NordicTrack®

Brand: NordicTrack®

Category: Residential Treadmills

Type: Folding Treadmill

Model Number: NTL221160

Model Name:

Owners Manual:

Exploded Diagrams

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry used@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Motors
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Belt Related
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
100427 100139 100427 9 5/16" NUT No Model Compatibility List $1.42 / Each

102457 100553 34 1/2" NUT No Model Compatibility List $0.90 / Each

101896 101061 101896 TS14 4" WHITE WIRE, M/F No Model Compatibility List $4.44 / Each

102973 109942 102973 124 3/8 No Model Compatibility List $4.63 / Each

101849 104794 77 CARRIAGE CAP No Model Compatibility List $1.14 / Each

106008 112125 49 38MM SQUARE INT ENDCAP No Model Compatibility List $1.17 / Each

114078 102521 114078 67 INCLINE MTR SPACER No Model Compatibility List $1.67 / Each

100814 115366 132 TRANSPORT HANDLE ENDCAP No Model Compatibility List $0.50 / Each

100186 116566 # 15 1/2" CABLE TIE No Model Compatibility List $0.69 / Each

119425 100031 119425 35 3/8" HEX JAM NUT No Model Compatibility List $1.50 / Each

101666 12002 99 M8 NYLON LOCKNUT No Model Compatibility List $0.42 / Each

012033 102045 012033 52 M10 NYLON LOCKNUT No Model Compatibility List $2.02 / Each

106584 120696 # FRAME CROSSBAR ENDCAP No Model Compatibility List $3.03 / Each

104626 120733 66 25MM ROUND INNER CAP No Model Compatibility List $1.48 / Each

122940 121503 43 M8 X 64MM BOLT No Model Compatibility List $5.05 / Each

121576 100424 121576 30 SPRING NUT No Model Compatibility List $0.31 / Each

113812 123396 28 25MM ROUND ANGLED CAP No Model Compatibility List $1.52 / Each

128263 102450 128263 17 #8 X 1 3/4" SCREW No Model Compatibility List $2.31 / Each

105930 129144 47 CABLE PULLEY WASHER No Model Compatibility List $2.45 / Each

119570 13043 68 SEAT KNOB BOLT No Model Compatibility List $5.46 / Each

132239 13105 61 M8 X 48MM BOLT No Model Compatibility List $2.63 / Each

137562 13128 7 SCREW No Model Compatibility List $1.35 / Each

131483 100360 131483 118 LATCH BOLT No Model Compatibility List $2.66 / Each

147362 132095 62 M10 X 60MM BOLT No Model Compatibility List $5.66 / Each

100073 132315 107 WIRE TIE No Model Compatibility List $0.51 / Each

013300 100149 013300 32 #8 X 3/4" WASHER HD SCREW No Model Compatibility List $1.16 / Each

133333 100032 133333 36 #8 HOOD CLIP No Model Compatibility List $0.59 / Each

101656 13509 29 SCREW, NOTE: No Model Compatibility List $0.15 / Each

135575 100664 135575 84 M6 X 38MM BOLT No Model Compatibility List $6.05 / Each

116773 135884 62 M6 X 16MM SCREW No Model Compatibility List $1.21 / Each

013607 100132 013607 14A #8 X 3/4" TRUSS HEAD SCRW No Model Compatibility List $0.20 / Each

136728 100137 136728 18 #8 X 1/2" SCREW No Model Compatibility List $0.27 / Each

162196 140239 23 FOAM PAD, 5 3/4" No Model Compatibility List $18.90 / Each

102276 14041 99 IDLER ARM WASHER No Model Compatibility List $0.11 / Each

014127 104040 014127 # 1/4" WASHER No Model Compatibility List $1.09 / Each

014149 100449 014149 67 5/16" STAR WASHER No Model Compatibility List $0.18 / Each

014157 100141 014157 22 #8 STAR WASHER No Model Compatibility List $1.06 / Each

100097 146119 # FLOOR MAT 36" X 72" No Model Compatibility List $39.00 / Each

104532 150842 # WARNING DECAL, BLACK No Model Compatibility List $2.51 / Each

152478 100695 152478 31 M8 X 25MM WASHER No Model Compatibility List $0.68 / Each

100301 158013 # FELT PAD No Model Compatibility List $0.68 / Each

159986 100347 159986 15 TOP LIFT MOTOR BOLT No Model Compatibility List $6.39 / Each

016057 100063 016057 65 8" CABLE TIE No Model Compatibility List $1.18 / Each

163045 100123 163045 25 3/8" STAR WASHER Part # 3 On Drawing No Model Compatibility List $1.18 / Each

100602 166909 # PAD FRAME WARNING DECAL No Model Compatibility List $1.67 / Each

100128 167049 6 #10 X 3/4" SCREW No Model Compatibility List $0.29 / Each

111528 169660 21 1/4" X 1 1/4" SCREW No Model Compatibility List $1.25 / Each

173169 100061 173169 70 GROMMET No Model Compatibility List $0.85 / Each

168917 175966 3 RIGHT CROSSBAR No Model Compatibility List $97.96 / Each

168916 176937 2 LEFT CROSSBAR No Model Compatibility List $111.06 / Each

164096 176950 38 WEIGHT TUBE BRACKET No Model Compatibility List $19.52 / Each

164097 176954 CN-WT TUBE BKT/WSHRS No Model Compatibility List $0.00 / Each
Out Of Stock
109927 181979 20 3/8" X 1 1/4" SCREW No Model Compatibility List $2.15 / Each

183246 102957 183246 33 1/4 No Model Compatibility List $1.04 / Each

168918 185256 30 SLEEVE No Model Compatibility List $3.97 / Each

186253 109966 186253 105 CONSOLE FRAME CAP Yes Model Compatibility List $5.31 / Each

186726 100201 186726 71 POWER SWITCH Yes Model Compatibility List $18.59 / Each

186819 100120 186819 13 #8 X 1/2" SCREW No Model Compatibility List $0.38 / Each

189813 100113 189813 TS15 FILTER W/6" WIRE No Model Compatibility List $21.68 / Each

198639 100147 198639 43 BELT GUIDE Yes Model Compatibility List $9.99 / Each

203283 101667 203283 2 5/16"X 2" BTN SCRW, NOTE: No Model Compatibility List $3.88 / Each

102975 209460 # HEX KEY No Model Compatibility List $5.27 / Each

211260 100163 211260 TS6 INCLINE MOTOR WIRE HRNS 12" No Model Compatibility List $14.43 / Each

100212 214773 TS4 6" GRN WIRE F/R, PWR GRND No Model Compatibility List $2.06 / Each

215822 100187 215822 125 4 No Model Compatibility List $4.90 / Each

215823 100197 215823 # AUDIO WIRE,18" Yes Model Compatibility List $8.06 / Each

217913 105949 217913 111 1/4 No Model Compatibility List $2.08 / Each

219168 100095 219168 # 1 TUBE LUBE KIT No Model Compatibility List $6.19 / Each

219170 100096 219170 # 3 TUBE LUBE KIT No Model Compatibility List $27.62 / Each

168920 220768 # USER'S MANUAL No Model Compatibility List $3.64 / Each

223662 109952 223662 59 IDLER ROLLER Yes Model Compatibility List $139.52 / Each

100182 227199 86 UPRIGHT GROMMET No Model Compatibility List $1.41 / Each

100227 230979 68 HOOD MOUNT No Model Compatibility List $3.49 / Each

100185 240351 53 ANCHORED CABLE TIE No Model Compatibility List $0.67 / Each

100178 252433 85 WARNING DECAL No Model Compatibility List $0.43 / Each

111344 269380 16 5/16"X1 1/4"PTCH BLT,NOTE No Model Compatibility List $1.76 / Each

111469 269381 127 1/4X 1/2" ISO HANDLE SCRW No Model Compatibility List $1.08 / Each

105684 271382 7 5/16" X 1 1/2" SCREW No Model Compatibility List $1.81 / Each

286707 100162 286707 # INCLINE MOTOR SENSOR KIT No Model Compatibility List $45.57 / Each

291486 100133 291486 128 #8X5/8" DECKRAIL SCREW No Model Compatibility List $1.25 / Each

109922 295136 1 5/16" X 3/4" SCREW No Model Compatibility List $1.04 / Each

102452 295758 19 5/16" MOTOR SCREW No Model Compatibility List $1.67 / Each

102459 298474 27 RUBBER GROMMET No Model Compatibility List $1.38 / Each

298484 102454 298484 3 5/16" BOLT,FLASH TM11-200 No Model Compatibility List $1.46 / Each

298898 112032 298898 104 KEY/CLIP Yes Model Compatibility List $19.81 / Each

301345 102503 301345 122 BASE PAD No Model Compatibility List $1.99 / Each

100037 305284 38 LATCH WARNING DECAL No Model Compatibility List $1.36 / Each

102523 305750 # 3/16" ALLEN WRENCH No Model Compatibility List $20.75 / Each

311589 102969 311589 55 MOTOR BELT No Model Compatibility List $34.68 / Each

104822 312455 78 CONSOLE FAN No Model Compatibility List $112.30 / Each

110137 316650 99 8" CABLE TIE, 50# No Model Compatibility List $0.35 / Each

319487 102462 319487 87 ISOLATOR SPRING No Model Compatibility List $13.21 / Each

328330 102471 328330 54 DRIVE MOTOR Yes Model Compatibility List $475.56 / Each

329452 111504 329452 114 CUSHION BUSHING No Model Compatibility List $7.60 / Each

329503 111507 329503 117 CUSHION WHEEL Yes Model Compatibility List $12.37 / Each

102525 331708 # CONSOLE BACK BUMPON No Model Compatibility List $0.42 / Each

109929 341769 23 3/8" X 2 3/4" SCREW No Model Compatibility List $4.38 / Each

346519 109924 346519 14 3/8" X 1 1/2" BOLT No Model Compatibility List $3.71 / Each

349213 109923 349213 4 5/16" X 2 1/4" BOLT No Model Compatibility List $2.89 / Each

351453 111506 351453 116 CUSHION ROD Yes Model Compatibility List $105.97 / Each

126890 351467 76 UPRIGHT CROSSBAR No Model Compatibility List $41.45 / Each

127149 351686 79 TRAY No Model Compatibility List $35.77 / Each

351689 111501 351689 112A ADJUSTMENT HANDLE No Model Compatibility List $46.24 / Each

351691 111503 351691 113 HANDLE CAP No Model Compatibility List $4.87 / Each

112047 351693 72 BELLY PAN No Model Compatibility List $65.68 / Each

351698 127150 351698 88 LEFT REAR CAP Yes Model Compatibility List $14.31 / Each

351958 111502 351958 112B ADJUSTMENT HANDLE INSERT No Model Compatibility List $1.09 / Each

352008 111094 352008 66 INCLINE MOTOR Yes Model Compatibility List $127.05 / Each

352010 126883 352010 40 WALKING BELT Yes Model Compatibility List $170.85 / Each

352011 109946 352011 51 DRIVE ROLLER/PULLEY Yes Model Compatibility List $120.48 / Each

353163 127145 353163 42 RIGHT FOOT RAIL Yes Model Compatibility List $59.99 / Each

353164 127144 353164 41 LEFT FOOT RAIL Yes Model Compatibility List $59.99 / Each

353269 127148 353269 62 MOTOR HOOD No Model Compatibility List $97.25 / Each

109983 353430 108 SPEAKER No Model Compatibility List $26.86 / Each

111534 355174 102 FOOT RAIL PLATE No Model Compatibility List $1.66 / Each

111547 355175 98 FOOT RAIL CLIP No Model Compatibility List $1.43 / Each

100094 356520 # ACCESSORY KIT No Model Compatibility List $38.99 / Each

109963 357773 74 HANDRAIL No Model Compatibility List $36.92 / Each

111434 358504 126 TRAY FAN COVER No Model Compatibility List $17.48 / Each

358779 109953 358779 60 LEFT REAR CAP Yes Model Compatibility List $19.70 / Each

358780 109954 358780 61 RIGHT REAR CAP No Model Compatibility List $19.70 / Each

109974 360378 119 CONTROLLER CLAMP No Model Compatibility List $2.39 / Each

127217 360585 95 FAN No Model Compatibility List $30.06 / Each

360938 111533 360938 58 CUSHION PLATE Yes Model Compatibility List $5.76 / Each

111531 360940 97 CUSHION WHEEL STOP No Model Compatibility List $3.16 / Each

360945 111529 360945 37 CUSHION No Model Compatibility List $17.50 / Each

109945 361845 50 CONTROLLER BRACKET No Model Compatibility List $18.09 / Each

111470 362730 39 WALKING PLATFORM No Model Compatibility List $177.23 / Each

364027 102396 364027 12 1/4" X 2 1/2" BOLT No Model Compatibility List $1.83 / Each

364361 103644 364361 109 CHEST HEART RATE MONITOR No Model Compatibility List $115.05 / Each

111540 370562 115 CUSHION ROD BRACKET No Model Compatibility List $35.12 / Each

109931 372033 28 3/8" X 1" SCREW No Model Compatibility List $3.70 / Each

109941 372092 45 3/8" BUSHING No Model Compatibility List $3.16 / Each

109956 372106 63 INCLINE FRAME SPACER No Model Compatibility List $1.54 / Each

109957 372107 64 FRAME SPACER No Model Compatibility List $2.01 / Each

109982 372108 46 1/2" BUSHING No Model Compatibility List $2.24 / Each

109930 372109 26 1/2" X 2.25" BOLT, NOTE: No Model Compatibility List $2.57 / Each

109958 372310 65 INCLINE FRAME No Model Compatibility List $65.78 / Each

127155 374043 TS7 30 FAN HRNS No Model Compatibility List $17.11 / Each

127153 374117 103 RIGHT REAR CAP No Model Compatibility List $5.20 / Each

127712 374389 44 LEFT FRAME COVER No Model Compatibility List $50.99 / Each

127714 374390 57 RIGHT FRAME COVER No Model Compatibility List $50.99 / Each

111523 378826 123 FLEX CUSHION WASHER No Model Compatibility List $0.22 / Each

109928 381122 22 3/8" X 1 3/4" BOLT No Model Compatibility List $1.98 / Each

109978 382172 92 REAR WHEEL No Model Compatibility List $4.85 / Each

109967 382237 93 BASE No Model Compatibility List $350.66 / Each

109976 382318 90 RIGHT UPRIGHT COVER No Model Compatibility List $73.55 / Each

109975 382319 89 LEFT UPRIGHT COVER No Model Compatibility List $73.55 / Each

383788 111132 383788 83 UPRIGHT WIRE No Model Compatibility List $59.26 / Each

127210 385210 80 PULSE CROSSBAR No Model Compatibility List $101.11 / Each

127212 385211 82 RIGHT HANDRAIL BOTTOM CVR No Model Compatibility List $15.77 / Each

127211 385212 81 RIGHT HANDRAIL TOP COVER No Model Compatibility List $18.28 / Each

127643 385213 32 1/4" X 5/8" SCREW No Model Compatibility List $56.58 / Each

127208 385214 73 LEFT HANDRAIL TOP COVER No Model Compatibility List $18.28 / Each

127209 385215 75 LEFT HANDRAIL BOTTOM CVR No Model Compatibility List $15.77 / Each

127216 385326 94 LEFT TRAY No Model Compatibility List $21.47 / Each

385327 127222 385327 101 RIGHT TRAY No Model Compatibility List $24.47 / Each

385328 127221 385328 100 CONSOLE BASE No Model Compatibility List $123.06 / Each

136582 385886 91 LEFT UPRIGHT No Model Compatibility List $190.02 / Each

136581 385887 84 RIGHT UPRIGHT No Model Compatibility List $190.02 / Each

136585 386930 121 LATCH CROSSBAR No Model Compatibility List $61.18 / Each

127641 387423 106 CONSOLE FRAME No Model Compatibility List $94.85 / Each

138045 387622 # LITPAC, NOTE: No Model Compatibility List $171.71 / Each

138044 387623 # USER'S MANUAL No Model Compatibility List $16.03 / Each

138046 387624 # HARDWARE KIT, NOTE: No Model Compatibility List $83.45 / Each

387652 138042 387652 96A CONSOLE (ROYAL WOLF) No Model Compatibility List $999.00 / Each

388199 109949 388199 56 STORAGE LATCH Yes Model Compatibility List $96.90 / Each

138043 390530 96B CNSL REPROG THUMB DRIVE No Model Compatibility List $86.55 / Each

399623 138041 399623 48 CONTROLLER No Model Compatibility List $203.78 / Each

401248 1015239 401248 # 1 CONSOLE ETNT22116V1 No Model Compatibility List $1399.00 / Each
