Life Fitness - Optima Duals Leg Extension

Repair Parts for Life Fitness Optima Duals Leg Extension OSLEC

Brand: Life Fitness

Category: Commercial Strength Equipment

Type: Strength Systems

Model Name: Optima Duals Leg Extension

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Rotating Parts
  • Plastic Parts
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
2 506172 3102514 2 Hardware: Flat Washer 3/8" ID No Model Compatibility List $1.57 / Each

2
6 506290 3223311 6 3/8-16X3-1/2 UNS HEX FHB G5 ZN No Model Compatibility List $10.04 / Each

1
9 506337 3232421 9 Reatining Ring 0.940" D No Model Compatibility List $1.57 / Each

1
3 506348 3235601 3 Ball Bearing No Model Compatibility List $8.15 / Each

1
2 506351 3235801 2 Grip - 1.25" OD No Model Compatibility List $29.86 / Each

11
3 506357 3236001 3 SpringPin Bushing No Model Compatibility List $15.00 / Each

2,8,12,13,14
4 506380 3236503 4 M4 X 0.7 X 10MM PHL PAN MS ST ZN No Model Compatibility List $1.57 / Each

1
2 506389 3236901 2 Hardware: Nut Hex Jam 10 MM No Model Compatibility List $6.00 / Each

2
3 506390 3236902 3 Hardware: Nut 16 MM ID No Model Compatibility List $1.57 / Each

2
1 506393 3237403 1 Plug 1" Hole No Model Compatibility List $1.57 / Each

1
1 506397 3237801 1 Pulley 4.5" OD No Model Compatibility List $29.59 / Each

8
5 506411 3239101 5 Hardware: Phillips Pan Screw No Model Compatibility List $1.57 / Each

2
6 506412 3239103 6 Screw, M5X.8 X 16 PHl PAN TT ST BZ No Model Compatibility List $1.57 / Each

2
5 506430 3239601 5 Pulley - 6" No Model Compatibility List $19.69 / Each

8
6 506434 3240501 6 Set Screw No Model Compatibility List $1.57 / Each

2
5 506465 3243902 5 Ring12 MM No Model Compatibility List $1.57 / Each

1
7 506491 3251703 7 Hardware: Screw 30MM No Model Compatibility List $5.21 / Each

2
4 506494 3251707 4 Hardware: Screw 50MM No Model Compatibility List $1.57 / Each

2
7 506496 3251709 7 Hardware: Screw 60MM No Model Compatibility List $1.57 / Each

2
9 506498 3251711 9 Hardware: Screw 70MM No Model Compatibility List $4.45 / Each

2
1 506502 3251717 1 M10 X 1.5 X 100 HXS SOC CS ST ZN No Model Compatibility List $9.35 / Each

1
1 506503 3251718 1 M10 X 1.5 X 110 HXS SOC CS ST ZN No Model Compatibility List $9.13 / Each

1
1 506504 3251719 1 Hardware: Screw 120MM No Model Compatibility List $3.20 / Each

2
8 506507 3252803 8 M6-1.0 X 12 HXS BUT CS ST ZN No Model Compatibility List $1.51 / Each

1
1 506528 3256205 1 Hardware: Screw 40MM No Model Compatibility List $6.87 / Each

2
7 506540 3257205 7 Hardware: Bolt 25MM No Model Compatibility List $2.80 / Each

2
3 506554 3264101 3 Hardware: Washer No Model Compatibility List $1.57 / Each

2
7 506562 3266603 7 Bearing Flange 19MM No Model Compatibility List $12.54 / Each

1
8 507029 6140701 8 Glide 1 X 1 No Model Compatibility List $3.04 / Each

1
1 507075 6757701 1 Cable Clip No Model Compatibility List $4.86 / Each

2,4,5,6
1 507519 7308701 1 Cap Bearing Housing No Model Compatibility List $3.20 / Each

9
2 507530 7316510 2 Shaft, 25MM X 2.500 No Model Compatibility List $26.50 / Each

1
1 507543 7322301 1 Plate 1.97 OD X .447 ID 10 GA No Model Compatibility List $3.20 / Each

1
1 507590 7328621 1 Guide Rod, .75 OD Solid X 48.60 No Model Compatibility List $86.45 / Each

3
2 507601 7330002 2 Spacer Internal 0.653" L No Model Compatibility List $6.51 / Each

2,3,4,5,6
1 507608 7330010 1 Spacer, Internal X .344 No Model Compatibility List $13.10 / Each

2,3,4,5,6
3 507632 7347301 3 Hardware: Nut 10 MM ID No Model Compatibility List $8.15 / Each

2
9 507645 7351501 9 Pull Pin Spring No Model Compatibility List $1.57 / Each

2,12,13,14
1 507650 7352101 1 Cushion Weight Stack No Model Compatibility List $3.20 / Each

3,4,5,6
1 507663 7353801 1 Weight Plate 15 LB No Model Compatibility List $46.05 / Each

3
2 507673 7357901 2 Shaft Collar No Model Compatibility List $37.81 / Each

1
3 507918 7424799 3 ASSY, ROLLER PAD SHORT Custom No Model Compatibility List $122.08 / Each

8,12,13,14
1 507922 7425102 1 Pull Pin 6.750 No Model Compatibility List $59.25 / Each

12,13,14
5 507995 7446901 5 Hardware: Pin Retaining No Model Compatibility List $33.71 / Each

12,13,14
4 507996 7447001 4 Compression Spring No Model Compatibility List $14.99 / Each

2
1 508110 7489403 1 Bushing, .500 OD X .402 ID X .272 No Model Compatibility List $3.28 / Each

8
1 508113 7489411 1 BSHNG, .500 OD X .402 ID X 0.969 No Model Compatibility List $4.26 / Each

1
8 508534 7571301 8 Label Serial Number No Model Compatibility List $1.57 / Each

1
3 508761 7662901 3 Grip Cap No Model Compatibility List $14.75 / Each

9,11
4 508768 7690101 4 Bumper Sleeve- 1.000 ID No Model Compatibility List $1.57 / Each

3
4 509056 7767601 4 Bumper PS Increment No Model Compatibility List $12.11 / Each

1
3 509147 7800501 3 Small Cap No Model Compatibility List $16.17 / Each

9
8 509331 8039501 8 Label Warning Triangle 10-0099-067 BNR No Model Compatibility List $1.52 / Each

1
3 509342 8045001 3 BEARING Increment Weight No Model Compatibility List $3.86 / Each

3
2 509350 8048001 2 Knob Tulip Style No Model Compatibility List $2.61 / Each

1
6 509654 8254001 6 Axle TCWHL No Model Compatibility List $8.15 / Each

8
1 509713 8308902 1 RUBBER, SELF ADHESIVE X 270.0 No Model Compatibility List $16.73 / Each

1
1 509714 8308903 1 RUBBER, SELF ADHESIVE X 115.0 No Model Compatibility List $13.94 / Each

1
2 509758 8331701 2 Bayonet, OS, 12 Plate No Model Compatibility List $61.34 / Each

1
1 509761 8332101 1 Bracket, OS Tower, Increment Weight Striker No Model Compatibility List $69.03 / Each

2,3,4,5,6
1 509773 8343101 1 Tag - Bolt To Floor No Model Compatibility List $1.87 / Each

2
1 509810 8370701 1 Cover, OS Tower, Top No Model Compatibility List $37.64 / Each

9
1 509812 8370801 1 Shroud, OS Tower No Model Compatibility List $99.70 / Each

12,13,14
2 509817 8370901 2 Shroud, OS Tower, Center, Standard No Model Compatibility List $29.98 / Each

12,13,14
1 509820 8371001 1 Cap, OS Tower, Top No Model Compatibility List $2.80 / Each

9
3 509821 8371201 3 Clip, OS Tower No Model Compatibility List $4.19 / Each

2
4 509822 8371301 4 Cover, OS Tower, Bottom No Model Compatibility List $19.96 / Each

9
7 509838 8418601 7 Cap, Med Flov, Arched No Model Compatibility List $2.08 / Each

9
6 509839 8418801 6 Cap, Sflov, Tube No Model Compatibility List $2.08 / Each

9,3
1 509840 8423801 1 Foot, OS Tower No Model Compatibility List $4.88 / Each

9
2 509862 8452604 2 SHAFT, 19MM, X 93.900 No Model Compatibility List $14.65 / Each

1
1 509863 8452605 1 SHAFT, 19MM DIA X 154.500 MM No Model Compatibility List $19.52 / Each

1
3 509870 8455699 3 Pad, Back, Flat Custom No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6,12,13,14
1 509892 8472902 1 Weldment, OS, 15 Deg Pulley Plate No Model Compatibility List $70.41 / Each

8,3
1 509893 8473099 1 ASSY, OS, 15 DEG. PULLEY Custom No Model Compatibility List $101.77 / Each

8
1 509895 8474501 1 Foot, Optima No Model Compatibility List $16.73 / Each

9
1 509926 8504201 1 BODY, INCREMENT WEIGHT, 7 LB No Model Compatibility List $77.94 / Each

3
1 509927 8504301 1 Assembly, Increment Weight, 7 LB No Model Compatibility List $105.97 / Each

3
2 509928 8505601 2 Assembly, OS Head Plate, 12 Plate No Model Compatibility List $207.08 / Each

1
3 509930 8506101 3 Assembly, Selector Pin No Model Compatibility List $20.23 / Each

12,13,14
1 509943 8514502 1 PLATE, OS PULLEY COVER - PLT No Model Compatibility List $9.77 / Each

8,9
3 509971 8531606 3 Cable, OSLEC, Tower No Model Compatibility List $140.83 / Each

4,5,6
1 509976 8544201 1 Assembly, OS, Spring Pin No Model Compatibility List $40.44 / Each

2,12,13,14
2 510060 8592601 2 Plate, Cable Retainer No Model Compatibility List $4.88 / Each

4,5,6
7 510071 8624101 7 Bushing, Seat Glide Ext. No Model Compatibility List $7.66 / Each

8,12,13,14
8 510072 8624201 8 Bushing, Seat Glide INT. No Model Compatibility List $7.66 / Each

8,12,13,14
9 510083 8630801 9 Label, ASTM, Select Vertical-Sheet No Model Compatibility List $72.52 / Each

1
1 510106 8664101 1 Assembly, OS, Head Plate No Model Compatibility List $132.66 / Each

1
5 510134 8682601 5 Tape, Non-Skid, Clear No Model Compatibility List $1.49 / Each

1
1 510143 8692801 1 Retainer, Guide Rod, Short No Model Compatibility List $9.77 / Each

3
1 510144 8692802 1 Retainer, Guiderod, Long No Model Compatibility List $24.40 / Each

3
2 510166 8701301 2 Stop, Kicker No Model Compatibility List $41.14 / Each

1
9 510187 8716301 9 PLATE, FLOATING STOP No Model Compatibility List $4.05 / Each

1
- 510280 8766208 - Label, OSLEC, Placard No Model Compatibility List $64.84 / Each

4,5,6
- 510294 8766306 - Label, OSLC, Multi Lang Sheet No Model Compatibility List $14.65 / Each

1
- 510295 8766307 - Label, OSLE, Multi Lang Sheet No Model Compatibility List $14.65 / Each

1
- 510309 8769601 - Label, Weight Stack, 13 Plate No Model Compatibility List $23.00 / Each

3,4,5,6
5 510364 8792402 5 ASSY, OSLEC, WORKARM - PLT No Model Compatibility List $344.41 / Each

3
6 510365 8792501 6 ASSY, OSLEC, TIBIA No Model Compatibility List $146.41 / Each

1
9 510366 8792602 9 WLDMT, OSLEC, X-MEM, LOWER - PLT No Model Compatibility List $97.61 / Each

1
2 510367 8792902 2 ASSY, OSLEC TOWER BOX - PLT No Model Compatibility List $507.81 / Each

1
2 510368 8795402 2 WLDMT, OSLEC, WORKARM - PLT No Model Compatibility List $236.35 / Each

3
1 510369 8795801 1 WLDMT, OSLEC, TIBIA No Model Compatibility List $108.07 / Each

1
4 510370 8796701 4 Cam, OSLEC No Model Compatibility List $121.32 / Each

1
2 510371 8796802 2 Assembly, OSLECTWR, Sub - Plate No Model Compatibility List $507.45 / Each

1
1 510372 8796902 1 WLDMT, OSLEC TOWER - PLT No Model Compatibility List $453.88 / Each

1
2 510434 8811702 2 ASSY, OSLEC, MAIN FRAME - PLT No Model Compatibility List $643.43 / Each

3
1 510458 8818502 1 ASSY, OSLEC, BACK FRAME - PLT No Model Compatibility List $222.41 / Each

3,4,5,6
3 510461 8820199 3 Pad, Seat, Flat Custom No Model Compatibility List $0.00 / Each
Out Of Stock 		12,13,14
4 510517 8829101 4 Shroud Kit, OSTWR, Standard No Model Compatibility List $425.90 / Each

12,13,14
1 510553 8837801 1 SPRING, OSLEC, TORSION No Model Compatibility List $34.16 / Each

2
1 510565 8839302 1 WLDMT, OSLEC, SEAT FRAME - PLT No Model Compatibility List $325.60 / Each

3,12,13,14
7 510566 8839402 7 ASSY, OSLEC, SEAT FRAME - PLT No Model Compatibility List $323.32 / Each

3,12,13,14
1 510567 8839602 1 WLDMT, OSLEC, BACK FRAME - PLT No Model Compatibility List $174.31 / Each

3,4,5,6
1 510568 8839902 1 BRKT, OSLEC, BACK FRAME - PLT No Model Compatibility List $38.35 / Each

3,4,5,6
1 510569 8840002 1 WLDMT, OSLEC, MAIN FRAME - PLT No Model Compatibility List $567.66 / Each

3
1 510575 8842602 1 WLDMT, OSLEC, TOP X-MEM - PLT No Model Compatibility List $94.12 / Each

1
3 510576 8842902 3 ASSY, OSLEC, FRAME BOX - PLT No Model Compatibility List $0.00 / Each
Out Of Stock 		3
2 510577 8843201 2 Stop, OSLEC, Workarm No Model Compatibility List $13.94 / Each

3
4 510629 8860901 4 ASSY, OSLEC, LE TIBIA No Model Compatibility List $232.61 / Each

1
1 510630 8861001 1 WLDMT, OSLEC, LE TIBIA No Model Compatibility List $166.63 / Each

1
2 510653 8868401 2 LABEL, OSLEC, ADJUSTMENT No Model Compatibility List $1.57 / Each

1
1 510654 8868501 1 ASSY, OSLEC, ADJ PLATE No Model Compatibility List $33.47 / Each

1
8 511229 9179101 8 CAM FOLLOWER, 1.25 No Model Compatibility List $99.00 / Each

1
5 517135 LEA3239102 5 Hardware: Screw No Model Compatibility List $1.52 / Each

2
3 517136 LEA3242002 3 Hardware: Hex Nut 10MM D No Model Compatibility List $1.57 / Each

2
7 517145 LEA3251702 7 Screw; M10 X1.5 25MM No Model Compatibility List $3.20 / Each

2
9 20000181 7351501 9 1 SPRING; PULL PIN LARGE No Model Compatibility List $3.22 / Each

14
