NordicTrack® - C2200

Brand: NordicTrack®

Category: Residential Treadmills

Type: Folding Treadmill

Model Number:

Info

Model Numbers are Unique Identifiers, they are important because they lead you to access diagrams and part lists specific to the version of a given model equipment you own. Bottom line, they help you get the right part. Note: Sometimes we put a serial prefix in this field to elicit versioning, and if this field is blank that means the model name alone will suffice for part selection.

831.306001

Model Name: C2200

Exploded Diagrams

Other Languages Available

Image	Catalog #	MPN	Part List Key	Quantity On Model	Part Description	Notes	Available Used	Model Compatibility List	New price

Image	Catalog #	MPN	Part List Key	Quantity On Model	Part Description	Notes	Available Used	Model Compatibility List	New price
	013288	265269	0	1	Screw M4 X 64MM		No	Model Compatibility List	$12.99 / Each	1
	1004202	014174	0	1	M8 Split Washer		No	Model Compatibility List	$11.99 / Each	1
	1004210	249928	0	1	M8 X 20MM Button Screw		No	Model Compatibility List	$11.99 / Each	1
	1004394	013322	0	1	#8 X 3/4" Foot Pedal Screw		No	Model Compatibility List	$5.99 / Each	1
	1004489	170205	0	1	Speed Sensor		Yes	Model Compatibility List	$21.99 / Each	47
	1009452	113842	0	1	Magnet		Yes	Model Compatibility List	$11.99 / Each	1
	1011536	153209	0	1	Crank Arm Endcap		Yes	Model Compatibility List	$14.99 / Each	1
	1011564	241949	0	1	Tension Brake Resistance Motor		Yes	Model Compatibility List	$82.99 / Each	28
	1011566	242356	0	1	Screw 8 X 13mm		Yes	Model Compatibility List	$11.99 / Each	1
	1011772	012042	0	1	M8 Locknut		Yes	Model Compatibility List	$11.99 / Each	1
	1011778	013162	0	1	Clamp Screw		Yes	Model Compatibility List	$11.99 / Each	1
	1011798	131090	0	1	Reed Switch Cable Retainer Clamp		Yes	Model Compatibility List	$14.99 / Each	19
	1011867	251830	0	1	Bolt M8 X 38MM		Yes	Model Compatibility List	$15.99 / Each	1

View Drawing
