Matrix Commercial - G3-FW96P - 2008

Repair Parts for Matrix Commercial G3-FW96P G3FW96

Brand: Matrix Commercial

Category: Benches/Racks

Type: Strength Systems

Model Name: G3-FW96P

Version: 2008

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Circuit Boards
  • Plastic Parts
  • Motors
  • Seats
  • Posts
  • Pins
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
B 700166 000554-A B10 Foot pad;Rubber No Model Compatibility List $14.46 / Each

9,3,12,13,14
Z 701466 004518-AB Z03 ROUND HEX SOCKET SCREW M10X1.5PX75L No Model Compatibility List $8.42 / Each

2
B 701653 004693-AC B15 Screw;Hex Socket;M8x1.25Px15L;Cr No Model Compatibility List $2.44 / Each

2
Z 701914 004943-00 Z02 Nut;Nylon;M10x1.5P;Cr Plate; No Model Compatibility List $2.00 / Each

2,3
V 702318 005990-E V05 Decal;Matrix Logo No Model Compatibility List $18.77 / Each

7,3
Z 702531 008523-B Z11 Washer;Arc;M10x28x10.5T;SS41 No Model Compatibility List $9.10 / Each

2
Z 704193 020465-AB Z01 Washer;Flat;M10.2X25PX2.0T;Chromed No Model Compatibility List $1.79 / Each

7,2,12,13,14
N 706652 064176-A Not shown hardware set;;2;;FW96;; No Model Compatibility List $33.77 / Each

1
B 708657 1000104684 B13 RVN;Pattern;YZN;ALS7-8125-3.8(0.5-3.8) No Model Compatibility List $3.35 / Each

1
B 712032 1000225334 B11 Hanging Rod;45#;Cr Plate;FW96 No Model Compatibility List $29.30 / Each

3
B 712129 1000226827 B12 Elastomer;Plastic;; No Model Compatibility List $43.71 / Each

9
717975 1000349130 1 Frame set;;left;Iced Sliver;FW96KM-G3;;S No Model Compatibility List $0.00 / Each
Out Of Stock 		3
717976 1000349131 2 Frame set;;Right;iced sliver;fw96km-g3 No Model Compatibility List $0.00 / Each
Out Of Stock 		3
718143 1000349364 AG4 CON Tube Set;;U;painting;;Iced Sliver;FW No Model Compatibility List $0.00 / Each
Out Of Stock 		3
718144 1000349365 AG1 CON Tube Set;;D;painting;;Iced Sliver;FW No Model Compatibility List $0.00 / Each
Out Of Stock 		3
Screw, Flat Hex Socket, M8x1.25Px8L 725312 069801 C29 Screw, Flat Hex Socket, M8x1.25Px8L No Model Compatibility List $1.79 / Each

2
B 728949 991668-AC B14 Screw;FH;M8X1.25PX30L;;HS;;CHM;; No Model Compatibility List $3.64 / Each

2
729012 Order Kit 1 AB1 Console Base Set;Semi-Assy;;;;TM701-1US; No Model Compatibility List $0.00 / Each
Out Of Stock 		7,3
729024 Order Kit 2 AB2 Motor set;Semi-Assy;;;;TM701-1US;;Servic No Model Compatibility List $0.00 / Each
Out Of Stock 		10
View Drawing
