Matrix Commercial - G3-FW40P - 2008

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry used@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
000514-C 700145 000514-C B07 Foot pad;Tube;Rubber;GM07 No Model Compatibility List $2.80 / Each

9,3,12,13,14
001422-BA 700461 001422-BA B08 End Cover;Ellipse;40x80x3.0t;MS20 No Model Compatibility List $2.80 / Each

9
004780-00 701758 004780-00 Z05 Screw;Hex Socket;BH;M10x1.5Px25L;Adhere No Model Compatibility List $1.54 / Each

2
004943-00 701914 004943-00 Z18 Nut;Nylon;M10x1.5P;Cr Plate; No Model Compatibility List $1.54 / Each

2,3
005007-00 701968 005007-00 B15 Washer;Spring;12.2x21.5x3.0t No Model Compatibility List $1.54 / Each

2
005130-00 702098 005130-00 C19 Washer;Flat;8.4x15.5x1.6T;Chromed No Model Compatibility List $1.54 / Each

7,2,12,13,14
005132-00 702102 005132-00 B16 Washer;Flat;13x26x2.5T;Chromed No Model Compatibility List $1.38 / Each

7,2,12,13,14
005990-E 702318 005990-E V04 Decal;Matrix Logo No Model Compatibility List $14.44 / Each

7,3
006663-A 702414 006663-A V01 Decal;Seat Pad Adjustable;GM07 No Model Compatibility List $2.58 / Each

7,3,12,13,14
008234-C 702505 008234-C C17 Bushing;Fixed Plate No Model Compatibility List $7.00 / Each

8,3
018876-C 703872 018876-C B09 Plastic Pad;FW40 No Model Compatibility List $7.00 / Each

9,12,13,14
019153-A 703902 019153-A C13 Pull pin knob; Yellow No Model Compatibility List $5.22 / Each

12,13,14
020126-DB 704039 020126-DB C11 Screw;Seat Stopper;M8x1.25Px20L No Model Compatibility List $1.38 / Each

2,12,13,14
020304-AC 704137 020304-AC Z06 Screw;Hex Socket;M10X1.5PX35L;Cr Plate No Model Compatibility List $1.54 / Each

2,3
020465-AB 704193 020465-AB Z07 Washer;Flat;M10.2X25PX2.0T;Chromed No Model Compatibility List $1.38 / Each

7,2,12,13,14
020489-A 704217 020489-A Z22 Washer;Arc;10.2x20.0x1.5t;Chromed No Model Compatibility List $1.54 / Each

7,2,12,13,14
020699-A 704232 020699-A V03 Rivet;1/8X12.5L No Model Compatibility List $1.38 / Each

1
022377-B 704304 022377-B B10 Stopper Mast;S45C;FW40 No Model Compatibility List $23.16 / Each

1
1000090006 707066 1000090006 C16 End Cover;Seat Tube Sleeve No Model Compatibility List $2.80 / Each

9,3,12,13,14
1000090177 707084 1000090177 C13 Pull Pin Handle;Orange;TPP;137C;MS10 No Model Compatibility List $7.00 / Each

12,13,14,11
1000097266 707975 1000097266 C40 Sleeve;Seat Tube No Model Compatibility List $9.44 / Each

3,12,13,14
708071 1000098871 C09 Pull Pin Set;Seat;Orange Knob No Model Compatibility List $31.26 / Each

12,13,14
1000099499 708091 1000099499 C18 Screw;SH;M8X1.25PX14L;;HS;;CHM;;SP No Model Compatibility List $1.28 / Each

2
1000102864 708448 1000102864 Z09 Screw;Hex Socket;Round;M10x1.5Px60L;Cr P No Model Compatibility List $6.26 / Each

2
1000102869 708453 1000102869 B14 Screw;Hex Socket;Round;M12x1.75Px25L;Cr No Model Compatibility List $2.64 / Each

2
708470 1000102888 B11 Screw;Hex Socket;Countersunk;M8x1.25Px35 No Model Compatibility List $1.28 / Each

2
1000102893 708473 1000102893 B12 Screw;Hex Socket;Flat;M8x1.25Px20L;Cr Pl No Model Compatibility List $1.06 / Each

2
1000104684 708657 1000104684 B13 RVN;Pattern;YZN;ALS7-8125-3.8(0.5-3.8) No Model Compatibility List $2.58 / Each

1
1000233349 713160 1000233349 B09 Plastic Pad;;;PU;Black;320x40x19;FW40; No Model Compatibility List $49.38 / Each

9,4,5,6,12,13,14
718129 1000349336 AB1 Frame Set;;;painting;;Iced Sliver;FW40KM No Model Compatibility List $0.00 / Each
Out Of Stock
3
718130 1000349337 AC1 base set;;;painting;;Iced Sliver;FW40KM- No Model Compatibility List $0.00 / Each
Out Of Stock
3
718131 1000349338 AD1 Support Rack Set;;;painting;;Iced Sliver No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
718132 1000349339 AJ1 Adjustable Set;Seat;;painting;;Iced Sliv No Model Compatibility List $0.00 / Each
Out Of Stock
12,13,14
726607 083458 Z62 Washer;Lock;8.2x13.5x2.0t No Model Compatibility List $1.54 / Each

2
726987 086517 H65 Screw;Round Hex Socket;M10x1.5Px25L No Model Compatibility List $2.80 / Each

2
095242 728543 095242 Not Shown Hardware Kit;#;Semi-Assy;FW40KM-G3 No Model Compatibility List $7.78 / Each

1
729261 See Pad Matrix E02 Elbow Pad;;PU;Black;;FW213-KM; No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6,12,13,14
View Drawing
