LIFE Styler - 5.0 MPH

Exploded Diagrams

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry used@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Motors
  • Seats
  • Posts
  • Pins
  • Belt Related
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
100691 102620 100691 39 #12 X 1.25" SCREW No Model Compatibility List $1.32 / Each

2
101630 100126 101630 10 5/16" STAR WASHER No Model Compatibility List $0.16 / Each

2
101897 101675 101897 . WHITE JUMPER WIRE 14" No Model Compatibility List $7.19 / Each

4,5,6
101676 101898 . BLACK JUMPER WIRE 14" No Model Compatibility List $4.07 / Each

4,5,6
102634 100111 102634 . 8" GRN WIRE F/R, POWER No Model Compatibility List $4.75 / Each

4,5,6
102955 104351 102955 64 INCLINE SENSOR SWITCH No Model Compatibility List $16.73 / Each

4,5,6,10
102959 104355 102959 65 SMALL BOLT No Model Compatibility List $1.28 / Each

2
101456 103823 . 14" WHITE WIRE, M/F No Model Compatibility List $4.22 / Each

4,5,6
118656 104581 8 3/8" X 1" SCREW No Model Compatibility List $0.88 / Each

2
124508 104624 36 SHAFT BOLT No Model Compatibility List $1.36 / Each

2
104925 3/8 118371 104925 3/8" -16 X 4.5" 17 MOTOR PIVOT BOLT No Model Compatibility List $5.91 / Each

2,8
104208 105477 . MOTOR NUT No Model Compatibility List $0.31 / Each

2
106337 124506 106337 4 SAFETY KEY/CLIP Yes Model Compatibility List $6.56 / Each

2,9
124865 107120 . OWNERS MANUAL * No Model Compatibility List $5.00 / Each

1
123759 108080 6 SCREW No Model Compatibility List $0.26 / Each

2
124504 109383 26 CIRCUIT BREAKER No Model Compatibility List $24.42 / Each

4,5,6
119946 124433 119946 . PULSE/CLOTHES CLIP Yes Model Compatibility List $79.20 / Each

2,12,13,14
012082 101287 012082 11 5/16" NYLON LOCK NUT Yes Model Compatibility List $0.22 / Each

2
101294 012108 29 3/8" NYLON LOCKNUT No Model Compatibility List $0.33 / Each

2
125819 101014 125819 7 LARGE STANDOFF Yes Model Compatibility List $0.34 / Each

2
013162 101030 013162 55 M4 X 13MM SCREW Yes Model Compatibility List $1.26 / Each

2
013206 100358 013206 49 REAR ROLLER BOLT 1/4"-20X3" Yes Model Compatibility List $4.51 / Each

2,8
121927 013275 31 FRAME PIVOT BOLT No Model Compatibility List $0.40 / Each

2,8,3
013300 100149 013300 41 #8 X 3/4" WASHER HD SCREW Yes Model Compatibility List $1.28 / Each

2
013423 100258 013423 35 1/2" TAP SCREW No Model Compatibility List $1.24 / Each

2
118932 013445 15 MOTOR BOLT No Model Compatibility List $0.41 / Each

2
137290 118667 137290 . WHEEL SPACER Yes Model Compatibility List $1.88 / Each

2,3,4,5,6,8
102276 014041 22 IDLER ARM WASHER No Model Compatibility List $0.12 / Each

2,8,3
111703 014087 18 UPRT MOUNTING WASHER No Model Compatibility List $0.43 / Each

2
014127 104040 014127 32 1/4" WASHER No Model Compatibility List $1.20 / Each

2,3
014157 100141 014157 34 #8 STAR WASHER Yes Model Compatibility List $1.17 / Each

2
016028 118356 016028 . ADHESIVE CLIP No Model Compatibility List $2.23 / Each

2
110964 016055 23 WIRE CLIP,FAN No Model Compatibility List $1.44 / Each

2,8,4,5,6
185582 104353 185582 38 CHOKE Yes Model Compatibility List $76.47 / Each

1
219168 100095 219168 . 1 TUBE LUBE KIT No Model Compatibility List $6.81 / Each

1,3,15
219170 100096 219170 # 3 TUBE LUBE KIT No Model Compatibility List $30.38 / Each

1,3,15
102842 045010 . 3/16" HEX KEY No Model Compatibility List $0.85 / Each

9
031229a KV5-DWY-57F 031229a 031229 Power Cord Yes Model Compatibility List $32.99 / Each

5,6
019084 1015857 019084 # 2 Power Power Cord Entry Strain Relief Grommet (Incline) Yes Model Compatibility List $3.29 / Each

4,6
171905 1015858 171905 # 1 Wireless Pulse Heart Rate Receiver Board + Wire (Used) Yes Model Compatibility List $49.50 / Each

7
124669 1000884 124669 # 1 Hardwired Power Cord (Used Yes Model Compatibility List $16.49 / Each

6
070084 1018987 070084 0 1 Rear Roller (Used Only) Yes Model Compatibility List $86.90 / Each

8
View Drawing
