Matrix Commercial - U7xe-05 - 2014

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry used@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Motors
  • Seats
  • Posts
  • Pins
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
000041-AA 700024 000041-AA J19 Transport Wheel Yes Model Compatibility List $7.00 / Each

8
002782-C 700924 002782-C Not Shown Power Cord;External(USA);3000,14AWG;110V(non-nema) Yes Model Compatibility List $56.14 / Each

4,5,6
002787-C 700925 002787-C Not Shown Power Cord;External(USA);3000,14AWG;110V(nema) No Model Compatibility List $56.14 / Each

4,5,6
003383-A 701032 003383-A N94 Ferrite Choke;FH0900B-2;Lian Ci;TM38 No Model Compatibility List $7.00 / Each

1
003393-A 701035 003393-A P51 Ferrite Core;FH1500B;TM87 K1 RH12.5x12.5x8 No Model Compatibility List $2.80 / Each

1
004050-A 701146 004050-A T07 Pedal Strap Set(includes both sides);Rub No Model Compatibility List $28.06 / Each

8,9
004077-A2 701159 004077-A2 U03 Ball Bearing;6004ZZ;20X42X12T;;SKF;;; No Model Compatibility List $15.42 / Each

8
004321-00 701260 004321-00 N59 Screw;Round;PH;M4 x 0.7P x 10L No Model Compatibility List $1.54 / Each

2
004375-AC 701321 004375-AC G27 Screw;Phillip;BH;Stainess;M5x0.8Px15L;BE No Model Compatibility List $1.38 / Each

2
004385-00 701332 004385-00 N85 Screw;BH;M5X0.8PX12L;;PH;;BAN;; No Model Compatibility List $1.38 / Each

2
004447-AB 701390 004447-AB D20 Screw;Hex Socket;Round;M5x0.8Px12L;Adher No Model Compatibility List $1.10 / Each

2
004447-AC 701391 004447-AC G21 SCREW;SH;M5X0.8PX12L;CT;HS;;BAN;; No Model Compatibility List $1.28 / Each

2
004627-00 701605 004627-00 N83 Screw;Phillip;BH;Tapped;5x12L No Model Compatibility List $1.54 / Each

2
004884-00 701862 004884-00 B38 Nut;Hex;M8X1.25P No Model Compatibility List $1.38 / Each

2
004889-00 701866 004889-00 P55 Nut;Hex;M5x0.8P;Nickel No Model Compatibility List $1.54 / Each

2
004957-00 701924 004957-00 R09 Nut;Lock;M25X1.5P;SS41;BAN Yes Model Compatibility List $2.80 / Each

2
004980-A 701945 004980-A B19 Insert Nut;Hex;NHS-580-3.0(M5X0.8P) No Model Compatibility List $1.38 / Each

2
004987-00 701951 004987-00 R05 Key;Round;Dual End;6X6X12L No Model Compatibility List $1.28 / Each

9
005042-00 702004 005042-00 J17 Washer;Flat;8.2X30.0X2.0T;Black Zinc No Model Compatibility List $1.54 / Each

2,4,5,6
005075-00 702046 005075-00 S05 Washer;Flat;6.2X16X2.0T;Black Zinc No Model Compatibility List $1.54 / Each

2,4,5,6
005094-00 702066 005094-00 N156 Washer;Flat;3.2x8.0x1.0T;Black Zinc No Model Compatibility List $1.54 / Each

2,4,5,6
005157-A 702131 005157-A N153 Washer;Flat;4.3x12.0x1.0T;Black Zinc No Model Compatibility List $1.38 / Each

2,4,5,6
005220-00 702178 005220-00 J14 Washer;Wavy;20.7x29.1x.3T No Model Compatibility List $1.54 / Each

2,4,5,6
005354-00 702229 005354-00 U09 C-Clip;Internal;R-42 No Model Compatibility List $1.38 / Each

2
005366-00 702241 005366-00 R07 C-Clip;External;S-25 No Model Compatibility List $1.22 / Each

2
006078-00 702325 006078-00 V11 Decal;Grounding;TM08 No Model Compatibility List $1.46 / Each

7,3
008864-A 702589 008864-A N151 Screw;Special;Round;2.9x1.06Px7L(Hi-Lo) No Model Compatibility List $1.38 / Each

2
008865-B 702590 008865-B N154 Screw;Special;Round;2.9x1.06Px12L(Hi-Lo No Model Compatibility List $1.38 / Each

2
008866-A 702591 008866-A N152 Screw;Special;Round;4.0x1.34Px12L(Hi-Lo No Model Compatibility List $1.28 / Each

2
010515-00 702795 010515-00 W19 Copper Pillar;M3x12L No Model Compatibility List $1.28 / Each

1
018652-B 703852 018652-B B44 Screw;SH;M6X1.0PX16.5L-8L;;HS;CRMO;BAN;; No Model Compatibility List $2.80 / Each

2
020005-00 703962 020005-00 P02 Screw;Phillip;Round;M3x6L;;Zn-BL No Model Compatibility List $1.38 / Each

2
020069-00 703990 020069-00 J16 Screw;SH;M8X1.25PX12L;HS;BP;G12.9; No Model Compatibility List $1.38 / Each

2
056225-A 705777 056225-A P52 Ferrite;PART OF #79 CABLE;NOT ORDERABLE; No Model Compatibility List $6.48 / Each

4,5,6
061339-B 706354 061339-B W56 Fan;DC12V/0.3A PMB1297PYB3-AY;EP70 No Model Compatibility List $90.22 / Each

8,4,5,6
065248-A 706754 065248-A P03 TV Coax Adaptor;Female;F-A028-NBX7-C Yes Model Compatibility List $2.80 / Each

4,5,6
067774-A 706978 067774-A N35 Power Cord;FH33.3x8.25x16.4(FH0900B);TM95 No Model Compatibility List $6.48 / Each

4,5,6
1000201693 709609 1000201693 N96 Exchange connectorl; KST DWTSFSOLR; No Model Compatibility List $0.78 / Each

1
1000206777 710100 1000206777 P32 C Safe+TV Connect Wire;200(TKP H20J2-15x No Model Compatibility List $31.16 / Each

4,5,6
1000206779 710102 1000206779 W66 Console Cable;250(MOLEX,50-57-9408+MOLEX, No Model Compatibility List $43.52 / Each

7,4,5,6
710164 1000207104 P38 LI Battery;2200MA/H;EP606; No Model Compatibility List $0.00 / Each
Out Of Stock
1
1000207108 710166 1000207108 P36 Battery Con Wire;200(TKP H110-03S+TKP H6 No Model Compatibility List $10.88 / Each

4,5,6
1000208207 710268 1000208207 W18 Inverter Board Set;TM503;T7xe; No Model Compatibility List $169.44 / Each

1
1000208238 710276 1000208238 AN15 Cover;Console;Back;Printing;EP No Model Compatibility List $68.18 / Each

7,9,4,5,6
1000208248 710277 1000208248 AN4 Cover;Overlay;15 INCH;PR;OV;EP92F; No Model Compatibility List $106.66 / Each

9
1000208535 710289 1000208535 AN51 Heart Rate Board Set;SALUTRON 8600;EP93C; No Model Compatibility List $231.24 / Each

12,13,14
1000208781 710307 1000208781 N15 Plastic BASE;U;ABS/PA746;PA:60461;T7x-03 No Model Compatibility List $2.58 / Each

9,3
1000210553 710483 1000210553 N16 USB;EP90B No Model Compatibility List $11.08 / Each

1
1000211294 710607 1000211294 N98 Screw;FH;M3X0.5PX30L;-;PH;BZN; No Model Compatibility List $1.28 / Each

2
1000212322 710678 1000212322 N25 Shim;Rubber;D;NBR;BLACK;TM507C; No Model Compatibility List $1.28 / Each

4,5,6
1000214924 710880 1000214924 P08 Battery;650(FDFNYD2-187)X2 VHR-2N+FUSE Yes Model Compatibility List $25.30 / Each

7,12,13,14
1000216152 711044 1000216152 N22 Fan ADJ Plate;SUS304;0.3t;T9000; No Model Compatibility List $2.58 / Each

8,3
1000217094 711146 1000217094 W21 Wire;NET;550(TKP,H6630R1-08AMP 569532) No Model Compatibility List $2.58 / Each

4,5,6
1000224836 711996 1000224836 W69 CONSOLE GND WIRE;130+220(KST,FDFNYD2-250 No Model Compatibility List $7.00 / Each

7,4,5,6
1000226528 712082 1000226528 N27 Fixing Plate;TUNER;SECC;1.0t;TM521; No Model Compatibility List $6.48 / Each

3
1000226689 712104 1000226689 AN31 Overlay Set;TV;-;English;EP613 No Model Compatibility List $140.38 / Each

4,5,6
1000229467 712551 1000229467 W53 CONSOLE CONTROL BOARD;H001;COATING;EP611 No Model Compatibility List $25.26 / Each

7
1000231078 712866 1000231078 G26 SCREW;BH;?X5X1.6PX12L(HI-LO);PH;BZN; No Model Compatibility List $1.28 / Each

2
1000231080 712867 1000231080 W27 Wire;Ipod;550(JST XADR-16+PAP-06/-10);T7 No Model Compatibility List $25.26 / Each

4,5,6
1000232274 713008 1000232274 W47 GND;-;-;Yellow/Green1;I-POD;18AWG;200mm; No Model Compatibility List $6.48 / Each

1
1000232817 713051 1000232817 P03 USB Wire;-;-;500+550;(JST XAP-06V-1X2+KS No Model Compatibility List $10.38 / Each

4,5,6
1000233231 713135 1000233231 N46 FIXING PLATE;15 INCH;SPCC;0.8t;T-7xe-04- No Model Compatibility List $25.98 / Each

3
1000233262 713147 1000233262 1 Panel Board Set;15 inch;-;-;TFT LCD;EP61 No Model Compatibility List $1.00 / Each

7
1000309219 713881 1000309219 P09 Battery WP1.2-12;12V 1.2Ah; Yes Model Compatibility List $56.14 / Each

1
1000323618 715314 1000323618 W20 Control Board Set;LMM;;;EP613;; No Model Compatibility List $1199.00 / Each

7
1000346722 717677 1000346722 4 Drive axle set;;L/F;crank;S-BOM;;CB93;;NEW No Model Compatibility List $308.86 / Each

8,10
1000346723 717678 1000346723 4 Transmission set;;S-BOM;;CB93;;NE No Model Compatibility List $153.38 / Each

1
1000353342 718757 1000353342 W28 Ipod Extend Wire;;;;;;300(MF1512S0017+JA No Model Compatibility List $56.14 / Each

9,4,5,6
1000366515 719870 1000366515 W24 Earphone board set;;;;EP620; No Model Compatibility List $32.48 / Each

1
1000404540 723181 1000404540 W24/W58 Earphone board set;;;;Earphone board set No Model Compatibility List $51.98 / Each

1
1000425274 724734 1000425274 AW1 Tuner Module;;;REV 2.0;S20170417;;US for No Model Compatibility List $452.38 / Each

1
069851 725318 069851 W33 Console TV Cable Extended Wire;250L(FM-0086-N No Model Compatibility List $7.80 / Each

7,9,4,5,6
726397 081594 W101 Pulse Wire;150(FDFNYD2-250-1+546BS-2);TM No Model Compatibility List $2.80 / Each

4,5,6,12,13,14
726540 082661 B39 Screw;Wagon;M8x1.25Px20L;BLACK No Model Compatibility List $0.54 / Each

2,4,5,6
726549 082734 P59 Washer;Senated;M5.3X10X0.6;Zinc Plate No Model Compatibility List $1.38 / Each

2,3
726594 083278 Z22 USB Cover;USB-03 No Model Compatibility List $1.46 / Each

9
726607 083458 Z62 Washer;Lock;8.2x13.5x2.0t No Model Compatibility List $1.54 / Each

2
726832 085415 W33 LVDS Wire;15 Inch TFT LCD;410(HRS DF14H-20P+D No Model Compatibility List $21.22 / Each

7,4,5,6,12,13,14
085779 726885 085779 AM1 Elevator Motor;AC;110V/123mm;JM03;only Yes Model Compatibility List $272.98 / Each

4,5,6,10
726928 086064 N33 Cover;Console;Right;ABS/PA-746;BL;TM501; No Model Compatibility List $2.58 / Each

7,9
726929 086065 N34 Cover;Console;Left;ABS/PA-746;BL;TM501; No Model Compatibility List $2.58 / Each

7,9
726993 086533 N47 Bracket;Isolation Board Cover;0.6t;TM503 No Model Compatibility List $6.48 / Each

2,9,3,4,5,6
727017 086684 W13 Speaker Set;AK-402808BC-3T+280+XAP-02;TM No Model Compatibility List $13.58 / Each

1
727041 086852 W38 Rubber Ring;GM-5 No Model Compatibility List $0.78 / Each

1
727076 087056 N13 Vent;Fan;ABS/PA-746;Pantone:877C;TM501; No Model Compatibility List $34.80 / Each

8
727194 087672 Z41 Screw;Hex Socket;Round;M5x0.8Px8L No Model Compatibility List $1.38 / Each

2
727213 087846 N49 Foam;Overlay;1;315.5x4.0x1.0t;Rubber/BL; No Model Compatibility List $1.28 / Each

1
727214 087847 V01 No Model Compatibility List $0.00 / Each
Out Of Stock
1
727215 087848 V09 No Model Compatibility List $0.00 / Each
Out Of Stock
1
727351 088743 N81 Screw;TRH;M3x.5Px6L;MT;PH;CST;ZNC;F-T No Model Compatibility List $1.38 / Each

2
727358 088790 N52 Anti-Slippery Pad;TPR+30%PP;BL;MX-E5XC-F No Model Compatibility List $7.00 / Each

12,13,14
727371 088888 N42 insulation Plate;INVETER;PC;8B35;3M-467; No Model Compatibility List $1.40 / Each

3
727421 089108 W34 Wire;Tuner Signal;JST PAP-12;T7x-01; No Model Compatibility List $23.92 / Each

4,5,6
727442 089261 N18 Cover;IPOD Fixing;ABS/PA746;Deep Grey 80 No Model Compatibility List $2.80 / Each

9
727469 089486 N12 Bushing;KSS Moveable;KG-008;10M/Reel; No Model Compatibility List $18.18 / Each

8
727474 089506 Not Shown No Model Compatibility List $0.00 / Each
Out Of Stock
1
727514 089691 W02 TV Control Board Set;TM503;T7xe; No Model Compatibility List $307.82 / Each

7,4,5,6
727543 089849 W45 Wire;Hand Pulse Sensor;350L(2510A-06,TKP No Model Compatibility List $16.08 / Each

4,5,6,12,13,14
727795 091027 W25 LCM Wire;130L(H6630R1-18)x2 No Model Compatibility List $20.04 / Each

4,5,6
727796 091028 W30 TV Key Wire;160L(H6630R1-14)x2 No Model Compatibility List $6.48 / Each

9,4,5,6
727858 091621 N41 Fix Plate;Tuner;MX-E7X-C;US;EP91 No Model Compatibility List $12.80 / Each

3
727961 092217 W75 Heart Rate Power Wire;250L(2510A-03+XAP- No Model Compatibility List $7.02 / Each

4,5,6,12,13,14
728026 092696 N202 Fixing Plate;Fan;0.8t;T5x-02; No Model Compatibility List $7.00 / Each

8,3
728132 093219 AB1 RIGHT MAIN FRAME SET No Model Compatibility List $453.16 / Each

3
728371 094425 Not Shown No Model Compatibility List $0.00 / Each
Out Of Stock
1
0000094929 728450 0000094929 J11 Cap;Stabilizer;Left-Front;ABS/PA757;P804 Yes Model Compatibility List $9.26 / Each

9
0000095100 728498 0000095100 J12 Cap;Stabilizer;Right-Front;ABS/PA757;P80 Yes Model Compatibility List $7.26 / Each

9
728542 095231 W04 Control Board;USB;H001;U105A5;EP603; No Model Compatibility List $21.76 / Each

7
728544 095247 W52 C-Safe;E LEAD;3P00DMJE001-0A;EP92F; No Model Compatibility List $80.64 / Each

1
728600 095575 N203 Tape;Foam;One-Sided;50x15x1.5T; No Model Compatibility List $1.28 / Each

1
0000095638 728614 0000095638 J15 Foot Pad;Adjustable;M12X58H;12.9;EP304; Yes Model Compatibility List $26.04 / Each

3,9,12,13,14
728616 095641 N157 SCREW;RND;#X4.0X1.34PX8L(HI-LO);PH;BZN; No Model Compatibility List $1.28 / Each

2
728977 N/A V05 Console Mast,Old version (4 holes on front) No Model Compatibility List $0.00 / Each
Out Of Stock
7
729118 Part of Kit 1 AC11 Stabilizer Frame;Rear;B;Panting;MM330;EP212 No Model Compatibility List $0.00 / Each
Out Of Stock
3
729127 Part of Kit 14 AJ3 Crank Pin Sleeve;Aluminum Casting;EP525- No Model Compatibility List $0.00 / Each
Out Of Stock
8,3,12,13,14
729129 Part of Kit 15 AJ4 Link Arm;Left;Panting;MM330;EP212 No Model Compatibility List $0.00 / Each
Out Of Stock
3
729133 Part of Kit 16 T01 Stabilizer;Front;Panting;MM330;EP212 No Model Compatibility List $0.00 / Each
Out Of Stock
1
729135 Part of Kit 17 T02 Transmission Axle;42CrMo;EP217 No Model Compatibility List $0.00 / Each
Out Of Stock
8
729138 Part of Kit 2 AD2 Console Mast;Painting;MM330;6027-45- No Model Compatibility List $0.00 / Each
Out Of Stock
7
729144 Part of Kit 22 U04 Generator;-;8.0KG EP537-1US;-;-;-; No Model Compatibility List $0.00 / Each
Out Of Stock
8
729165 Part of Kit 4 R03 Pedal Arm;Left;EP212 No Model Compatibility List $0.00 / Each
Out Of Stock
8,9,3
729519 ZMS4000948 Not Shown BIKES - Virtual Active Board Kit (10 Map Pack) No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
ZMS4004742 729777 ZMS4004742 Not Shown Silicon Plug, 0.25"0.125"0.75" Black No Model Compatibility List $1.76 / Each

4,5,6
