Matrix Commercial - G3-FW52-03 - 2013

Repair Parts for Matrix Commercial G3-FW52-03 G3FW52

Brand: Matrix Commercial

Category: Freeweight

Type: Strength Systems

Model Name: G3-FW52-03

Version: 2013

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Motors
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
B 700145 000514-C B22 Foot pad;Tube;Rubber;GM07 No Model Compatibility List $3.64 / Each

9,3,12,13,14
B 700146 000515-A B23 Foot pad;Rubber;100;FW10 No Model Compatibility List $9.10 / Each

9,3,12,13,14
B 700155 000528-BA B21 Foot pad;Rubber;BL;MS53 No Model Compatibility List $39.42 / Each

9,3,12,13,14
D 700177 000586-F D04 Foam Grip;25.4x5.0x75L No Model Compatibility List $3.35 / Each

11
D 700223 000727-B D04 Foam Grip;24x5.0tx90L No Model Compatibility List $4.06 / Each

11
Q 700448 001402-A Q01 End Cap;Round No Model Compatibility List $1.79 / Each

9
Q 700461 001422-BA Q02 End Cover;Ellipse;40x80x3.0t;MS20 No Model Compatibility List $3.64 / Each

9
Z 701449 004493-00 Z02 Screw;Hex Socket;Round;M8x1.25Px16L No Model Compatibility List $1.79 / Each

2
D 701610 004629-00 D09 SCREW;BH;5X18L;SM;PH;;BZN;;POT No Model Compatibility List $1.66 / Each

2
B 701654 004693-AD B24 Screw;Flat Hex Socket;M8x1.25Px15L No Model Compatibility List $1.66 / Each

2
B 701657 004694-AC B25 Screw;Hex Socket;Flat;M8x1.25Px10L No Model Compatibility List $1.66 / Each

2
Z 701758 004780-00 Z05 Screw;Hex Socket;BH;M10x1.5Px25L;Adhere No Model Compatibility List $2.00 / Each

2
701764 004786-00 Z05 Screw;Hex Socket;BH;CrMo;M10x1.5Px25L No Model Compatibility List $3.64 / Each

2
I 701836 004855-AC I07 Set Screw;M6X1.0PX4L No Model Compatibility List $1.79 / Each

2
Z 701981 005017-00 Z07 Washer;Spring;SW10 10.2X18.4X2.5T;Chromed No Model Compatibility List $1.33 / Each

7,2,12,13,14
C 702056 005084-00 C95 Washer;Flat;5.3X10.0X1.0T;Chromed No Model Compatibility List $2.00 / Each

7,2,12,13,14
B 702098 005130-00 B29 Washer;Flat;8.4x15.5x1.6T;Chromed No Model Compatibility List $2.00 / Each

7,2,12,13,14
C 702217 005330-00 C92 Tinnamen Nut Yes Model Compatibility List $1.59 / Each

2
V 702318 005990-E V06 Decal;Matrix Logo No Model Compatibility List $18.77 / Each

7,3
V 702411 006656-A V01 Decal;Serial Number;Aluminum No Model Compatibility List $1.66 / Each

7,3
B 702505 008234-C B27 Bushing;Fixed Plate No Model Compatibility List $9.10 / Each

8,3
I 702711 009356-B I08 Stopper Mast;Foam;AL6061;GM03 No Model Compatibility List $3.64 / Each

1
I 702721 009371-E I06 Cap;Grip;GM03 No Model Compatibility List $15.34 / Each

9,11
I 703879 018940-A I05 Foam;Grip;24X5.0tx150L No Model Compatibility List $8.42 / Each

11
D 703899 019121-C D08 End Cap;Adjustable Tube No Model Compatibility List $3.64 / Each

9,3
B 704041 020127-A B28 Screw;Hex Socket;Round;M8X1.25PX12L No Model Compatibility List $1.79 / Each

2
C 704074 020186-00 C97 Screw;Phillip;BH;Tapped;4x30L; No Model Compatibility List $1.79 / Each

2
Z 704193 020465-AB Z08 Washer;Flat;M10.2X25PX2.0T;Chromed No Model Compatibility List $1.79 / Each

7,2,12,13,14
D 704199 020473-A D10 Washer;Flat;5.0X10.0X2.0T No Model Compatibility List $1.66 / Each

2
V 704232 020699-A V02 Rivet;1/8X12.5L No Model Compatibility List $1.79 / Each

1
V 704254 021614-A V05 Decal;Adjustic;With Glue;FW52 No Model Compatibility List $9.10 / Each

7,3
A 704414 024077-ZKM AI1 HANDLEBAR SET, G3FW52 No Model Compatibility List $441.79 / Each

11
704847 025569-AA AB1 Frame Set;Painting;FW52 No Model Compatibility List $1.30 / Each

3
Z 705462 049253-AA Z04 Screw;SH;M6X1.0PX10L;;HS;;ZN;; No Model Compatibility List $1.66 / Each

2
D 705485 049287-00 D13 Washer;Flat;12.5x20.0x2.0t; No Model Compatibility List $2.00 / Each

2
C 705701 055205-AB C100 Washer;Flat;12.5X20.0X1.0T;Chromed No Model Compatibility List $1.79 / Each

7,2,12,13,14
Q 706986 067941-C Q03 Cap;25x50x3.0T;GM20 No Model Compatibility List $1.79 / Each

9
B 707066 1000090006 B26 End Cover;Seat Tube Sleeve No Model Compatibility List $3.64 / Each

9,3,12,13,14
B 707976 1000097267 B35 Sleeve;Seat Tube No Model Compatibility List $9.10 / Each

3,12,13,14
708072 1000098872 B34 Pull Pin Set;Seat;Orange Knob No Model Compatibility List $36.48 / Each

12,13,14
C 708484 1000102910 C94 Circlip;External C Type;S-12;BED No Model Compatibility List $1.33 / Each

2
B 708815 1000106129 B34 Adjustment Pin Assembly;Seat;Yellow Knob No Model Compatibility List $54.73 / Each

3,12,13,14
D 709227 1000111351 D29 Handle;Adj;Grip;GM41-KM No Model Compatibility List $4.71 / Each

11
C 709531 1000201046 C66 Washer;FLT;4.3X8X0.8T;SPHC;CHM;NA; No Model Compatibility List $1.79 / Each

2
C 709532 1000201047 C65 Screw;BH;M4X0.7PX10L;MT;NL;HS;G8.8;CHM; No Model Compatibility List $1.79 / Each

2
B 709734 1000202489 B05 Plastic Cover;ABS;BL;GM02C No Model Compatibility List $6.81 / Each

9
J 709735 1000202490 J10 Stopper Piece;Chair;-;45;CHM;GM02C; No Model Compatibility List $46.10 / Each

1
J 709736 1000202491 J12 Spring;RCL;2.0X13;40MN;CHM; No Model Compatibility List $2.65 / Each

2
J 709737 1000202492 J13 Spring;RCL;2.0X13;40MN;CHM; No Model Compatibility List $2.65 / Each

2
V 710093 1000206765 V05 Spec Label;Seat Adjustment;PC;-;FW52C- No Model Compatibility List $18.56 / Each

12,13,14
D 710112 1000206799 D40 Axle, SWIVEL;20;NICKEL PLATING;ADJUSTABL No Model Compatibility List $20.05 / Each

8
J 710422 1000210194 J01 BACK PAD;-;PU;BLACK;-; No Model Compatibility List $56.55 / Each

4,5,6,12,13,14
710433 1000210215 J01 BACK PAD;-;PU;NO LEATHER;-; No Model Compatibility List $208.47 / Each

4,5,6,12,13,14
J 710434 1000210264 J01 BACK PAD;-;PU;RED;-; No Model Compatibility List $103.06 / Each

4,5,6,12,13,14
J 710440 1000210284 J01 BACK PAD;-;PU;MIST BLUE;-; No Model Compatibility List $103.06 / Each

4,5,6,12,13,14
J 710447 1000210304 J01 BACK PAD;-;PU;CLAY RED;-; No Model Compatibility List $111.31 / Each

4,5,6,12,13,14
C 711692 1000222320 C96 Screw;SH;M5x25L;-;HS;-;CHM;BP;-; No Model Compatibility List $1.66 / Each

2
D 714856 1000318730 D05 Stopper Block;Stopper;;45#;;FW52C;; No Model Compatibility List $8.42 / Each

1
D 714858 1000318732 D06 Support Base;;;POM;;;FW52C; No Model Compatibility List $11.80 / Each

3
D 714859 1000318734 D07 Bushing1;Adjustable;;45#;Chrome;FW52C; No Model Compatibility List $129.56 / Each

7,8,12,13,14
N 715559 1000326139 Not Shown Manual set;Semi-Assy;;;English;FW52D-KM; No Model Compatibility List $10.11 / Each

1
V 716097 1000332444 V07 EN LABEL;;;;;;;FW52D-KM No Model Compatibility List $1.66 / Each

1
2 716191 1000334459 2 Adjustment Tube Set;;;;FW52D-KM;; No Model Compatibility List $550.91 / Each

3
1 717986 1000349141 1 Handle Set;;;Iced Sliver;FW52D;;Service No Model Compatibility List $202.77 / Each

11
718150 1000349379 AB1 base set;;;painting;;Iced Sliver;FW52D;S No Model Compatibility List $919.33 / Each

3
723242 1000405697 D10 Pull Pin Base;Non-adjustable;M16(22mm);; No Model Compatibility List $11.80 / Each

3,12,13,14
Round Pad;200;Black;GM01 725999 079186 D20 Round Pad;200;Black;GM01 No Model Compatibility List $54.05 / Each

4,5,6,12,13,14
Adjustable Tube Set 726788 084827 AD1 Adjustable Tube Set No Model Compatibility List $319.51 / Each

3
Round Pad;American Beauty Red;200;GM01 726903 085965 B20 Round Pad;American Beauty Red;200;GM01 No Model Compatibility List $58.40 / Each

12,13,14
Assembly Manual;English;MX-H5X-F 727264 088184 Not Shown Assembly Manual;English;MX-H5X-F No Model Compatibility List $20.28 / Each

3
Round Pad;Slate Blue;200;GM01KM 727265 088185 B20 Round Pad;Slate Blue;200;GM01KM No Model Compatibility List $57.43 / Each

12,13,14
727486 089564 not shown Manual;Assembly;FW52 No Model Compatibility List $15.42 / Each

3
Hardware;Semi-Assy;FW52KM-G3 727487 089567 Not Shown Hardware;Semi-Assy;FW52KM-G3 No Model Compatibility List $40.46 / Each

1
Stopper BlockRubber;GM30 727687 090440 H08 Stopper BlockRubber;GM30 No Model Compatibility List $2.73 / Each

1
Round Pad;LA Slate Gray;200 #GM01KM-G3 728030 092769 B20 Round Pad;LA Slate Gray;200 #GM01KM-G3 No Model Compatibility List $114.89 / Each

12,13,14
728038 092795 J01 Back Pad;LA Slate Gray;FW52KM-G3 No Model Compatibility List $211.22 / Each

4,5,6,12,13,14
728911 098853 B20 Round Pad;No Leather;GM01KM-G3 No Model Compatibility List $97.24 / Each

12,13,14
729012 Order Kit 1 AI1 Console Base Set;Semi-Assy;;;;TM701-1US; No Model Compatibility List $0.00 / Each
Out Of Stock 		7,3
729024 Order Kit 2 AD3 Motor set;Semi-Assy;;;;TM701-1US;;Servic No Model Compatibility List $0.00 / Each
Out Of Stock 		10
729261 See Pad Matrix J01 Elbow Pad;;PU;Black;;FW213-KM; No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6,12,13,14
