Matrix Commercial - VY-6037-02 - 2013

Repair Parts for Matrix Commercial VY-6037-02 VYGM322

Brand: Matrix Commercial

Category: Single Station

Type: Strength Systems

Model Name: VY-6037-02

Version: 2013

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
B 713806 1000308417 B12 2" x 2" END CAP No Model Compatibility List $5.46 / Each

9
713808 1000308419 B20 1" Vinyl Cap No Model Compatibility List $2.18 / Each

9
B 713810 1000308421 B16 HALF-ROUND RUBBER BUMPER No Model Compatibility List $16.41 / Each

1
Z 713814 1000308428 Z36 3/8" NUT No Model Compatibility List $1.43 / Each

2
Z 713818 1000308436 Z28 WASHER;FLT;USS;Diam.0.344XDiam.0.875X.06 No Model Compatibility List $1.43 / Each

2
Z 713819 1000308437 Z31 SCREW;HH;.375-16 x 1.50;ZN; No Model Compatibility List $2.37 / Each

2
713820 1000308438 Z33 SCREW;HH;.375-16 x 3.00;ZN; No Model Compatibility List $3.02 / Each

2
713821 1000308439 Z40 NUT;NLK;.375-16;ZN; No Model Compatibility List $1.43 / Each

2
713825 1000308443 Z37 SCREW;FH;.375-16 x 1.25;ZN; No Model Compatibility List $2.18 / Each

2
713832 1000308450 B53 1" Round Finishing Cap No Model Compatibility List $3.35 / Each

9
V 713842 1000308473 V53 Lable, hand pinch No Model Compatibility List $3.02 / Each

12,13,14
B 713937 1000309841 B13 2" X 3" END CAP No Model Compatibility List $7.28 / Each

9
713943 1000309851 Z34 SCREW;HH;.375-16 x 2.25;ZN; No Model Compatibility List $2.18 / Each

2
Z 713950 1000309858 Z27 3/4" FLAT WASHER No Model Compatibility List $1.33 / Each

2
713997 1000310096 Z44 1/4" SPLIT LOCK WASHER No Model Compatibility List $1.33 / Each

2
Z 714016 1000310219 Z45 SCREW;HH;.250-20 x 0.75;ZN; No Model Compatibility List $1.33 / Each

2
714017 1000310270 B10 1"OD x 5/8"ID NYLON PIPE - 3 1/2" No Model Compatibility List $21.94 / Each

1
714026 1000310302 B52 6" CABLE PULLEY w/ NARROW BUSHING No Model Compatibility List $36.48 / Each

8,4,5,6
B 714032 1000310308 B9 4" FOOT (LONG) No Model Compatibility List $18.23 / Each

9,3
Z 714033 1000310313 Z38 1/4" BLACK FLAT WASHER No Model Compatibility List $1.43 / Each

2,4,5,6
Z 714034 1000310314 Z39 BHSCS - 5 1/6-18 x 3/4" No Model Compatibility List $2.37 / Each

1
714037 1000310330 B46 FOOT; PLASTIC No Model Compatibility List $16.87 / Each

9,3
714038 1000310334 Weight Stack 1 6000 TOP PLATE No Model Compatibility List $78.47 / Each

3
B 714040 1000310339 B41 ROUND WEIGHT STACK BUMPER No Model Compatibility List $5.90 / Each

3,4,5,6
714041 1000310343 Weight Stack 2 Orange SELECTOR PIN w/ 6 1/2" CORD No Model Compatibility List $25.53 / Each

4,5,6,12,13,14
714079 1000311963 Z35 Screw;HH;.375-16x1.25;Zinc No Model Compatibility List $0.00 / Each
Out Of Stock 		2
714097 1000312070 Z32 SCREW;HH;.313-18 x 2.50;ZN; No Model Compatibility List $2.18 / Each

2
714098 1000312072 Z30 HHB 5/16-16 x 2 3/4" No Model Compatibility List $2.18 / Each

1
W 714118 1000312127 Weight Stack 4 BHS 5/16" - 1" No Model Compatibility List $5.46 / Each

1
714131 1000312171 Z25 1 9/16" Internal Snap Ring No Model Compatibility List $3.02 / Each

2
B 714153 1000312233 B51 3" ROUND END CAP No Model Compatibility List $6.73 / Each

9
714193 1000312342 V50 DECAL,WARNING: BOLT DOWN;English No Model Compatibility List $0.00 / Each
Out Of Stock 		7,2,3
714240 1000312817 Weight Stack 3 5/16" SPLIT LOCK WASHER No Model Compatibility List $1.33 / Each

2
714247 1000312877 B22 6000 Top Plastic No Model Compatibility List $170.66 / Each

9
714249 1000312880 Weight Stack 8 CAST IRON No Model Compatibility List $104.75 / Each

1
B 714349 1000313917 B17 1 1/4" ID - 20 1/2" Rubber Grip (9" With No Model Compatibility List $36.48 / Each

11
714451 1000314828 B42 5/8" GUIDE ROD - 58 1/2" No Model Compatibility List $0.00 / Each
Out Of Stock 		3
714465 1000315136 V52 6000 STACK DECALS, MEDIUM No Model Compatibility List $30.39 / Each

7,3,4,5,6
714514 1000315565 B14 INA 1" LINEAR SHAFT - 50" No Model Compatibility List $0.00 / Each
Out Of Stock 		3
B 714515 1000315566 B26 1" LINEAR SHAFT BEARING (Plastic)(Blue Housing) No Model Compatibility List $109.49 / Each

8,9,3
714516 1000315572 V54 6037 PLACARD;English No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6
714517 1000315573 V55 6037 PLACARD;English No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6
714538 1000315894 V51 DECAL MATRIX 11X1 - Black for Blue Moon, Iced Silver, Blood Red, White, Sunburst Orange, Fence Green, or Yellow frame No Model Compatibility List $6.73 / Each

7,3,4,5,6
715624 1000327214 AB7 WELDMENT FS937 SHAFT;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock 		3
715625 1000327215 AB7 WELDMENT FS937 SHAFT;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
715626 1000327216 AB7 WELDMENT FS937 SHAFT;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
715627 1000327235 V54 6037 PLACARD;French No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6
715628 1000327242 V55 6037 PLACARD;French No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6
716313 1000335318 B23 CLAMP - COVER No Model Compatibility List $0.00 / Each
Out Of Stock 		9,4,5,6
717443 1000345209 Z58 Screw;HH;.375-16x5.00;Zinc No Model Compatibility List $0.00 / Each
Out Of Stock 		2
717500 1000345600 B5 5/8# Single Split Collar No Model Compatibility List $10.92 / Each

1
717650 1000346601 B21 Stabilizer Foot;Black Ridge No Model Compatibility List $45.60 / Each

9,3,4,5,6
717779 1000347532 B11 4.5" Pulley for Rope / Cable No Model Compatibility List $18.56 / Each

8,4,5,6
718270 1000349780 AB3 Handle Assy;6037;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock 		11
718271 1000349781 AB3 Handle Assy;6037;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6,11
718272 1000349782 AB3 Handle Assy;6037;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6,11
719230 1000358061 Z59 Screw;Set;.250-20 x 0.3125 No Model Compatibility List $0.00 / Each
Out Of Stock 		2
719300 1000359440 B6 6000 ADD ON PLATE No Model Compatibility List $0.00 / Each
Out Of Stock 		3
719322 1000359722 Weight Stack 6 Cable Clip Top Half Assembly No Model Compatibility List $0.00 / Each
Out Of Stock 		2,3,4,5,6
719682 1000363760 V49 Warning Label;Frame;;;PC;;English; No Model Compatibility List $0.00 / Each
Out Of Stock 		3
719683 1000363766 V49 Warning Label;Frame;;;PC;;French;GM40 No Model Compatibility List $5.04 / Each

3
719801 1000365731 B47 ASSEMBLY; CABLE No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
719803 1000365773 B56 3/16" Plasma - 16.2 SQ IN No Model Compatibility List $0.00 / Each
Out Of Stock 		1
719807 1000365834 Weight Stack Set WEIGHT STACK 6000 CRIMP CABLE 150# No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
721552 1000384006 V48 Serial Number Label;4" x 1.5";3M; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
722025 1000387203 B24 6000 GUARD - 59 5/16";Charcoal No Model Compatibility List $0.00 / Each
Out Of Stock 		9,3
722152 1000388185 AB2 2037 SUB-ASSEMBLY;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock 		3
722153 1000388186 AB2 2037 SUB-ASSEMBLY;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
722154 1000388187 AB2 2037 SUB-ASSEMBLY;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
722155 1000388199 B15 DIAMOND PLATE;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
722156 1000388201 AB4 WELDMENT; SEAT FRAME;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock 		3,12,13,14
722157 1000388202 AB4 WELDMENT; SEAT FRAME;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6,12,13,14
722158 1000388203 AB4 WELDMENT; SEAT FRAME;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6,12,13,14
722159 1000388217 Weight Stack 7 WELDMENT; BAYONET No Model Compatibility List $0.00 / Each
Out Of Stock 		3
722160 1000388219 AB1 Main Frame;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock 		3
722161 1000388220 AB1 Main Frame;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
722162 1000388221 AB1 Main Frame;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
729261 See Pad Matrix J8 Elbow Pad;;PU;Black;;FW213-KM; No Model Compatibility List $0.00 / Each
Out Of Stock 		4,5,6,12,13,14
View Drawing
