Matrix Commercial - MG-DP921-02 - N/A

Repair Parts for Matrix Commercial MG-DP921-02 MGTS25,MGTS42

Brand: Matrix Commercial

Category: Multi Station

Type: Strength Systems

Model Name: MG-DP921-02

Version: N/A

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
Z 713814 1000308428 Z28 3/8" NUT No Model Compatibility List $1.43 / Each

2
Z 713818 1000308436 Z15 WASHER;FLT;USS;Diam.0.344XDiam.0.875X.06 No Model Compatibility List $1.43 / Each

2
Z 713819 1000308437 Z21 SCREW;HH;.375-16 x 1.50;ZN; No Model Compatibility List $2.37 / Each

2
Z 713826 1000308444 Z36 WASHER;FLT;USS;Diam.0.406XDiam.1.000X.06 No Model Compatibility List $1.43 / Each

2
Z 713828 1000308446 Z13 WASHER;FLT;USS;Diam.0.281XDiam.0.734X.06 No Model Compatibility List $1.43 / Each

2
713830 1000308448 Z56 5/16" X 1 1/2" BOLT No Model Compatibility List $1.43 / Each

2
V 713842 1000308473 V54 Lable, hand pinch No Model Compatibility List $3.02 / Each

12,13,14
W 713939 1000309846 WS pulley 7 1/2" JAM NUT No Model Compatibility List $1.43 / Each

2
W 713940 1000309847 WS Pulley 8 WASHER, .50 OD X .38 ID X .05 No Model Compatibility List $1.43 / Each

2
713943 1000309851 Z19 SCREW;HH;.375-16 x 2.25;ZN; No Model Compatibility List $2.18 / Each

2
Z 713946 1000309854 Z27 NUT;NLK;.250-20;ZN; No Model Compatibility List $1.43 / Each

2
Z 713950 1000309858 Z31 3/4" FLAT WASHER No Model Compatibility List $1.33 / Each

2
N 713975 1000310008 Not Shown ROUND LEVELER BOOT No Model Compatibility List $5.04 / Each

3
B 713981 1000310014 B38 End Cap No Model Compatibility List $5.90 / Each

9
Z 713991 1000310088 Z25 Washer, Curved, 1/2" No Model Compatibility List $3.02 / Each

2
713996 1000310095 B34 1/2" OD x 1/4" ID Plastic Spacer - 1" No Model Compatibility List $1.33 / Each

2,9,3,4,5,6
713997 1000310096 WS Pulley 12 1/4" SPLIT LOCK WASHER No Model Compatibility List $1.33 / Each

2
713998 1000310097 Z20 SCREW;HH;.250-20 x 2.00;ZN; No Model Compatibility List $1.33 / Each

2
Z 714016 1000310219 Z53 SCREW;HH;.250-20 x 0.75;ZN; No Model Compatibility List $1.33 / Each

2
B 714018 1000310273 B45 4" FOOT (SHORT) No Model Compatibility List $20.05 / Each

9,3
714020 1000310280 Not Shown Flange Center Bushing - (Top Plate) No Model Compatibility List $5.04 / Each

8,3
714026 1000310302 B2 6" CABLE PULLEY w/ NARROW BUSHING No Model Compatibility List $36.48 / Each

8,4,5,6
714038 1000310334 Weight Stack Set 3 6000 TOP PLATE No Model Compatibility List $78.47 / Each

3
B 714040 1000310339 B41 ROUND WEIGHT STACK BUMPER No Model Compatibility List $5.90 / Each

3,4,5,6
714041 1000310343 Weight Stack Set 1 Orange SELECTOR PIN w/ 6 1/2" CORD No Model Compatibility List $25.53 / Each

4,5,6,12,13,14
Z 714094 1000312064 Z24 5/16" x 1" BOLT No Model Compatibility List $1.33 / Each

2
W 714105 1000312091 WS Pulley 5 SCREW;HH;.500-13 x 1.75;ZN; No Model Compatibility List $3.28 / Each

2
714109 1000312099 Z17 HCS 1/2-13 x 4 1/4" No Model Compatibility List $5.04 / Each

1
714126 1000312159 WS Pulley 9 1/2 - 13 NUT No Model Compatibility List $1.33 / Each

2
Z 714127 1000312161 Z26 NUT;NLK;.500-13;ZN;TALL; No Model Compatibility List $1.43 / Each

2
B 714153 1000312233 B39 3" ROUND END CAP No Model Compatibility List $6.73 / Each

9
B 714156 1000312237 B43 3" FOOT No Model Compatibility List $16.87 / Each

9,3
B 714176 1000312298 B8 1/2" BRASS BUSHING No Model Compatibility List $5.04 / Each

8
714193 1000312342 V52 DECAL,WARNING: BOLT DOWN;English No Model Compatibility List $0.00 / Each
Out Of Stock 		7,2,3
Z 714235 1000312700 Z14 7/16" FLAT WASHER No Model Compatibility List $2.44 / Each

2
714246 1000312876 WS Pulley 4 SCREW;HH;.375-16 x 3.25;ZN; No Model Compatibility List $3.74 / Each

2
714253 1000312893 B11 3/8" SAFETY CLIP No Model Compatibility List $16.82 / Each

2,9
B 714266 1000312976 B10 HANDLE W-STRAP D-RING (SHORT) No Model Compatibility List $25.98 / Each

11
714538 1000315894 V50 DECAL MATRIX 11X1 - Black for Blue Moon, Iced Silver, Blood Red, White, Sunburst Orange, Fence Green, or Yellow frame No Model Compatibility List $6.73 / Each

7,3,4,5,6
714740 1000317727 B58 5/8" RUBBER GROMMET No Model Compatibility List $9.49 / Each

2
714915 1000319630 V52 DECAL,WARNING: BOLT DOWN;French No Model Compatibility List $0.00 / Each
Out Of Stock 		7,2,3
715263 1000321910 B40 5/8" GUIDE ROD - 76" No Model Compatibility List $211.22 / Each

3
715264 1000321944 Weight Stack Set 2 WEIGHT PLATE 20# W_BUSHINGS 18.4 X 4.3X No Model Compatibility List $103.06 / Each

8,3
715796 1000328403 V55 900 STACK DECALS, MEDIUM No Model Compatibility List $16.87 / Each

7,3,4,5,6
715967 1000329864 B48 Cable Assy No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6
716147 1000333470 V56 Weight Plate Decals No Model Compatibility List $0.00 / Each
Out Of Stock 		7,3
716648 1000338388 B5 Plug;Seat Post No Model Compatibility List $0.00 / Each
Out Of Stock 		12,13,14
717146 1000341926 AB5 4" Foot (Short) No Model Compatibility List $0.00 / Each
Out Of Stock 		9,3
717168 1000342602 AB1 WELDMENT; USER FRAME;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock 		3
717169 1000342603 AB1 WELDMENT; USER FRAME;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
717170 1000342604 AB1 WELDMENT; USER FRAME;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
717215 1000342962 B4 Stack Guard;Grey No Model Compatibility List $493.45 / Each

9,3,4,5,6
717377 1000344562 V50 Decal;Matrix;Grey for Black Matte, Black Ridge, Black Glossy, Moss Green, or Blue Streak frame No Model Compatibility List $15.18 / Each

7,3,4,5,6
717500 1000345600 B49 5/8# Single Split Collar No Model Compatibility List $10.92 / Each

1
717650 1000346601 B44 Stabilizer Foot;Black Ridge No Model Compatibility List $45.60 / Each

9,3,4,5,6
718282 1000350082 B56 3M safety walk; 4" x 18" No Model Compatibility List $0.00 / Each
Out Of Stock 		9
718779 1000353447 AB7 WELDMENT FRAME 900 SERIES WEIGHT STACK;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
718780 1000353448 AB7 WELDMENT FRAME 900 SERIES WEIGHT STACK;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
718781 1000353449 AB7 WELDMENT FRAME 900 SERIES WEIGHT STACK;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
719338 1000359953 V49 Warning Label;Anti Falling Down;MS24B;;; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
719682 1000363760 V51 Warning Label;Frame;;;PC;;English; No Model Compatibility List $0.00 / Each
Out Of Stock 		3
719683 1000363766 V51 Warning Label;Frame;;;PC;;French;GM40 No Model Compatibility List $5.04 / Each

3
719705 1000364025 V49 Warning Label;Anti Falling Down;MS24B;;; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
719810 1000365837 Weight Stack Se WEIGHT STACK;15 20# 16" C125 No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
720993 1000379407 B35 Spring Pin Assy;Body Spring Pin; No Model Compatibility List $35.46 / Each

2,12,13,14
721006 1000379467 B32 Drop Plate Assy;9000 Series;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
721007 1000379468 B57 Drop Plate Assy;Reversed;900 Series;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
721552 1000384006 V53 Serial Number Label;4" x 1.5";3M; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
721920 1000386596 B33 WEIGHT STACK PULLEY ASSEMBLY No Model Compatibility List $217.98 / Each

8,3,4,5,6
721921 1000386597 WS Pulley 11 HCS 1/4"-20 x 3.00" Zinc No Model Compatibility List $0.00 / Each
Out Of Stock 		1
722457 1000392392 B3 Drop Down Plate Bracket Assy;901;Black R No Model Compatibility List $152.07 / Each

2,3,4,5,6
722461 1000392484 Z22 SCREW;HH;.500-13 x 4.75;ZN; No Model Compatibility List $0.00 / Each
Out Of Stock 		2
722527 1000393455 AB4 WELDMENT T ADJUSTMENT POST;Chrome No Model Compatibility List $0.00 / Each
Out Of Stock 		7,3,12,13,14
723045 1000402696 WS Pulley 1 Weldment;Pulley;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock 		8,3,4,5,6
723046 1000402697 WS Pulley 6 Pulley No Model Compatibility List $0.00 / Each
Out Of Stock 		8
723047 1000402698 WS Pulley Set WS Pulley Set;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock 		8,4,5,6
724564 1000422093 AB6 WELDMENT PULLEY;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock 		8,3
724565 1000422094 AB6 WELDMENT PULLEY;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock 		8,3,4,5,6
724566 1000422095 AB6 WELDMENT PULLEY;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock 		8,3,4,5,6
724567 1000422107 Weight Stack Set 4 WELDMENT CENTER STICK 15 HOLE No Model Compatibility List $0.00 / Each
Out Of Stock 		3
729261 See Pad Matrix J47 Elbow Pad;;PU;Black;;FW213-KM; No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6,12,13,14
