Matrix Commercial - MG-PL77 Seated Calf - 2014

Repair Parts for Matrix Commercial MG-PL77 Seated Calf PL03

Brand: Matrix Commercial

Category: Plate Loaded

Type: Strength Systems

Model Name: MG-PL77 Seated Calf

Version: 2014

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Motors
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
B 700154 000524-A B19 Foot pad;Screw Set Leveler;Rubber;FW11 No Model Compatibility List $38.32 / Each

2,9,3,12,13,14
D 700199 000627-CA D32 Foam;Black;31.8x5.0tx340L No Model Compatibility List $29.30 / Each

4,5,6
M 700200 000628-AA M07 Foam;C,31.8x5.0tx150L No Model Compatibility List $10.95 / Each

1
B 700399 001243-C B17 Washer;Back Pad;POM;GM07 No Model Compatibility List $3.35 / Each

2,4,5,6,12,13,14
End Cap;Round 700448 001402-A Q06 End Cap;Round No Model Compatibility List $1.79 / Each

9
D 700451 001406-A D17 End Cover;89 No Model Compatibility List $1.79 / Each

9
B 700521 001526-D B15 Bolt;Cover;M8x1.25Px40L No Model Compatibility List $2.52 / Each

2,9
B 700526 001529-B B26 Stopper Bolt;Rubber No Model Compatibility List $1.79 / Each

2
D 700685 001791-AA D22 Fix Block;Weight Lifting Connecting Sleeve;POM; No Model Compatibility List $3.64 / Each

3,10
D 701159 004077-A2 D25 Ball Bearing;6004ZZ;20X42X12T;;SKF;;; No Model Compatibility List $20.05 / Each

8
D 701183 004118-00 D34 Bearing;Dry;Flange;LEF-2015 LFF-2015 No Model Compatibility List $3.64 / Each

8
Z 701436 004482-AB Z18 Screw;Hex Socket;Round;M8x1.25Px20L;Cr No Model Compatibility List $2.00 / Each

2
701499 004536-AC D35 Screw;SH;M8X1.25PX15L;;HS;;CHM;; No Model Compatibility List $0.00 / Each
Out Of Stock 		2
D 701836 004855-AC D36 Set Screw;M6X1.0PX4L No Model Compatibility List $1.79 / Each

2
B 701939 004975-00 B20 Insert Nut;Brass;ALS7-8125-3.8(0.5-3.8) No Model Compatibility List $1.90 / Each

2
Z 701968 005007-00 Z03 Washer;Spring;12.2x21.5x3.0t No Model Compatibility List $2.00 / Each

2
Z 702102 005132-00 Z04 Washer;Flat;13x26x2.5T;Chromed No Model Compatibility List $1.79 / Each

7,2,12,13,14
D 702112 005139-AB D28 Washer;Flat;8.2x16.0x1.4T;Chromed No Model Compatibility List $1.79 / Each

7,2,12,13,14
D 702505 008234-C D24 Bushing;Fixed Plate No Model Compatibility List $9.10 / Each

8,3
Z 702531 008523-B Z15 Washer;Arc;M10x28x10.5T;SS41 No Model Compatibility List $9.10 / Each

2
D 702706 009347-B D26 Sleeve;Axle;;SS41;8mm;Cr Plate;;;GM03 SS41 No Model Compatibility List $9.10 / Each

8,3
M 702710 009355-B M09 Stopper Mast;Foam;AL6061;GM02 No Model Compatibility List $3.64 / Each

1
M 702722 009372-E M10 Cap;Grip;GM02 No Model Compatibility List $13.36 / Each

9,11
Adjustment Knob Set;Seat;Yellow 702965 013422-Z1G2 B41 Adjustment Knob Set;Seat;Yellow No Model Compatibility List $36.48 / Each

12,13,14
Pull pin knob; Yellow 703902 019153-A B22 Pull pin knob; Yellow No Model Compatibility List $6.79 / Each

12,13,14
Screw;Seat Stopper;M8x1.25Px20L 704039 020126-DB Z30 Screw;Seat Stopper;M8x1.25Px20L No Model Compatibility List $1.79 / Each

2,12,13,14
Screw;Hex Socket;Round;M8X1.25PX12L 704041 020127-A X05 Screw;Hex Socket;Round;M8X1.25PX12L No Model Compatibility List $1.79 / Each

2
Screw;Hex Socket;M10X1.5PX35L;Cr Plate 704137 020304-AC F16 Screw;Hex Socket;M10X1.5PX35L;Cr Plate No Model Compatibility List $2.00 / Each

2,3
Z 704193 020465-AB Z12 Washer;Flat;M10.2X25PX2.0T;Chromed No Model Compatibility List $1.79 / Each

7,2,12,13,14
D 704301 022372-C D30 Axle;Swivel ArmSupt Tube;SCM4;FW77 No Model Compatibility List $16.64 / Each

8,3
Hardware; 706633 064015-A Not Shown Hardware; No Model Compatibility List $31.72 / Each

1
D 707066 1000090006 D23 End Cover;Seat Tube Sleeve No Model Compatibility List $3.64 / Each

9,3,12,13,14
B 707084 1000090177 B27 Pull Pin Handle;Orange;TPP;137C;MS10 No Model Compatibility List $9.10 / Each

12,13,14,11
Sticker;Weight;PL03 707244 1000091590 V01 Sticker;Weight;PL03 No Model Compatibility List $1.66 / Each

3
707656 1000094060 4 Elevation Set;Cr Plate;PL03 No Model Compatibility List $287.27 / Each

3,10
Pad Block;Painting;PL03 707657 1000094061 B16 Pad Block;Painting;PL03 No Model Compatibility List $23.63 / Each

12,13,14
H 707798 1000095593 H08 Cap;Leg Pad;ABS;GM42 No Model Compatibility List $2.13 / Each

9,12,13,14
C 707799 1000095594 C22 Cap;Leg Pad;ABS;GM42 No Model Compatibility List $1.87 / Each

9,12,13,14
707978 1000097380 D14 Sleeve;Seat Tube No Model Compatibility List $12.92 / Each

3,12,13,14
708037 1000098086 D37 Spring Pin;;Diam.4x20;;; No Model Compatibility List $2.18 / Each

2,12,13,14
Decal;AL;PL03 708064 1000098708 V02 Decal;AL;PL03 No Model Compatibility List $3.35 / Each

7,3
D 708071 1000098871 D13 Pull Pin Set;Seat;Orange Knob No Model Compatibility List $40.64 / Each

12,13,14
D 708091 1000099499 D27 Screw;SH;M8X1.25PX14L;;HS;;CHM;;SP No Model Compatibility List $1.66 / Each

2
Z 708464 1000102880 Z02 Screw;Hex Socket;BH;M12x1.75Px30L;Cr Pla No Model Compatibility List $5.04 / Each

2
Screw;Hex Socket;Stopper;Cone;M6x1.0Px6L 708466 1000102883 B33 / Screw;Hex Socket;Stopper;Cone;M6x1.0Px6L No Model Compatibility List $1.66 / Each

2
B 708469 1000102887 B24 Screw;Hex Socket;Countersunk;M8x1.25Px16 No Model Compatibility List $2.18 / Each

2
Z 708473 1000102893 Z01 Screw;Hex Socket;Flat;M8x1.25Px20L;Cr Pl No Model Compatibility List $1.38 / Each

2
B 708477 1000102897 B21 Screw;Thin Head;M8x1.25Px30L;-;HS;-;CHM; No Model Compatibility List $2.37 / Each

2
D 708591 1000103978 D20 CON Tube;weight lifting;Outer No Model Compatibility List $120.02 / Each

3,10
D 708592 1000103979 D19 CON Tube;weight lifting;Inner No Model Compatibility List $212.71 / Each

3,10
RVN;Pattern;YZN;ALS7-8125-3.8(0.5-3.8) 708657 1000104684 B06 RVN;Pattern;YZN;ALS7-8125-3.8(0.5-3.8) No Model Compatibility List $3.35 / Each

1
Z 708661 1000104689 Z14 Screw;RND;M10x1.5Px115L;HS;G8.8;CHM No Model Compatibility List $8.42 / Each

2
Z 708710 1000105038 Z05 Pin;Spring;5x30L;OXIDIZE No Model Compatibility List $3.64 / Each

2,12,13,14
Logo Label;MATRIX;BLACK WORD/WHITE BASE; 709507 1000200848 V02 Logo Label;MATRIX;BLACK WORD/WHITE BASE; No Model Compatibility List $3.35 / Each

3,4,5,6
C 713593 1000305377 C07 Cover;Back Cover;;PA746;FW203-KM No Model Compatibility List $11.80 / Each

9,4,5,6
V 713703 1000306714 V04 Warning Label;;;;;;;Olympic Bench; No Model Compatibility List $8.42 / Each

1
Z 713794 1000308342 Z13 Screw;Hex;Hex Head;M10x1.5Px35L;Machine No Model Compatibility List $1.66 / Each

2,4,5,6
713848 1000308754 V01 Logo Label;FW201-KM No Model Compatibility List $0.00 / Each
Out Of Stock 		1
4 717878 1000348225 4 Lift set;Semi-Assy;;;;PL03B;; No Model Compatibility List $506.97 / Each

10
N 717880 1000348229 Not Shown Hardware Set;Semi-Assy;;;;PL03B; No Model Compatibility List $62.50 / Each

1
718016 1000349183 1 Frame set;;;Iced Sliver;PL03KM-G3;;Servi No Model Compatibility List $0.00 / Each
Out Of Stock 		3
718017 1000349184 2 pedal arm set;;Big;Iced Sliver;PL03KM-G3 No Model Compatibility List $0.00 / Each
Out Of Stock 		8,9,3
718018 1000349185 3 pedal arm set;;Small;Iced Sliver;PL03KM- No Model Compatibility List $0.00 / Each
Out Of Stock 		8,9,3
V 718538 1000351267 V03 Instructional Labe;Safety;;;;;;PL03B-KM No Model Compatibility List $15.18 / Each

9
D 718622 1000352277 D29 Stopper Pin;;;20CrMo;;PL210-KM;Diam.8x46 No Model Compatibility List $11.80 / Each

12,13,14
V 718927 1000354311 V08 Decal;;25LBS;;;;;Starting Resistance PL0 No Model Compatibility List $3.35 / Each

7,3,10
719451 1000361667 1 Frame Set;Semi-Assy;;;;PL03B;Iced Sliver No Model Compatibility List $0.00 / Each
Out Of Stock 		3
B 719452 1000361679 B16 Pad Plate;;;painting;;Iced Sliver;PL03B; No Model Compatibility List $23.63 / Each

3,12,13,14
2 719453 1000361685 2 Pedal Arm set;Semi-Assy;1;;;PL03B;Iced S No Model Compatibility List $337.97 / Each

8,9,3
3 719454 1000361697 3 Pedal Arm set;Semi-Assy;2;;;PL03B;Iced S No Model Compatibility List $135.17 / Each

8,9,3
H 725014 100995 H10 Stopper Ring;Leg Pad;ABS;GM42 No Model Compatibility List $2.83 / Each

12,13,14
Screw, Flat Hex Socket, M8x1.25Px8L 725312 069801 C29 Screw, Flat Hex Socket, M8x1.25Px8L No Model Compatibility List $1.79 / Each

2
726607 083458 Z62 Washer;Lock;8.2x13.5x2.0t No Model Compatibility List $2.00 / Each

2
Stopper Pad;PU;PL03 727029 086768 B13 Stopper Pad;PU;PL03 No Model Compatibility List $25.32 / Each

12,13,14
Pedal;PL03 727030 086769 B14 Pedal;PL03 No Model Compatibility List $106.65 / Each

8,9
Swivel Arm Axle;20x138.4L;PL03 727031 086775 D12 Swivel Arm Axle;20x138.4L;PL03 No Model Compatibility List $22.72 / Each

8,3
horn;30x651L;PL03 727032 086778 D21 horn;30x651L;PL03 No Model Compatibility List $94.72 / Each

1
Support Rubber Plate;Pedal Arm;PL03 727033 086784 D15 Support Rubber Plate;Pedal Arm;PL03 No Model Compatibility List $41.83 / Each

8,9,3
Label;ADJPL03 727034 086792 V02 Label;ADJPL03 No Model Compatibility List $3.35 / Each

1
Hard Ware Kit;Semi-Assy;PL03 727035 086794 Not Shown Hard Ware Kit;Semi-Assy;PL03 No Model Compatibility List $38.53 / Each

1
StopperRubberPL03 727749 090781 B27 StopperRubberPL03 No Model Compatibility List $1.66 / Each

1
Sleeve TubeHorn;Black;50x260L;PL03 727838 091250 D19 Sleeve TubeHorn;Black;50x260L;PL03 No Model Compatibility List $119.44 / Each

3,4,5,6
Rubber PadHornBlack;PL03 727839 091251 D20 Rubber PadHornBlack;PL03 No Model Compatibility List $23.43 / Each

4,5,6,12,13,14
Warning sticker;small;GM40-KM 728185 093501 V08 Warning sticker;small;GM40-KM No Model Compatibility List $1.66 / Each

1
728408 094583 Not Shown Manual;Assembly Guide;PL03 No Model Compatibility List $15.63 / Each

3
CON Plate; Cap;SPHC3.0t;GM42 728704 096073 H12 CON Plate; Cap;SPHC3.0t;GM42 No Model Compatibility List $2.37 / Each

9,3
Stopper Ring;Cap;AL6061;GM42 728705 096074 H13 Stopper Ring;Cap;AL6061;GM42 No Model Compatibility List $19.81 / Each

9
729012 Order Kit 1 4 Console Base Set;Semi-Assy;;;;TM701-1US; No Model Compatibility List $0.00 / Each
Out Of Stock 		7,3
729024 Order Kit 2 AM01 Motor set;Semi-Assy;;;;TM701-1US;;Servic No Model Compatibility List $0.00 / Each
Out Of Stock 		10
729027 Order Kit 3 AH03 Sleeve Set;Semi-Assy;;;;TM658E-2KM;; No Model Compatibility List $0.00 / Each
Out Of Stock 		3
729071 Pad Matrix C29 Cushion;;PU,Vesicant;Black;GM14KM-G3; No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
729261 See Pad Matrix J02 Elbow Pad;;PU;Black;;FW213-KM; No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6,12,13,14
