Matrix Commercial - MG-A84-03 - 2014

Repair Parts for Matrix Commercial MG-A84-03 FW227

Brand: Matrix Commercial

Category: Freeweight

Type: Strength Systems

Model Number:

Info

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

FW227

Model Name: MG-A84-03

Version: 2014

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

16510.0-base.pdf

Image	Catalog #	MPN	Part List Key	Quantity On Model	Part Description	Notes	Available Used	Model Compatibility List	New price
	700249	000776-A	G02		Elastomer;E5-09B;FW91		No	Model Compatibility List	$9.52 / Each	1
	700447	001401-A	B05		End Cap;76.2		No	Model Compatibility List	$3.64 / Each	9
	701657	004694-AC	B09		Screw;Hex Socket;Flat;M8x1.25Px10L		No	Model Compatibility List	$1.66 / Each	2
	702102	005132-00	Z03		Washer;Flat;13x26x2.5T;Chromed		No	Model Compatibility List	$1.79 / Each	7,2,12,13,14
	704035	020124-A	Z02		Screw;Hex Socket;Socket Head;M12X1.75PX4		No	Model Compatibility List	$3.35 / Each	2
	704193	020465-AB	G05		Washer;Flat;M10.2X25PX2.0T;Chromed		No	Model Compatibility List	$1.79 / Each	7,2,12,13,14
	706373	061531-AA	B06		Leveler;Foot Pad;FW151		No	Model Compatibility List	$14.56 / Each	9,3,12,13,14
	708730	1000105174	G04		Nut;Nylon;M10x1.5P;G12.9;CHM		No	Model Compatibility List	$1.79 / Each	2
	708743	1000105261	Z01		Nut;Nylon;M12x1.75P;G12.9;CHM		No	Model Compatibility List	$1.38 / Each	2
	713542	1000304977	AG1		Disassembly connect set;;;painting;;Blac		No	Model Compatibility List	$540.77 / Each	3,4,5,6
	713893	1000309326	G03		Screw;Hex Socket;Flat Head;M10X1.5PX40L;		No	Model Compatibility List	$5.04 / Each	2
	715719	1000327837	AB2		Support Set;;R;painting;;Iced Sliver;FW2		No	Model Compatibility List	$197.70 / Each	3
	715720	1000327840	AB2		Support Set;;R;painting;;Lace White;FW22		No	Model Compatibility List	$197.70 / Each	3,4,5,6
	715721	1000327841	AB2		Support Set;;R;painting;;Black Glossy;FW		No	Model Compatibility List	$196.01 / Each	3,4,5,6
	715722	1000327843	AB1		Support Set;;L;painting;;Iced Sliver;FW2		No	Model Compatibility List	$204.46 / Each	3
	715723	1000327846	AB1		Support Set;;L;painting;;Lace White;FW22		No	Model Compatibility List	$204.46 / Each	3,4,5,6
	715724	1000327847	AB1		Support Set;;L;painting;;Black Glossy;FW		No	Model Compatibility List	$204.46 / Each	3,4,5,6

View Drawing
