Matrix Commercial - VY-D847-02 - 2013

Repair Parts for Matrix Commercial VY-D847-02 VYTS24

Brand: Matrix Commercial

Category: Multi Station

Type: Strength Systems

Model Name: VY-D847-02

Version: 2013

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Seats
  • Posts
  • Pins
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
B 713806 1000308417 B10 2" x 2" END CAP No Model Compatibility List $5.46 / Each

9
Z 713814 1000308428 Z11 3/8" NUT No Model Compatibility List $1.43 / Each

2
Z 713826 1000308444 Z18 WASHER;FLT;USS;Diam.0.406XDiam.1.000X.06 No Model Compatibility List $1.43 / Each

2
B 713834 1000308452 B31 7" RUBBER FOOT No Model Compatibility List $14.59 / Each

9,3
713841 1000308472 V23 Lable, Olympic Bench No Model Compatibility List $6.73 / Each

1
V 713842 1000308473 V30 Lable, hand pinch No Model Compatibility List $3.02 / Each

12,13,14
S 713939 1000309846 Single Pulley 7 1/2" JAM NUT No Model Compatibility List $1.43 / Each

2
S 713940 1000309847 Single Pull 11 WASHER, .50 OD X .38 ID X .05 No Model Compatibility List $1.43 / Each

2
713943 1000309851 Z15 SCREW;HH;.375-16 x 2.25;ZN; No Model Compatibility List $2.18 / Each

2
S 713946 1000309854 Single Pulley 5 NUT;NLK;.250-20;ZN; No Model Compatibility List $1.43 / Each

2
S 713950 1000309858 Single Pull 10 3/4" FLAT WASHER No Model Compatibility List $1.33 / Each

2
713984 1000310019 Single Pulley 4 SCREW;HH;.500-13 x 2.00;ZN; No Model Compatibility List $3.02 / Each

2
713997 1000310096 Single Pulley 9 1/4" SPLIT LOCK WASHER No Model Compatibility List $1.33 / Each

2
714017 1000310270 B8 1"OD x 5/8"ID NYLON PIPE - 3 1/2" No Model Compatibility List $21.94 / Each

1
Z 714031 1000310307 Z13 SCREW;HH;.375-16 x 1.00;ZN;SAE 5 No Model Compatibility List $2.37 / Each

2
714038 1000310334 Weight Stack 1 6000 TOP PLATE No Model Compatibility List $78.47 / Each

3
B 714040 1000310339 B26 ROUND WEIGHT STACK BUMPER No Model Compatibility List $5.90 / Each

3,4,5,6
714041 1000310343 Weight Stack 2 Orange SELECTOR PIN w/ 6 1/2" CORD No Model Compatibility List $25.53 / Each

4,5,6,12,13,14
714107 1000312095 Z14 SCREW;HH;.500-13 x 3.25;ZN; No Model Compatibility List $5.04 / Each

2
W 714118 1000312127 Weight Stack 4 BHS 5/16" - 1" No Model Compatibility List $5.46 / Each

1
714126 1000312159 Single Pulley 8 1/2 - 13 NUT No Model Compatibility List $1.33 / Each

2
Z 714127 1000312161 Z12 NUT;NLK;.500-13;ZN;TALL; No Model Compatibility List $1.43 / Each

2
S 714189 1000312326 Single Pull 12 4" CABLE PULLEY - 3/8" HOLE No Model Compatibility List $27.01 / Each

8,4,5,6
714193 1000312342 V20 DECAL,WARNING: BOLT DOWN;English No Model Compatibility List $0.00 / Each
Out Of Stock 		7,2,3
B 714205 1000312386 B3 DUMBBELL CRADLE No Model Compatibility List $14.59 / Each

1
Z 714235 1000312700 Z17 7/16" FLAT WASHER No Model Compatibility List $2.44 / Each

2
714240 1000312817 Weight Stack 3 5/16" SPLIT LOCK WASHER No Model Compatibility List $1.33 / Each

2
714246 1000312876 Single Pulley 3 SCREW;HH;.375-16 x 3.25;ZN; No Model Compatibility List $3.74 / Each

2
714249 1000312880 Weight Stack 8 CAST IRON No Model Compatibility List $104.75 / Each

1
714253 1000312893 B9 3/8" SAFETY CLIP No Model Compatibility List $16.82 / Each

2,9
714333 1000313747 B25 5/8" CRR - 81 1/2" No Model Compatibility List $0.00 / Each
Out Of Stock 		1
B 714344 1000313871 B6 TRICEP ROPE (MA-TA) No Model Compatibility List $213.54 / Each

1
714350 1000313928 B7 CABLE, D847 No Model Compatibility List $317.69 / Each

4,5,6
714465 1000315136 V24 6000 STACK DECALS, MEDIUM No Model Compatibility List $30.39 / Each

7,3,4,5,6
714538 1000315894 V21 DECAL MATRIX 11X1 - Black for Blue Moon, Iced Silver, Blood Red, White, Sunburst Orange, Fence Green, or Yellow frame No Model Compatibility List $6.73 / Each

7,3,4,5,6
714592 1000316304 V23 DECAL OLY BENCH;French No Model Compatibility List $8.42 / Each

7,3
714915 1000319630 V20 DECAL,WARNING: BOLT DOWN;French No Model Compatibility List $0.00 / Each
Out Of Stock 		7,2,3
715260 1000321753 B4 Revolving Curl Bar No Model Compatibility List $0.00 / Each
Out Of Stock 		1
716246 1000334840 AB1 WELDMENT D847;Iced Silver No Model Compatibility List $0.00 / Each
Out Of Stock 		3
716247 1000334841 AB1 WELDMENT D847;Black Glossy No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
716248 1000334842 AB1 WELDMENT D847;Lace White No Model Compatibility List $0.00 / Each
Out Of Stock 		3,4,5,6
717156 1000342316 B32 Rubber Stopper;Cable Ball;Drilled 3/8" f No Model Compatibility List $23.71 / Each

4,5,6
717377 1000344562 V21 Decal;Matrix;Grey for Black Matte, Black Ridge, Black Glossy, Moss Green, or Blue Streak frame No Model Compatibility List $15.18 / Each

7,3,4,5,6
717500 1000345600 B2 5/8# Single Split Collar No Model Compatibility List $10.92 / Each

1
717779 1000347532 B5 4.5" Pulley for Rope / Cable No Model Compatibility List $18.56 / Each

8,4,5,6
719322 1000359722 Weight Stack 6 Cable Clip Top Half Assembly No Model Compatibility List $0.00 / Each
Out Of Stock 		2,3,4,5,6
719753 1000365174 B33 D Ring;Purchased; No Model Compatibility List $13.49 / Each

1
721552 1000384006 V22 Serial Number Label;4" x 1.5";3M; No Model Compatibility List $0.00 / Each
Out Of Stock 		1
721920 1000386596 Single Pull Set WEIGHT STACK PULLEY ASSEMBLY No Model Compatibility List $217.98 / Each

8,3,4,5,6
721921 1000386597 Single Pulley 2 HCS 1/4"-20 x 3.00" Zinc No Model Compatibility List $0.00 / Each
Out Of Stock 		1
723268 1000406013 Single Pulley 1 Weldment; Head Plate Pulley;Black Ridge No Model Compatibility List $0.00 / Each
Out Of Stock 		8,3,4,5,6
723623 1000410570 Weight Stack 7 CENTER STICK WELDMENT (D847) No Model Compatibility List $0.00 / Each
Out Of Stock 		3
723624 1000410571 Weight Stack Set WEIGHT STACK 18+1 w/o PULLEY No Model Compatibility List $0.00 / Each
Out Of Stock 		8,3,4,5,6
View Drawing
