Grip; Handlebar No Model Compatibility List $3.82 / Each

11
Incline Frame Set 725600 074055 AH1 Incline Frame Set No Model Compatibility List $116.25 / Each

3,10
Foot Lock Latch 725602 074057 H31 Foot Lock Latch No Model Compatibility List $10.87 / Each

9,3
Linkage Arm; Lower Left 725603 074058 AH3 Linkage Arm; Lower Left No Model Compatibility List $31.30 / Each

3
Linkage Arm; Lower Right 725604 074059 AH4 Linkage Arm; Lower Right No Model Compatibility List $39.10 / Each

3
Cover,Console 725605 074062 N01 Cover,Console No Model Compatibility List $115.31 / Each

7,9
Holder; MP3 Player 725606 074064 N05 Holder; MP3 Player No Model Compatibility List $25.56 / Each

1
Motor Cover; Upper 725607 074075 Q01 Motor Cover; Upper Yes Model Compatibility List $88.66 / Each

9,10
Roller End Cap; Right 725608 074081 Q07 Roller End Cap; Right Yes Model Compatibility List $16.69 / Each

8,9
End Cap; Front Main Frame 725609 074082 Q09 End Cap; Front Main Frame Yes Model Compatibility List $3.82 / Each

9,3
Decal; Motor Cover 725610 074087 V06 Decal; Motor Cover No Model Compatibility List $10.32 / Each

7,9,3,10
Keypad 725618 074239 N61 Keypad No Model Compatibility List $191.62 / Each

9,12,13,14
Console Mast;Left 725725 075193 AC1 Console Mast;Left No Model Compatibility List $191.57 / Each

7
Console Mast;Right 725726 075194 AC2 Console Mast;Right No Model Compatibility List $192.27 / Each

7
Faceplate-T500 725727 075195 N02 Faceplate-T500 No Model Compatibility List $27.59 / Each

3,4,5,6
Running Belt;;;Black;;495x2590x1.6t 725728 075197 R02 Running Belt;;;Black;;495x2590x1.6t No Model Compatibility List $249.13 / Each

15,4,5,6
Hardware Pack-T500 725752 075930 KIT Hardware Pack-T500 No Model Compatibility List $34.92 / Each

4,5,6
Sticker;;L;Consle POP;;TM307 725883 077685 V22 Sticker;;L;Consle POP;;TM307 No Model Compatibility List $3.54 / Each

12,13,14
Sticker;R;Consle POP;TM307 725884 077686 V23 Sticker;R;Consle POP;TM307 No Model Compatibility List $3.54 / Each

12,13,14
Sticker; Cover;;B;;TM307 725885 077688 V39 Sticker; Cover;;B;;TM307 No Model Compatibility List $3.54 / Each

9
Sticker;;Console;;TM307 725886 077690 V07 Sticker;;Console;;TM307 No Model Compatibility List $12.87 / Each

7
Sticker;air cushion ;L;;TM307 725887 077691 V34 Sticker;air cushion ;L;;TM307 No Model Compatibility List $3.54 / Each

3
Sticker;air cushion ;R;;TM307 725888 077692 V35 Sticker;air cushion ;R;;TM307 No Model Compatibility List $3.54 / Each

3
Manual,Owner 725890 077695 KIT Manual,Owner No Model Compatibility List $9.65 / Each

1
Connect Wire;Head Phone;TM307 725962 078655 N65 Connect Wire;Head Phone;TM307 No Model Compatibility List $8.87 / Each

4,5,6
Running Deck-682x1140x18T-T500 726028 079381 B27 Running Deck-682x1140x18T-T500 No Model Compatibility List $249.13 / Each

3
Handlebar Set (w/foam),Left-T500 726098 079929 G01 Handlebar Set (w/foam),Left-T500 No Model Compatibility List $53.12 / Each

11
Side Rail Set 726216 080756 Q05 Side Rail Set Yes Model Compatibility List $82.08 / Each

9
Safety Key Set 726500 082397 AN3 Safety Key Set Yes Model Compatibility List $42.74 / Each

9
Handlebar Set;Right 726860 085663 G04 Handlebar Set;Right No Model Compatibility List $53.12 / Each

11
Board;Audio Input/Output 726886 085785 N50 Board;Audio Input/Output No Model Compatibility List $12.43 / Each

1
Display Console - Used Only 1001214 SUH-t121f-1 Display Console - Used Only No Model Compatibility List $180.70 / Each
Out Of Stock 		7
Cushion Deck-T500 (Used) 1023186 074076 Q03 Cushion Deck-T500 (Used) No Model Compatibility List $51.99 / Each

1
Endcap Left (Used) 1023213 074079 Q06 Endcap Left (Used) No Model Compatibility List $20.79 / Each

1
Coaxial TV Video Cable Wire (Used) 1023151 T500-CTVVCW 0 1 Coaxial TV Video Cable Wire (Used) No Model Compatibility List $12.99 / Each

1
M 039043-00 039043-00 M02 1 Incline Elevation Motor Yes Model Compatibility List $336.70 / Each

1
DC Drive Motor Johnson 1000111822 JM05-015 0 1 DC Drive Motor Johnson Yes Model Compatibility List $674.57 / Each

1
Screw 3/8-16-1.65 (Used) 1026732 004595-B 0 1 Screw 3/8-16-1.65 (Used) No Model Compatibility List $5.99 / Each

1
P 1001381 003326-00 P02 1 Power Switch Yes Model Compatibility List $29.99 / Each

6,24
P 1001764 002169-A P07 1 Power Cord Yes Model Compatibility List $39.99 / Each

6
sCREW 3/8-16-1.60 1026937 ME0106026B 0 1 sCREW 3/8-16-1.60" (Used) No Model Compatibility List $3.99 / Each

1
P 1002002 002169-A P07 1 Cord Power Yes Model Compatibility List $34.99 / Each

6
P 1002861 002248-D P14 1 Sensor RPM Yes Model Compatibility List $25.99 / Each

47
M 1002968 039043-00 M02 1 Motor Incline Yes Model Compatibility List $189.99 / Each

28
M 1003509 032671-HF M03 1 Controller Yes Model Compatibility List $265.00 / Each

48
M 1029909 004480-Z M46 Screw (Used) Yes Model Compatibility List $5.00 / Each

1
P 1002658 003363-00 P11 Power Entry Module Yes Model Compatibility List $19.99 / Each

6
View Drawing

general Info

Customer Service

About us

Address

6114 Madison Ct.
Morton Grove, IL 60053
847-309-2818

Hydra Fitness Exchange © 2024. All Rights Reserved.

Payment options
