Matrix Commercial - VY-D47-02 - 2013

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry used@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Plastic Parts
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
1000308428 713814 1000308428 Z15 3/8" NUT No Model Compatibility List $1.10 / Each

2
713820 1000308438 Z12 SCREW;HH;.375-16 x 3.00;ZN; No Model Compatibility List $2.32 / Each

2
1000308444 713826 1000308444 Z22 WASHER;FLT;USS;Diam.0.406XDiam.1.000X.06 No Model Compatibility List $1.10 / Each

2
713838 1000308466 B23 Flat Bumper - Weight Horn No Model Compatibility List $2.32 / Each

3
1000309773 713935 1000309773 Z1 Screw Set;M6x1.0Px5L;BP;POT No Model Compatibility List $2.52 / Each

2
1000309841 713937 1000309841 B17 2" X 3" END CAP No Model Compatibility List $5.60 / Each

9
1000309842 713938 1000309842 Spotter Stand 3 1 1/2" X 2" END CAP No Model Compatibility List $3.88 / Each

9
713976 1000310009 K2 CAP, END TUBE, 31.8MM No Model Compatibility List $5.60 / Each

9,3
713977 1000310010 K1 COLLAR, TUBE, 31.8MM No Model Compatibility List $11.68 / Each

3
1000310115 714008 1000310115 Z21 FHSCS 1/4"-20 X 1/2" No Model Compatibility List $1.02 / Each

1
1000310313 714033 1000310313 J Hook Z3 1/4" BLACK FLAT WASHER No Model Compatibility List $1.10 / Each

2,4,5,6
1000312084 714101 1000312084 Z13 3/8" x 4" BOLT No Model Compatibility List $2.32 / Each

2
714102 1000312086 Z14 SCREW;HH;.375-16 x 4.25;ZN; No Model Compatibility List $0.00 / Each
Out Of Stock
2
714103 1000312087 Spotter Stand 6 SCREW;HH;.375-16 x 4.50;ZN; No Model Compatibility List $0.00 / Each
Out Of Stock
2
1000312231 714152 1000312231 B18 1 1/2" Round End Cap No Model Compatibility List $1.68 / Each

9
714160 1000312247 K4 End cap - weight horn 2.5lbs No Model Compatibility List $3.88 / Each

9,3
714161 1000312249 K5 End cap - weight horn 5lbs No Model Compatibility List $3.88 / Each

9,3
714162 1000312250 K8 End cap - weight horn 10lbs No Model Compatibility List $3.88 / Each

9,3
714163 1000312253 K7 End cap - weight horn 25lbs No Model Compatibility List $3.88 / Each

9,3
714164 1000312254 K6 End cap - weight horn 45lbs No Model Compatibility List $3.88 / Each

9,3
1000312711 714236 1000312711 Z20 1/4" x 1/2" BUTTON HEAD No Model Compatibility List $1.12 / Each

1
1000313142 714279 1000313142 J Hook B8 1/4" ABS No Model Compatibility List $12.98 / Each

1
714280 1000313143 B16 1/4" ABS No Model Compatibility List $10.38 / Each

1
714283 1000313151 J Hook B7 1/4" ABS No Model Compatibility List $16.88 / Each

1
714284 1000313155 J Hook Z4 1/4"-20 UNC X 20 No Model Compatibility List $1.68 / Each

1
714285 1000313156 J Hook Z5 NUT;NLK;.250-20;BLACK;TALL; No Model Compatibility List $1.68 / Each

2,4,5,6
714286 1000313161 J Hook V10 LABEL, J-HOOK SELECTOR No Model Compatibility List $2.50 / Each

1
714310 1000313551 B32 2" TUBING EXTRUSION No Model Compatibility List $0.00 / Each
Out Of Stock
1
714323 1000313647 AB5 WELDMENT, LH POST No Model Compatibility List $0.00 / Each
Out Of Stock
3,12,13,14
714326 1000313658 AB9 WELDMENT, SAFETY BAR No Model Compatibility List $0.00 / Each
Out Of Stock
9,3
714327 1000313680 Spotter Stand 5 SCREW;HH;.375-16 x 5.50;ZN; No Model Compatibility List $3.88 / Each

2
714538 1000315894 V35 DECAL MATRIX 11X1 - Black for Blue Moon, Iced Silver, Blood Red, White, Sunburst Orange, Fence Green, or Yellow frame No Model Compatibility List $5.18 / Each

7,3,4,5,6
714644 1000316674 AB1 WELDMENT, REAR BASE;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
3
714645 1000316675 AB1 WELDMENT, REAR BASE;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
714646 1000316676 AB1 WELDMENT, REAR BASE;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
714647 1000316724 J Hook B6 ROUND KNOB-SPRING PIN ASSEMBLY No Model Compatibility List $0.00 / Each
Out Of Stock
2,3,12,13,14
1000318109 714766 1000318109 Kit 1 HAND GRIP 1.25 DIA 0-12"LONG No Model Compatibility List $37.68 / Each

11
714771 1000318165 Kit 2 WEIGHT HORN SET No Model Compatibility List $14.28 / Each

3
715247 1000321527 AB8 WELDMENT, SUPPORT;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
3
715248 1000321528 AB8 WELDMENT, SUPPORT;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
715249 1000321529 AB8 WELDMENT, SUPPORT;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
717231 1000343278 Spotter Kit L Spotter Stand Set;Left;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
717232 1000343279 Spotter Kit R Spotter Stand Set;Right;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
717314 1000343845 AB10 Chin Up Bar;Assy;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
1
717321 1000344035 AB10 Chin Up Bar;Assy;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
717322 1000344036 AB10 Chin Up Bar;Assy;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
717323 1000344063 B19 End Cap;Plastic;3" x 3"; No Model Compatibility List $5.18 / Each

9
717377 1000344562 V35 Decal;Matrix;Grey for Black Matte, Black Ridge, Black Glossy, Moss Green, or Blue Streak frame No Model Compatibility List $11.68 / Each

7,3,4,5,6
717444 1000345210 B34 7/16" HOLE PLUG; NYLON No Model Compatibility List $1.02 / Each

1
717584 1000346104 AB11 Support Assy;A47;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
3
717585 1000346105 AB11 Support Assy;A47;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
717586 1000346106 AB11 Support Assy;A47;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
717914 1000348617 V37 Decal, D47 lower No Model Compatibility List $0.00 / Each
Out Of Stock
7,3
717915 1000348618 V36 Decal, Varsity PR No Model Compatibility List $0.00 / Each
Out Of Stock
7,3
717931 1000348681 J Hook B11 1" Grip;3.25" Long;Closed End No Model Compatibility List $0.00 / Each
Out Of Stock
9,11
718749 1000353136 K3 1.25" Grip;Order by 1" increments; No Model Compatibility List $0.00 / Each
Out Of Stock
11
719680 1000363753 V34 Warning Label;Plate Loaded; No Model Compatibility List $0.00 / Each
Out Of Stock
3
719681 1000363756 V34 Warning Label;Plate Loaded;French No Model Compatibility List $0.00 / Each
Out Of Stock
3
720288 1000371121 AB4 WELDMENT, RH POST;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6,12,13,14
720934 1000378566 AB2 WELDMENT, LH BASE;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
3
720935 1000378567 AB2 WELDMENT, LH BASE;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720936 1000378568 AB2 WELDMENT, LH BASE;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720937 1000378581 AB3 WELDMENT, RH BASE;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
3
720938 1000378582 AB3 WELDMENT, RH BASE;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720939 1000378583 AB3 WELDMENT, RH BASE;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720942 1000378600 AB6 WELDMENT, LH WEIGHT STORAGE;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
3
720943 1000378601 AB6 WELDMENT, LH WEIGHT STORAGE;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720944 1000378602 AB6 WELDMENT, LH WEIGHT STORAGE;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720945 1000378615 AB7 WELDMENT, RH WEIGHT STORAGE;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock
3
720946 1000378616 AB7 WELDMENT, RH WEIGHT STORAGE;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720947 1000378617 AB7 WELDMENT, RH WEIGHT STORAGE;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock
3,4,5,6
720948 1000378629 J Hook Set L J Hook Set;Left;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
720949 1000378630 J Hook Set R J Hook Set;Right;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock
4,5,6
721552 1000384006 V33 Serial Number Label;4" x 1.5";3M; No Model Compatibility List $0.00 / Each
Out Of Stock
1
722596 1000395247 J Hook B2 HDPE Insert;J Hook No Model Compatibility List $0.00 / Each
Out Of Stock
1
729008 Order J Hook Set J Hook AB1 Weldment;J Hook No Model Compatibility List $0.00 / Each
Out Of Stock
3
729066 Order Spotter Stand Set Spotter Stand 2 Weldment;Spotter Stand No Model Compatibility List $0.00 / Each
Out Of Stock
3
