Octane Fitness - Pro3700 Standard Base

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry used@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Motors
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Belt Related
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
100321-001 600022 100321-001 MAIN FRAME COMPONENTS BRACKET, TOP, CONTROL BOX No Model Compatibility List $13.75 / Each

7,2,3,4,5,6
100396-001 600035 100396-001 CONSOLE MAST GRIP, STATIONARY, DIPPED No Model Compatibility List $3.75 / Each

11
100411-001 600044 100411-001 MAIN FRAME COMPONENTS AXLE, TRANSPORT WHEEL No Model Compatibility List $4.68 / Each

8
100414-001 600045 100414-001 CONSOLE MAST COVER, CONSOLE BACK No Model Compatibility List $11.88 / Each

7,9,4,5,6
100416-001 600047 100416-001 CONSOLE MAST INSERT, BOTTLE HOLDER No Model Compatibility List $25.00 / Each

9
100429-001 600049 100429-001 LOWER FRAME COMPONENTS SCREW, M4.8 X 1.6 X 13 TYPE AB, TYPE 1 CROSS RECESS PAN HEAD, ST, BZ No Model Compatibility List $4.68 / Each

2
100457-001 600054 100457-001 #22-ASSY SPACER, FLANGE TENSIONER No Model Compatibility List $4.68 / Each

2,3,4,5,6
100464-001 600057 100464-001 FAN MAGNET, RPM PULLEY No Model Compatibility List $4.68 / Each

8
100554-001 600070 100554-001 LOWER FRAME COMPONENTS SCREW, M5 X 0.8 X 12, PAN HEAD, TYPE 1 CROSS RECESSED, BZ No Model Compatibility List $4.68 / Each

2
100602-001 600074 100602-001 TOUCH SCREEN MAST SCREW, M5 X 0.8 X 10, PAN HEAD, TYPE 1, No Model Compatibility List $4.68 / Each

2
100700-001 600082 100700-001 MAIN FRAME COMPONENTS SCREW, M12x1.75x20L SHCS, STL, BZ No Model Compatibility List $4.68 / Each

2
100715-001 600085 100715-001 BOLT, M10 X 1.5 X 55, HEX HEAD, 12.9 STL, CZ No Model Compatibility List $2.50 / Each

2
100716-001 600086 100716-001 BRACED PEDAL LEVER BOLT, M10 X 1.5 X 20, HEX HEAD, GR 8.8, CZ No Model Compatibility List $4.68 / Each

2
100717-001 600087 100717-001 MULTI-AXIS BEARING LINK WASHER, 10 X 23 X 2, STEEL, CZ No Model Compatibility List $4.68 / Each

2
100760-001 600109 100760-001 CONSOLE MAST TERMINAL, EYELET TO QUICK DISCONNECT No Model Compatibility List $4.68 / Each

4,5,6
100822-001 600129 100822-001 BELT, DRIVE, 10 RIB, 580J Yes Model Compatibility List $67.50 / Each

10,15
100828-001 600130 100828-001 REAR TRACK COVER DUAL LOCK, 20.6MM DIA - 250 No Model Compatibility List $3.75 / Each

1
100830-001 600131 100830-001 LOWER FRAME COMPONENTS BRAKE, GENERATOR, 6302 Yes Model Compatibility List $562.50 / Each

8
100873-001 600155 100873-001 MAIN FRAME COMPONENTS SCREW, M5 X 0.8 X 8, TRUSS HEAD, TYPE II CROSS RECESSED, BZ No Model Compatibility List $4.68 / Each

2
100882-001 600158 100882-001 CONSOLE MAST DECAL, LARGE OCTANE No Model Compatibility List $5.00 / Each

7,3
100890-001 600161 100890-001 CONSOLE MAST CABLE ASSEMBLY, FEMALE SPADE - 5MM EYELET No Model Compatibility List $4.68 / Each

3,4,5,6,12,13,14
100896-001 600164 100896-001 CONSOLE MAST CABLE ASSEMBLY, KEYPAD-CONSOLE No Model Compatibility List $35.00 / Each

7,9,3,4,5,6,12,13,14
100913-001 600171 100913-001 FAN SCREW, M3.5 X 1.3 X 10 TYPE B, TYPE 1 CROSS RECESS PAN HEAD, ST, BZ No Model Compatibility List $4.68 / Each

2
100924-001 600179 100924-001 BAGGED HARDWARE WRENCH, HEX, M6 No Model Compatibility List $4.68 / Each

2
101013-001 600211 101013-001 CONSOLE MAST SCREW, M5 X 0.8 X 6, PAN HEAD, TYPE 1 CROSS RECESSED, CZ No Model Compatibility List $4.68 / Each

2
101014-001 600212 101014-001 LOWER FRAME COMPONENTS WASHER, M5, EXTERNAL TOOTH, STEEL, CZ No Model Compatibility List $4.68 / Each

2
101017-001 600213 101017-001 MAIN FRAME COMPONENTS BOLT, M6 X 1.0 X 20, HEX HEAD, GR 8.8, CZ No Model Compatibility List $4.68 / Each

2
101039-001 600226 101039-001 CONSOLE MAST DECAL, SMALL OCTANE No Model Compatibility List $3.75 / Each

7,3
101041-001 600228 101041-001 ACCESS PANEL DECAL, MEDIUM OCTANE No Model Compatibility List $7.50 / Each

7,3
101245-001 600261 101245-001 HOOD SHROUD DECAL, 80 DIA BUG No Model Compatibility List $4.38 / Each

7,3
101295-001 600268 101295-001 #16-ASSY SCREW, M8 X 1.25 X 20.0L SHCS, BLACK ZINC, 12.9 STL No Model Compatibility List $4.68 / Each

2,4,5,6
101296-001 600269 101296-001 #7-ASSEMBLY SCREW, M8 X 1.25 X 45.0L SHCS, BLACK ZIN, 12.9 STL No Model Compatibility List $4.68 / Each

2,4,5,6
101297-001 600270 101297-001 PRO310 SCREW, M5 X 0.8 X 16.0L SHCS, BLACK ZINC, 12.9 STL, SPRING WASHER No Model Compatibility List $4.68 / Each

2,4,5,6
101298-001 600271 101298-001 #8-ASSEMBLY SCREW, M5 X 0.8 X 10.0L SHCS, BLACK ZINC, 12.9 STL, SPRING WASHER No Model Compatibility List $4.68 / Each

2,4,5,6
101394-001 600294 101394-001 TOUCH SCREEN MAST TIE, CABLE, W3.6 X L185 No Model Compatibility List $4.68 / Each

2,4,5,6
101416-001 600295 101416-001 LOWER FRAME COMPONENTS CABLE TIE, SCREW MOUNT, M5 No Model Compatibility List $4.68 / Each

2,4,5,6
101436-001 600296 101436-001 Q47 PULLEY WELDMENT, CRANK SHAFT Yes Model Compatibility List $47.50 / Each

8,3
101443-001 600298 101443-001 MOVING ARM LABEL, LEVEL No Model Compatibility List $4.68 / Each

3
101456-001 600302 101456-001 MAIN FRAME COMPONENTS COVER, PLASTIC BOTTOM No Model Compatibility List $18.75 / Each

9
101561-001 600307 101561-001 #6-ASSEMBLY BOLT, M10 X 1.5 X 50, HEX HEAD, GR 8.8, CZ No Model Compatibility List $4.68 / Each

2
101592-001 600315 101592-001 CONSOLE MAST COUPLER ASSEMBLY, 8 POSITION, IN-LINE No Model Compatibility List $10.00 / Each

3
101646-001 600323 101646-001 ADJUSTABLE ROCKER BEARING, BALL, 6005, C2 No Model Compatibility List $6.88 / Each

8
101668-001 600332 101668-001 ASSEMBLY, ACCESS PANEL Yes Model Compatibility List $75.00 / Each

7,3,4,5,6
101718-001 600350 101718-001 MOVING ARM SPACER, ARM PIVOT TUBE No Model Compatibility List $2.50 / Each

2,8,3,4,5,6
101720-001 600352 101720-001 #10-ASSY WASHER, 10 X 30 X 2, STEEL, CZ No Model Compatibility List $4.68 / Each

2
101821-001 600382 101821-001 SCREW, M5 X 0.8 X 16.0L SHCS, SS, FLAT WASHER No Model Compatibility List $4.68 / Each

2
101823-001 600383 101823-001 MAIN FRAME COMPONENTS ASSEMBLY, BATTERY WITH PIN No Model Compatibility List $142.50 / Each

3,12,13,14
101844-001 600384 101844-001 LINK ASSEMBLY, LINK, STABILIZER No Model Compatibility List $0.00 / Each
Out Of Stock
3
101845-001 600385 101845-001 MAIN FRAME COMPONENTS GROMMET, 24 X 31.5 No Model Compatibility List $4.38 / Each

2
101861-001 600388 101861-001 MAIN FRAME COMPONENTS BOLT, 10MM J-HOOK No Model Compatibility List $5.00 / Each

2
101862-001 600389 101862-001 #11-ASSEMBLY SCREW, M8 X 1.25 X 16.0L SHCS, BLACK ZINC, 12.9 STL No Model Compatibility List $4.68 / Each

2,4,5,6
101863-001 600390 101863-001 #1-ASSY SHROUD, RIGHT Yes Model Compatibility List $130.00 / Each

7,9,12,13,14
101864-001 600391 101864-001 #1-ASSY SHROUD, LEFT Yes Model Compatibility List $132.50 / Each

7,9,12,13,14
101865-001 600392 101865-001 TOP SHROUD CLASSIC SHROUD, TOP No Model Compatibility List $65.00 / Each

7,9,12,13,14
101866-001 600393 101866-001 TOP SHROUD SHROUD, FRONT No Model Compatibility List $65.00 / Each

7,9,12,13,14
101867-001 600394 101867-001 REAR UPPER SHROUD SHROUD, UPPER REAR Yes Model Compatibility List $23.75 / Each

7,9,12,13,14
101870-001 600396 101870-001 COVER, MAST BOOT Yes Model Compatibility List $27.50 / Each

9,3
101878-001 600398 101878-001 MOVING ARM CONTACT, SS, BACK W/ ADHESIVE Yes Model Compatibility List $25.00 / Each

4,5,6
101879-001 600399 101879-001 MOVING ARM CONTACT, SS, FRONT W/ ADHESIVE Yes Model Compatibility List $30.00 / Each

4,5,6
101881-001 600400 101881-001 MOVING ARM SCREW, M3 X 0.5 X 16 BHCS, SS No Model Compatibility List $4.68 / Each

2
101920-001 600410 101920-001 MAIN FRAME COMPONENTS WASHER, WAVE, 16.7 X 22.5 X .3 No Model Compatibility List $4.68 / Each

2,4,5,6
101933-001 600416 101933-001 CONSOLE MAST CABLE ASSEMBLY, MAST, HR, PRO3700(XL) Yes Model Compatibility List $13.75 / Each

7,3,4,5,6,12,13,14
101935-001 600418 101935-001 RH MOVING ARM CABLE ASSEMBLY, HR-GRIPS Yes Model Compatibility List $10.00 / Each

7,3,4,5,6,12,13,14,11
101939-001 600420 101939-001 BRACED PEDAL LEVER PEDAL, SOFT DESIGN, PLASTIC No Model Compatibility List $37.50 / Each

8,9
101940-001 600421 101940-001 BRACED PEDAL LEVER PEDAL INSERT Yes Model Compatibility List $30.00 / Each

8,9
101949-001 600424 101949-001 MAIN FRAME COMPONENTS CABLE ASSEMBLY, STATIC GROUND, LONG No Model Compatibility List $2.50 / Each

3,4,5,6
101979-001 600428 101979-001 COVER, HANDLE BAR, NO DUAL LOCK Yes Model Compatibility List $5.63 / Each

9,11
101982-001 600430 101982-001 MAIN FRAME COMPONENTS WHEEL, TRANSPORT, 80MM, RIB No Model Compatibility List $3.75 / Each

8
101987-001 600432 101987-001 ASSEMBLY, TOP SHROUD No Model Compatibility List $145.00 / Each

7,9,3,12,13,14
102020-001 600439 102020-001 MOVING ARM KEYPAD, MOVING HANDLEBAR, Q47 No Model Compatibility List $10.63 / Each

9,12,13,14,11
102021-001 600440 102021-001 MOVING ARM PLATE, KEYPAD BACKER No Model Compatibility List $4.68 / Each

9,3,4,5,6,12,13,14
102022-001 600441 102022-001 MOVING ARM CAP, MOVING HB BUTTONS, FRONT Yes Model Compatibility List $4.38 / Each

9
102023-001 600442 102023-001 MOVING ARM CAP, MOVING HB BUTTONS, BACK Yes Model Compatibility List $4.38 / Each

9,4,5,6
102024-001 600443 102024-001 MOVING ARM CLIP, GROUNDING, MOVING HANDLEBAR No Model Compatibility List $4.68 / Each

2,11
102025-001 600444 102025-001 MOVING ARM BUTTON, MOVING HANDLEBAR No Model Compatibility List $3.13 / Each

11
102041-001 600446 102041-001 DECAL, COMMERCIAL, CUSTOMER SERVICE No Model Compatibility List $4.68 / Each

7,3
102042-001 600447 102042-001 WELDMENT, OFFSET CRANK, PRO Yes Model Compatibility List $92.50 / Each

8,3
102047-001 600448 102047-001 WELDMENT, RIGHT CRANK ARM Yes Model Compatibility List $67.50 / Each

8,3
102048-001 600449 102048-001 WELDMENT, LEFT CRANK ARM Yes Model Compatibility List $67.50 / Each

8,3
102071-001 600450 102071-001 REAR TRACK COVER COVER, REAR TRACK Yes Model Compatibility List $23.75 / Each

9,15,3,4,5,6
102074-001 600451 102074-001 COLLAR, LOCKING, SET SCREW, 25MM No Model Compatibility List $4.68 / Each

2
102076-001 600452 102076-001 MAIN FRAME COMPONENTS CABLE, CO-AXIAL, BASE No Model Compatibility List $25.00 / Each

3,4,5,6
102134-001 600459 102134-001 #35-ASSY SCREW, M5 X 0.8 X 18, PAN HEAD, TYPE 1 CROSS RECESSED, SS No Model Compatibility List $4.68 / Each

2
102135-001 600460 102135-001 REAR STABILIZER SCREW, M5 X 0.8 X 10, PAN HEAD, TYPE 1 CROSS RECESSED, SS No Model Compatibility List $4.68 / Each

2
102136-001 600461 102136-001 MAIN FRAME COMPONENTS ASSEMBLY, LOWER REAR SHROUD No Model Compatibility List $77.50 / Each

7,9,3,12,13,14
102138-001 600462 102138-001 MAIN FRAME COMPONENTS ASSY, TENSIONER No Model Compatibility List $42.50 / Each

3
102169-001 600464 102169-001 ASSEMBLY, CONSOLE MAST, 3700 No Model Compatibility List $325.00 / Each

7,3
102238-001 600475 102238-001 RH 3P LINK ASSEMBLY, LINK, 3P No Model Compatibility List $0.00 / Each
Out Of Stock
3
102239-001 600476 102239-001 RH 3P LINK ASSEMBLY, SWINGARM, 3700 No Model Compatibility List $0.00 / Each
Out Of Stock
3
102270-001 600487 102270-001 3700 IFI MAST CABLE ASSEMBLY, MAST, PRO370(0)(XL) No Model Compatibility List $30.00 / Each

3,4,5,6
102304-001 600492 102304-001 LOWER FRAME COMPONENTS SCREW, M5 X 0.8 X 12, PAN HEAD, TYPE 1, CROSS RECESSED, BZ, FLAT WASHER No Model Compatibility List $4.68 / Each

2
102306-001 600494 102306-001 PRO310 SCREW, M5 X 0.8 X 18, PAN HEAD, TYPE 1, CROSS RECESSED, BZ, FLAT WASHER No Model Compatibility List $4.68 / Each

2
102316-001 600496 102316-001 ADJUSTABLE ROCKER TIE, CABLE, W3.6 X L310 No Model Compatibility List $4.68 / Each

2,4,5,6
102453-001 600513 102453-001 #3-ASSY BOLT, M8 X 1.25 X 20, HEX HEAD, GR 8.8, CZ No Model Compatibility List $5.63 / Each

2
102454-001 600514 102454-001 LOWER FRAME COMPONENTS WASHER, 8 X 24 X 2, STEEL, CZ No Model Compatibility List $4.68 / Each

2
102498-001 600517 102498-001 SHAFT, ROCKER No Model Compatibility List $10.63 / Each

3
102505-001 600518 102505-001 CONSOLE MAST CABLE ASSEMBLY, CSAFE Yes Model Compatibility List $11.25 / Each

3,4,5,6
102513-001 600520 102513-001 3700 IFI MAST CABLE ASSEMBLY, MAST, HB BUTTONS Yes Model Compatibility List $13.75 / Each

3,4,5,6
102533-001 600525 102533-001 MAIN FRAME COMPONENTS STAND-OFF, BOARD, 4.8MM No Model Compatibility List $4.68 / Each

2
102627-001 600530 102627-001 ASSEMBLY, 3700 BADGE No Model Compatibility List $12.50 / Each

3
102648-001 600532 102648-001 LH MOVING ARM LABEL, PROGRAM No Model Compatibility List $4.68 / Each

1
102703-001 600537 102703-001 MAIN FRAME COMPONENTS CABLE ASSEMBLY, BATTERY TO MAST No Model Compatibility List $13.75 / Each

3,4,5,6
102710-001 600538 102710-001 ASSEMBLY, MULTI-AXIS BEARING LINK, PLAST Yes Model Compatibility List $195.00 / Each

8,3
102777-001 600555 102777-001 ASSEMBLY, TRACK COVER, OUTSIDE, LH No Model Compatibility List $65.00 / Each

9,15,3,4,5,6
102778-001 600556 102778-001 ASSEMBLY, TRACK COVER, OUTSIDE, RH No Model Compatibility List $65.00 / Each

9,15,3,4,5,6
102779-001 600557 102779-001 ASSEMBLY, TRACK COVER, CENTER No Model Compatibility List $62.50 / Each

9,15,3,4,5,6
102856-001 600563 102856-001 RH MOVING ARM CABLE ASSEMBLY, MOVING HANDLE BAR CONTROLS No Model Compatibility List $15.00 / Each

7,3,4,5,6,11
102857-001 600564 102857-001 RH MOVING ARM SCREW, M2.5 X 0.45 X 8 SHCS, SS No Model Compatibility List $4.68 / Each

2
102875-001 600567 102875-001 CONSOLE MAST SCREW, M5 X 0.8 X 12, PAN HEAD, TYPE 1 CROSS RECESSED, SS, SPRING WSHR-FLAT WSHR No Model Compatibility List $4.68 / Each

7,2,12,13,14
102892-001 600568 102892-001 LOWER FRAME COMPONENTS STAND-OFF, CABLE, 14 DIA No Model Compatibility List $4.68 / Each

2,4,5,6
102915-001 600574 102915-001 ASSEMBLY, MAIN FRAME COMPONENTS No Model Compatibility List $0.00 / Each
Out Of Stock
3
102916-001 600575 102916-001 ASSEMBLY, REAR TRACK COVER No Model Compatibility List $32.50 / Each

9,15,3,4,5,6
103051-001 600608 103051-001 #1-PRO 3700 BASE - FIXED STRIDE ASSEMBLY, MAIN FRAME COMPONENTS, RoHS No Model Compatibility List $0.00 / Each
Out Of Stock
3
103088-001 600617 103088-001 MAIN FRAME COMPONENTS CIRCUIT BOARD ASSEMBLY, BRAKE CONTROL BOARD, SAFETY CERT No Model Compatibility List $307.50 / Each

7,8,9,3,4,5,6
103370-001 600667 103370-001 ASSY, 3700 IFI MAST, RoHS No Model Compatibility List $407.50 / Each

3
103393-001 600669 103393-001 #23-ASSEMBLY NUT, HEX, NYLON INSERT, M8 X 1.25, CZ CLASS 10 No Model Compatibility List $4.68 / Each

2
103395-001 600670 103395-001 #6-ASSY NUT, HEX, NYLON INSERT, M10 X 1.5, CZ CLASS 10 No Model Compatibility List $4.68 / Each

2
104145-001 600812 104145-001 ASSEMBLY, ACCESS PANEL No Model Compatibility List $97.50 / Each

7,3,4,5,6
104147-001 600813 104147-001 ASSEMBLY, TOP SHROUD No Model Compatibility List $190.00 / Each

7,9,3,12,13,14
104148-001 600814 104148-001 TOP SHROUD SHROUD, TOP No Model Compatibility List $102.50 / Each

7,9,12,13,14
104149-001 600815 104149-001 TOP SHROUD SHROUD, FRONT No Model Compatibility List $95.00 / Each

7,9,12,13,14
104150-001 600816 104150-001 ASSEMBLY, LEFT SHROUD No Model Compatibility List $145.00 / Each

7,9,3,12,13,14
104152-001 600817 104152-001 ASSEMBLY, RIGHT SHROUD No Model Compatibility List $150.00 / Each

7,9,3,12,13,14
104247-001 600833 104247-001 PEDAL LEVER ASSY, ROUNDED ROLLER Yes Model Compatibility List $87.50 / Each

8,3
104638-001 600895 104638-001 CONSOLE MAST SCREW, M5 X 0.8 X 6, PAN HEAD, TYPE 1 CROSS RECESSED, BZ No Model Compatibility List $4.68 / Each

2
104956-001 600929 104956-001 ASSY, Q47 PULLEY, ROHS Yes Model Compatibility List $120.00 / Each

8,3
105030-001 600941 105030-001 CAST 3P LINK WASHER, WAVE, 19.3 X 26.0 X 1.4 No Model Compatibility List $2.50 / Each

2,4,5,6
105036-001 600942 105036-001 CAST 3P LINK WASHER, 10.5 X 26 X .5, SNAP FIT No Model Compatibility List $4.68 / Each

2
105037-001 600943 105037-001 CAST 3P LINK SLEEVE, LINKAGE No Model Compatibility List $11.25 / Each

3
105039-001 600945 105039-001 CAST 3P LINK AXLE, SHOULDERED Yes Model Compatibility List $11.25 / Each

8
600950 105100-001 REPLACED BY: 107672-001 ASSY, BRACED PEDAL LEVER, PRO No Model Compatibility List $507.50 / Each

8,9,3,4,5,6
105140-001 600959 105140-001 MAIN FRAME COMPONENTS CABLE ASSY, BRAKE GEN PWR, FERRITE No Model Compatibility List $25.00 / Each

8,3,4,5,6
105141-001 600960 105141-001 MAIN FRAME COMPONENTS CABLE ASSY, BRAKE GEN INDUCT, FERRITE No Model Compatibility List $22.50 / Each

8,3,4,5,6
105142-001 600961 105142-001 MAIN FRAME COMPONENTS CABLE ASSY, BASE, 3700, FERRITE No Model Compatibility List $45.00 / Each

3,4,5,6
105148-001 600962 105148-001 ASSEMBLY, RH 3P LINK No Model Compatibility List $167.50 / Each

3
105149-001 600963 105149-001 ASSEMBLY, LH 3P LINK No Model Compatibility List $167.50 / Each

3
105150-001 600964 105150-001 ASSEMBLY, LINK, STABILIZER No Model Compatibility List $75.00 / Each

3
105197-001 600975 105197-001 WLDMT, RIGHT COMM ROCKER No Model Compatibility List $90.00 / Each

3
105199-001 600976 105199-001 WLDMT, LEFT COMM ROCKER No Model Compatibility List $90.00 / Each

3
105605-001 600992 105605-001 #5-ASSEMBLY KIT BAR, ARM, M10 HOLES Yes Model Compatibility List $9.38 / Each

3
105606-001 600993 105606-001 #4-ASSEMBLY KIT BOLT, M10 X 1.5 X 65, HEX HEAD, GR 8.8, CZ No Model Compatibility List $3.13 / Each

2
105608-001 600994 105608-001 MAIN FRAME COMPONENTS CABLE ASSY, BASE, HB BUTTONS, LONG Yes Model Compatibility List $18.75 / Each

3,4,5,6
105609-001 600995 105609-001 MAIN FRAME COMPONENTS CABLE ASSY, BASE, MOVING HR, LONG Yes Model Compatibility List $21.25 / Each

7,3,4,5,6,12,13,14
106216-001 601071 106216-001 ASSEMBLY KIT, BASE HARDWARE No Model Compatibility List $32.50 / Each

3
106358-001 601081 106358-001 BRACED PEDAL LEVER PEDAL INSERT, REAR No Model Compatibility List $2.50 / Each

8,9
106485-001 601091 106485-001 ASSY, RH MOVING ARM, 3700/4700 No Model Compatibility List $282.50 / Each

3
106490-001 601093 106490-001 ASSY, LH MOVING ARM, 3700 No Model Compatibility List $282.50 / Each

3
106604-001 601110 106604-001 MULTI-AXIS LINK BEARING, BALL, 6000, C0 No Model Compatibility List $5.00 / Each

8
106935-001 601174 106935-001 ASSY, RH STANDING SHROUD Yes Model Compatibility List $130.00 / Each

7,9,3,12,13,14
106936-001 601175 106936-001 ASSY, LH STANDING SHROUD Yes Model Compatibility List $130.00 / Each

7,9,3,12,13,14
106983-001 601184 106983-001 CONSOLE MAST MOUNT, CABLE TIE, SCREW MOUNT No Model Compatibility List $4.68 / Each

2,4,5,6
107253-001 601222 107253-001 MAIN FRAME COMPONENTS ASSEMBLY, ROUNDED TRACK, LEFT No Model Compatibility List $287.50 / Each

15,3,4,5,6
107254-001 601223 107254-001 MAIN FRAME COMPONENTS ASSEMBLY, ROUNDED TRACK, RIGHT No Model Compatibility List $287.50 / Each

15,3,4,5,6
107836-001 601298 107836-001 MULTI-AXIS LINK SCREW, M6 X 1.0 X 18, SHCS, LOCK WSH, BZ No Model Compatibility List $2.50 / Each

2
900001-001 602208 900001-001 #2-ASSEMBLY BEARING, CRANK No Model Compatibility List $12.50 / Each

8
900009-001 602215 900009-001 #3-ASSEMBLY RING, RETAINING, 25MM No Model Compatibility List $4.68 / Each

2
900015-001 602219 900015-001 LOWER FRAME COMPONENTS LEVELER, 50MM DIAMETER Yes Model Compatibility List $14.99 / Each

3
900031-002 602222 900031-002 LOWER FRAME COMPONENTS NUT, HEX BLIND INSERT, M5 X 0.8 No Model Compatibility List $4.68 / Each

2
950005-009 602226 950005-009 #11-ASSEMBLY B18.3.1M, M5 X .8 X 20.0L SHCS, BLACK ZINC, STL No Model Compatibility List $4.68 / Each

4,5,6
950006-010 602229 950006-010 MAIN PULLEY B18.3.1M, M6 X 1.0 X 25.0L SHCS, BLACK ZINC, STL No Model Compatibility List $4.68 / Each

4,5,6
950038-009 602242 950038-009 LOWER FRAME COMPONENTS B18.2.4.1M, HEX NUT, STYLE 1, M10 X 1.5, BLACK ZINC, STL No Model Compatibility List $4.68 / Each

2,4,5,6
950042-008 602244 950042-008 MULTI-AXIS LINK B18.22M, WASHER, PLAIN, STL, M8 No Model Compatibility List $4.68 / Each

2
950042-010 602246 950042-010 MAIN FRAME COMPONENTS B18.22M, WASHER, PLAIN, STL, M12 No Model Compatibility List $4.68 / Each

2
950046-007 602248 950046-007 LOWER FRAME COMPONENTS NUT, HEX, NYLON INSERT, STL, M6 No Model Compatibility List $4.68 / Each

2
602249 950046-008 REPLACED BY: 103393-001 ADJUSTABLE ROCKER NUT, HEX, NYLON INSERT, STL, M8 No Model Compatibility List $4.68 / Each

2
602250 950046-009 REPLACED BY: 103395-001 MULTI-AXIS LINK NUT, HEX, NYLON INSERT, STL, M10 No Model Compatibility List $4.68 / Each

2
950052-006 602252 950052-006 #12-ASSEMBLY B18.21.2M, WASHER, LOCK, STL, M5 No Model Compatibility List $4.68 / Each

2
950052-008 602254 950052-008 #17-ASSY B18.21.2M, WASHER, LOCK, STL, M8 No Model Compatibility List $4.68 / Each

2
950052-009 602255 950052-009 #3-ASSEMBLY KIT B18.21.2M, WASHER, LOCK, STL, M10 No Model Compatibility List $4.68 / Each

2
950052-010 602256 950052-010 MAIN FRAME COMPONENTS B18.21.2M, WASHER, LOCK, STL, M12 No Model Compatibility List $4.68 / Each

2
View Drawing
