Matrix Commercial - G3-MS51-02 - 2018

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry used@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
000508-D 700139 000508-D B20 Foot Pad;Rubber;60mm No Model Compatibility List $3.96 / Each

9,3,12,13,14
000510-D 700141 000510-D B19 Foot Pad;Rubber;76.2mm No Model Compatibility List $4.38 / Each

9,3,12,13,14
000755-CA 700236 000755-CA L04 Elastomer;Incremental Weight Plate No Model Compatibility List $3.04 / Each

3
000791-B 700256 000791-B B18 Water Bottle Holder No Model Compatibility List $10.36 / Each

1
001402-A 700448 001402-A T12 End Cap;Round No Model Compatibility List $1.38 / Each

9
001513-A 700497 001513-A Z16 Rubber Block;Shock Absorb No Model Compatibility List $6.58 / Each

1
001523-E 700519 001523-E T13 Rubber Stop;CAM No Model Compatibility List $2.80 / Each

1
004482-AB 701436 004482-AB T31 Screw;Hex Socket;Round;M8x1.25Px20L;Cr No Model Compatibility List $1.54 / Each

2
004519-AE 701470 004519-AE Z08 Screw;Round;Hex Socket;M10x1.5Px80L No Model Compatibility List $3.80 / Each

2
004535-AC 701496 004535-AC Z01 Screw;Hex Socket;Round;M8x1.25Px30L No Model Compatibility List $2.80 / Each

2
004555-AB 701522 004555-AB Z17 Screw;Hex Socket;Round;M10x1.5Px25L;Cr;A No Model Compatibility List $3.08 / Each

2
004556-AB 701524 004556-AB Z10 Screw;Hex Socket;Round;M12x1.75Px25L;Cr; No Model Compatibility List $1.38 / Each

2
004557-A 701525 004557-A Z13 SCREW;SH;M6X1.0PX45L;;HS;;CHM;; No Model Compatibility List $1.28 / Each

2
004720-AC 701693 004720-AC K17 Screw;Hex Socket;Umbrella;M8x1.25Px20L; No Model Compatibility List $3.08 / Each

2
004938-00 701911 004938-00 Z14 Nut;Nylon;M6X1.0P;Chromed No Model Compatibility List $1.54 / Each

7,2,12,13,14
004943-00 701914 004943-00 Z07 Nut;Nylon;M10x1.5P;Cr Plate; No Model Compatibility List $1.54 / Each

2,3
005007-00 701968 005007-00 Z12 Washer;Spring;12.2x21.5x3.0t No Model Compatibility List $1.54 / Each

2
005040-00 702000 005040-00 K18 Washer;Flat;Diam.8.5xDiam.19.0x1.5T;;Bla No Model Compatibility List $1.42 / Each

2
005132-00 702102 005132-00 Z11 Washer;Flat;13x26x2.5T;Chromed No Model Compatibility List $1.38 / Each

7,2,12,13,14
005847-A 702308 005847-A K25 Lanyard;Weight Selection Pin No Model Compatibility List $15.42 / Each

3,12,13,14
006610-B 702382 006610-B V07 Decal;Foot Pad Adjustable;GM01 No Model Compatibility List $2.58 / Each

7,9,3,12,13,14
006611-E 702383 006611-E V03 Decal;Weight Plate;15LBS (Contains decals up to 295lbs) No Model Compatibility List $21.22 / Each

7,3
006652-C 702409 006652-C V05 Decal;Incremental Weight Plate No Model Compatibility List $3.12 / Each

7,3
006653-C 702410 006653-C V06 Decal;Weight Plate No Model Compatibility List $1.02 / Each

7,3
006656-A 702411 006656-A V12 Decal;Serial Number;Aluminum No Model Compatibility List $1.28 / Each

7,3
008523-B 702531 008523-B Z18 Washer;Arc;M10x28x10.5T;SS41 No Model Compatibility List $7.00 / Each

2
008546-F 702536 008546-F T10 Leveler Adjustable Cover No Model Compatibility List $71.60 / Each

9,3
009247-A 702654 009247-A F07 Axle;Swivel;;S45C;10x25L No Model Compatibility List $2.20 / Each

8
009289-F 702671 009289-F H07 Adjustable Axle;Back Pad ;GM03 No Model Compatibility List $2.80 / Each

8,4,5,6,12,13,14
015840-A 703709 015840-A AT2 Grip Fix Set;R;Painting;MS53 No Model Compatibility List $80.10 / Each

11
015943-AA 703738 015943-AA K06 Weight Plate Set;15 Lbs;Dry Bearing No Model Compatibility List $51.98 / Each

8,3
020304-AC 704137 020304-AC Z15 Screw;Hex Socket;M10X1.5PX35L;Cr Plate No Model Compatibility List $1.54 / Each

2,3
020465-AB 704193 020465-AB Z05 Washer;Flat;M10.2X25PX2.0T;Chromed No Model Compatibility List $1.38 / Each

7,2,12,13,14
020699-A 704232 020699-A V10 Rivet;1/8X12.5L No Model Compatibility List $1.38 / Each

1
1000098481 708045 1000098481 L02 Weight Plate, Incremental No Model Compatibility List $73.62 / Each

3
1000098483 708046 1000098483 L03 Extrawork;Incremental Weight Plate Hook; No Model Compatibility List $27.32 / Each

3
1000102867 708451 1000102867 Z04 Screw;Hex Socket;Round;M10x1.5Px100L;Cr No Model Compatibility List $9.96 / Each

2
1000102893 708473 1000102893 B33 Screw;Hex Socket;Flat;M8x1.25Px20L;Cr Pl No Model Compatibility List $1.06 / Each

2
1000104705 708675 1000104705 K19 Screw;RND;M6x1.0Px15L;HS;CHM;BP;G8.8 No Model Compatibility List $0.40 / Each

2
1000104720 708684 1000104720 F22 Screw;HH;M10x1.5Px45L;P-T15L;CHM;BP;G8.8 No Model Compatibility List $1.68 / Each

2
1000109127 709081 1000109127 V22 Decal;Pinch Point ;MS21KM-G3 No Model Compatibility List $1.36 / Each

7,3,12,13,14
1000210205 710428 1000210205 J02 BACK PAD;-;PU;BLACK;-; No Model Compatibility List $82.82 / Each

4,5,6,12,13,14
710566 1000210974 K09 Guide Rail;19x2180L No Model Compatibility List $207.72 / Each

9
1000301744 713338 1000301744 F08 Steel Rope-Extrawork;-;-;Press Rope Hand No Model Compatibility List $98.26 / Each

1
1000318313 714798 1000318313 AK1 Up Weight Plate Set-Exreawork;;;;;MS51; No Model Compatibility List $175.48 / Each

3
1000345425 717480 1000345425 K28 Stopper Ring;Guide Rod;;;Chrome;GM41;; No Model Compatibility List $14.02 / Each

7,3,12,13,14
1000349225 718051 1000349225 AH11 Foot Adjustable Set;;;Iced Sliver;GM01KM No Model Compatibility List $155.98 / Each

9,3
719338 1000359953 V25 Warning Label;Anti Falling Down;MS24B;;; No Model Compatibility List $0.00 / Each
Out Of Stock
1
1000363588 719669 1000363588 AB5 Stopper set;Guide Rod;;painting;;;MS20; No Model Compatibility List $27.28 / Each

3
719682 1000363760 V23 Warning Label;Frame;;;PC;;English; No Model Compatibility List $0.00 / Each
Out Of Stock
3
720311 1000371356 V27 Series no. Label;;;;PETP;;; No Model Compatibility List $0.00 / Each
Out Of Stock
1
1000372591 720426 1000372591 K10 Adjustable Pin;Weight Plate;;42CrMo;Chro No Model Compatibility List $42.10 / Each

7,3,12,13,14
1000375536 720727 1000375536 AF11 STEEL ROPE PULLEY SET;;;Iced Sliver;;;MS No Model Compatibility List $67.58 / Each

8
1000375594 720732 1000375594 N12 Pulley Set;Steel Cable;;;;Iced Sliver;MS No Model Compatibility List $5.18 / Each

8,4,5,6
1000380094 721052 1000380094 N17 Karabiner Spring Snap;;9(45mmx90mm);Sta No Model Compatibility List $19.16 / Each

2
721145 1000380986 V21 Instructional Labe;;;;PC;;English;MS51 No Model Compatibility List $11.68 / Each

1
722986 1000402110 V36 Warning Label;;40x40;;PC;;;COUNTER WEIGH No Model Compatibility List $2.32 / Each

1
723730 1000412388 Not Shown Hardware Set;Semi-Assy;;;;;MS51B; No Model Compatibility List $0.00 / Each
Out Of Stock
1
724295 1000417314 Not Shown Manual;;;English;;MS51B No Model Compatibility List $0.00 / Each
Out Of Stock
1
724320 1000418028 AT1 Seat Set;;;painting;;Iced Sliver;MS51B; No Model Compatibility List $0.00 / Each
Out Of Stock
12,13,14
724392 1000418961 AB11 Frame Set;Semi-Assy;;Iced Sliver;;;MS51B No Model Compatibility List $0.00 / Each
Out Of Stock
3
1000419004 724402 1000419004 AE11 Handle set;Semi-Assy;;;assembly;;MS51B; No Model Compatibility List $150.78 / Each

3,11
1000419026 724404 1000419026 AN1 Lower Pull Set;;;painting;;Iced Sliver;M No Model Compatibility List $252.18 / Each

1
073573 725584 073573 F21 Pulley; 115mm No Model Compatibility List $32.44 / Each

8
087955 727227 087955 B41 Screw;BH;M6X1.0PX10L;;HS;;CHM;;BP No Model Compatibility List $0.88 / Each

2
089983 727568 089983 F04 Grip;MS21KM-G3; No Model Compatibility List $37.40 / Each

11
729261 See Pad Matrix J01 Elbow Pad;;PU;Black;;FW213-KM; No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6,12,13,14
View Drawing
