Matrix Commercial - R1x-G4 - 2009

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry used@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Motors
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Belt Related
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
000537-BA 700158 000537-BA 55 Adjustable Foot Pad Set;CB61 No Model Compatibility List $10.20 / Each

9,3,12,13,14
001660-00 700562 001660-00 66 Bushing;Flanged;PVC;BLK;SB-26 No Model Compatibility List $1.28 / Each

8
004050-A 701146 004050-A 105 Pedal Strap Set(includes both sides);Rub No Model Compatibility List $28.06 / Each

8,9
004078-A2 701160 004078-A2 107 Ball Bearing;6005ZZ;Z25XZ47X12T;;TPI;;; Yes Model Compatibility List $14.72 / Each

8
004174-A 701213 004174-A 96 Drive Belt;Poly-V;390-J8 No Model Compatibility List $38.98 / Each

15,10
004329-00 701268 004329-00 64 Screw;Phillip;Round;M5x0.8Px10L; No Model Compatibility List $1.54 / Each

2
004355-00 701286 004355-00 63 Screw;Oval;PH; M4X0.7PX10L No Model Compatibility List $1.54 / Each

2
004369-AH 701311 004369-AH 99 Screw;Phillip;BH;Stainess;M5x0.8Px15L; No Model Compatibility List $1.38 / Each

2
004384-00 701331 004384-00 98 Screw;Phillip;BH;M5x0.8Px30L;Ni;Gap; No Model Compatibility List $1.54 / Each

2
004456-00 701402 004456-00 92 Screw;Round;Hex Socket;M5x0.8Px16L No Model Compatibility List $1.38 / Each

2
004462-00 701408 004462-00 91 Screw;Round;Hex Socket;M6x1.0Px15L;Chromed No Model Compatibility List $1.54 / Each

7,2,12,13,14
004526-AB 701480 004526-AB 43 Screw;Round;Hex Socket;M6X1.0PX30L No Model Compatibility List $1.38 / Each

2
004569-00 701541 004569-00 61 Screw;Plain;Hex Socket;M5X0.8PX15L No Model Compatibility List $1.54 / Each

2
004574-AD 701547 004574-AD 52 Screw;FH;M8x1.25Px15L;MT;HS;SST;CHM;F-T No Model Compatibility List $1.28 / Each

2
004615-00 701583 004615-00 65 Screw;Umbrella Cross Tapped;4x10L No Model Compatibility List $1.54 / Each

2
004628-00 701607 004628-00 57 Screw;Oval Tapping;Phillip;5x15L No Model Compatibility List $1.22 / Each

2,12,13,14
004647-00 701626 004647-00 51 Screw;Phillip;Round;3x12L No Model Compatibility List $1.38 / Each

2
004696-AB 701660 004696-AB 38 Screw;Hex Socket;8X1.25X20L;Chromed No Model Compatibility List $1.54 / Each

7,2,12,13,14
004745-00 701724 004745-00 68 Screw;BH;M8X1.25PX55L-25L;;HS;;BAN;;P-T No Model Compatibility List $1.28 / Each

2
004763-00 701740 004763-00 74 Screw;Hex Socket;BH;M8x1.25Px16L;Adhere No Model Compatibility List $1.54 / Each

2
004848-00 701828 004848-00 41 Set Screw;M6X1.0PX10L No Model Compatibility List $1.38 / Each

2
004926-00 701897 004926-00 46 Nut;Nylon;M8x1.25P No Model Compatibility List $1.54 / Each

2
004935-00 701909 004935-00 42 Nut;Nylon;M6X1.0P No Model Compatibility List $1.54 / Each

2
004964-00 701927 004964-00 103 Nut;Hex;Flange;M10x1.25P;Black Zinc No Model Compatibility List $1.54 / Each

2,4,5,6
005004-00 701961 005004-00 90 Washer;Spring;Lock;SW6 6.1x12.2x1.5t No Model Compatibility List $1.54 / Each

2
005005-00 701964 005005-00 69 Washer;Spring;Lock;8.2x15.4x2.0t No Model Compatibility List $1.22 / Each

2
005015-00 701978 005015-00 112 Washer;Spring;SW8 8.2X13.5X2.0T No Model Compatibility List $1.54 / Each

2
005082-00 702054 005082-00 62 Washer;Flat;5.0x16.0x1.0T;Black Zinc No Model Compatibility List $1.54 / Each

2,4,5,6
005155-A 702128 005155-A 89 Washer;Flat;6.2x12.0x2.0T;Black Zinc No Model Compatibility List $1.38 / Each

2,4,5,6
005165-00 702136 005165-00 109 Washer;Arc;8.2x18x1.5T No Model Compatibility List $1.54 / Each

2
005222-00 702180 005222-00 72 Washer;Wavy;16.7x22.5x0.3T No Model Compatibility List $1.54 / Each

2,4,5,6
005239-00 702193 005239-00 102 Washer;Lock;10.0x20.0x1.0T No Model Compatibility List $1.54 / Each

2
005366-00 702241 005366-00 106 C-Clip;External;S-25 No Model Compatibility List $1.22 / Each

2
005438-00 702275 005438-00 95 Spring;Foot Lock Latch;16x2.0x50Lx12N No Model Compatibility List $1.54 / Each

2,9,3
005844-B 702304 005844-B 56 Fix Buckle Base;PVC;GM01 No Model Compatibility List $1.38 / Each

3
005845-B 702306 005845-B 58 Fix Buckle Base;Nylon;GM01 No Model Compatibility List $1.38 / Each

3
006298-A 702346 006298-A 67 Decal;Guide Rail No Model Compatibility List $2.58 / Each

7,9,3
008016-A 702488 008016-A 47 Washer;Lock;8.4X18.0X3.0T;S45C No Model Compatibility List $1.38 / Each

2
008420-00 702517 008420-00 94 Adjustment Plate;Tension;6Hole No Model Compatibility List $1.28 / Each

3
017657-00 703809 017657-00 93 Spacer;Generator Shoulder;Right No Model Compatibility List $1.46 / Each

2,8,3,4,5,6
020297-00 704129 020297-00 110 Screw;BH;M8X1.25PX45L;;HS;;BZN;;BP No Model Compatibility List $1.54 / Each

2
020426-00 704176 020426-00 73 Washer;Flat;8.2x30.0x1.5T No Model Compatibility List $1.54 / Each

2
038076-A 705139 038076-A 100 Matrix Decal No Model Compatibility List $12.14 / Each

7,3
038449-A 705163 038449-A 84 Clip;Tapped Hole;FE;M5;YZN No Model Compatibility List $7.00 / Each

2
056225-A 705777 056225-A 80 Ferrite;PART OF #79 CABLE;NOT ORDERABLE; No Model Compatibility List $6.48 / Each

4,5,6
065248-A 706754 065248-A 75 TV Coax Adaptor;Female;F-A028-NBX7-C Yes Model Compatibility List $2.80 / Each

4,5,6
065640-A 706799 065640-A 50 Screw;Round Cross Tapped;M3X30L No Model Compatibility List $1.54 / Each

2
067654-AA 706967 067654-AA 39 Seat Position Indicator Plate;BLACK;RB50B; No Model Compatibility List $46.82 / Each

3,4,5,6,12,13,14
1000109595 709103 1000109595 104 Crank Arm Cover;Round;Plastic;Black No Model Compatibility List $2.94 / Each

8,9,3,4,5,6
1000347305 717744 1000347305 Not Shown Battery;With Protect circuit;;;;7.4V 148 No Model Compatibility List $140.38 / Each

4,5,6
1000364363 719731 1000364363 16 crank set;;;RB85-SBOM;Clear coat;RB85;; Yes Model Compatibility List $129.98 / Each

8
072350 725514 072350 70 Front Stabilizer End Cap;Left No Model Compatibility List $6.48 / Each

9
072351 725515 072351 71 Front Stabilizer End Cap;Right No Model Compatibility List $6.48 / Each

9
726116 080059 97 Rear Cover 2 Hole Fixing Plate;CST;RB85; No Model Compatibility List $1.28 / Each

9,3
726118 080108 60 Seat Pad,Black;RB85 No Model Compatibility List $93.68 / Each

4,5,6,12,13,14
726189 080680 79 Console Cable;Console to LCB No Model Compatibility List $42.10 / Each

7,4,5,6
726190 080681 53 HR Grip Sensor Wire No Model Compatibility List $26.04 / Each

7,4,5,6,12,13,14,11
726191 080682 81 HR Grip Sensor Extension Wire Lower;LCB No Model Compatibility List $30.74 / Each

7,4,5,6,12,13,14,11
0000080683 726192 0000080683 87 Generator Wire;Generator to LCB;JST VHR- Yes Model Compatibility List $14.58 / Each

4,5,6,7,8,12,13,14
726193 080684 86 Generator Load Wire;Generator to LCB;JST No Model Compatibility List $11.24 / Each

8,4,5,6
726194 080685 76 TV Signal Wire(Coax);E-port to Console;R No Model Compatibility List $14.28 / Each

7,4,5,6
726195 080686 77 TV Power Wire;E-port to Console No Model Compatibility List $12.14 / Each

7,4,5,6
726203 080700 78 Hand Grip Wire;1250L;(TKP H6630P1-06+SMP No Model Compatibility List $25.28 / Each

4,5,6,11
726246 080945 114 Screw;BH;M5X0.8PX40L;CT;PH;SST;;; No Model Compatibility List $1.28 / Each

2
726849 085631 17 Lower Control Board Set;CB66-KM No Model Compatibility List $594.90 / Each

7
085663 726860 085663 G04 Handlebar Set;Right No Model Compatibility List $40.86 / Each

11
726936 086118 49 Washer;Split;5.1X8.4X1.1T;;BAN; No Model Compatibility List $1.28 / Each

2
727039 086836 44 Spring;CMP;SUP;NKL;RB85-D37; No Model Compatibility List $6.48 / Each

2
088498 727315 088498 N02 Cover;Console;Upper No Model Compatibility List $108.10 / Each

7,9
727580 090125 1 Console Mast Set;MX-R1x;RB302 No Model Compatibility List $187.60 / Each

7
727581 090131 3 Seat Adjustment Handle Set ; MX-R1x; RB3 No Model Compatibility List $35.46 / Each

12,13,14,11
727583 090136 9 Rear Stabilizer Set; MX-R1x; RB302 No Model Compatibility List $318.76 / Each

1
727588 090146 11 Front Cover Set, Left; MX-R1x; RB302 No Model Compatibility List $88.84 / Each

9
727589 090149 12 Front Cover Set, Right; MX-R1x; RB302 No Model Compatibility List $87.76 / Each

9
727590 090151 13 Rear Cover Set, Left; MX-R1x; RB302 No Model Compatibility List $83.62 / Each

9
727592 090154 14 Rear Cover Set, Right; MX-R1x; RB302 No Model Compatibility List $81.98 / Each

9
090162 727594 090162 115 Manual;Manipulate;English;MX-R1x; No Model Compatibility List $13.96 / Each

1
727632 090256 4 HR Handlebar Set (HR grips included); MX No Model Compatibility List $228.30 / Each

7,12,13,14,11
090294 727651 090294 101 Model Decal;MX-U1x No Model Compatibility List $12.80 / Each

7,3
727657 090315 8 Seat Rail Set; MX-R1x; RB302 No Model Compatibility List $459.04 / Each

9,12,13,14
727658 090319 30 ECB / Generator Set;MX-R1x;RB302 No Model Compatibility List $560.20 / Each

8
727701 090496 2 Seat Frame Double Roller Set; MX-R1x; RB No Model Compatibility List $44.54 / Each

8,3,12,13,14
727702 090497 6 Back Pad Rear Cover Set; MX-R1x; RB302 No Model Compatibility List $38.30 / Each

9,4,5,6,12,13,14
727703 090501 7 Handlebar Set; MX-R1x; RB302 No Model Compatibility List $130.18 / Each

11
090505 727705 090505 Q01 Motor Cover-T800 No Model Compatibility List $66.66 / Each

9,10
0000090518 727707 0000090518 66 Pedal Set Yes Model Compatibility List $56.14 / Each

8,9
727840 091255 20 Seat Rail End Cap Set;MX-R1x;RB302 No Model Compatibility List $7.66 / Each

9,12,13,14
727841 091256 21 Rear Stabilizer End Cap Set, Left;MX-R1x No Model Compatibility List $9.86 / Each

9
727842 091257 22 Rear Stabilizer End Cap Set, Right;MX-R1 No Model Compatibility List $9.36 / Each

9
727843 091258 23 Seat Adjustment Block Set;MX-R1x;RB302 No Model Compatibility List $65.80 / Each

12,13,14
727844 091259 24 HR Grip Set (see Set 4 for full handleba No Model Compatibility List $116.08 / Each

7,12,13,14,11
727845 091260 27 Seat Rail Stopper Wheel Set;MX-R1x;RB302;SBOM No Model Compatibility List $24.96 / Each

8,9,12,13,14
727846 091261 28 Seat Rail Fixing Plate Set;MX-R1x;RB302 No Model Compatibility List $32.22 / Each

9,3,12,13,14
727847 091262 29 Seat Rail Adjustment PlateSet;MX-R1x;RB3 No Model Compatibility List $80.50 / Each

9,3,12,13,14
727848 091263 31 Sticker;Aperture;TV Rack;CB85;SBOM No Model Compatibility List $6.48 / Each

4,5,6
727849 091264 32 Cup Holder Set;MX-R1x;RB302 No Model Compatibility List $30.16 / Each

1
727850 091265 33 E-port Fixing Plate Set;MX-R1x;RB302 No Model Compatibility List $6.48 / Each

3
727903 092003 10 Front Wheel Set;MX-R1x;RB302;SBO No Model Compatibility List $4.30 / Each

8
727904 092004 19 Idler Set;MX-R1x;RB302;SBOM No Model Compatibility List $71.10 / Each

8
727905 092005 25 Lower Seat Frame Sett;MX-R1x;RB302;SBOM No Model Compatibility List $344.38 / Each

3,12,13,14
727906 092006 26 Upper Seat Frame Sett;MX-R1x;RB302;SBOM No Model Compatibility List $123.94 / Each

3,12,13,14
ZMS3000424 729455 ZMS3000424 Not Shown Power Supply-12 Volt A/C Adapter No Cord No Model Compatibility List $94.44 / Each

4,5,6
ZMS3000429 729456 ZMS3000429 Not Shown US Power Cord for 12-Volt Power Supply No Model Compatibility List $56.14 / Each

4,5,6
