Icon Health & Fitness, ProForm, Folding Treadmill, Residential Treadmills, PERSONAL TRAINER, PFTL22040
Phone : 847-309-2818 M-F 9am-4pm

ProForm - PERSONAL TRAINER

Exploded Diagrams

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry used@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Motors
  • Seats
  • Posts
  • Pins
  • Belt Related
  • Frame Related
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
122829 101799 # 9" BLACK WIRE, M/F No Model Compatibility List $4.06 / Each

4,5,6
101676 101898 # BLACK JUMPER WIRE 14" No Model Compatibility List $4.07 / Each

4,5,6
118360 102246 # 8" WHITE WIRE, 2F No Model Compatibility List $3.32 / Each

4,5,6
102634 100111 102634 # 8" GRN WIRE F/R, POWER Yes Model Compatibility List $4.75 / Each

4,5,6
102955 104351 102955 63 INCLINE SENSOR SWITCH No Model Compatibility List $16.73 / Each

4,5,6,10
102959 104355 102959 62 SMALL BOLT No Model Compatibility List $1.28 / Each

2,40
101456 103823 # 14" WHITE WIRE, M/F No Model Compatibility List $4.22 / Each

4,5,6
104208 105477 99 MOTOR NUT No Model Compatibility List $0.31 / Each

2
107503 117640 107503 35 MOTOR BOLT 3/8-16X5" Yes Model Compatibility List $6.51 / Each

2
123759 108080 32 SCREW No Model Compatibility List $0.26 / Each

2
109370 104346 109370 65 INCLINE DISK Yes Model Compatibility List $5.31 / Each

10
109382 103130 109382 17 CIRCUIT BREAKER Yes Model Compatibility List $11.52 / Each

4,5,6
109407 100115 109407 # 4" BLK WIRE F/F, POWER No Model Compatibility List $2.93 / Each

4,5,6
111410 109520 30 6" CABLE LOOM No Model Compatibility List $3.71 / Each

4,5,6
111869 102934 111869 5 CAGE NUT No Model Compatibility List $4.20 / Each

2,3
112083 100300 112083 # 8" BLUE WIRE, 2F No Model Compatibility List $5.46 / Each

4,5,6
121908 112609 22 FRONT ROLLER ADJ BOLT No Model Compatibility List $0.43 / Each

2,8
113278 117627 113278 92 PULY/FLWH/FAN Yes Model Compatibility List $76.56 / Each

8
123765 115872 # STRAIN RELIEF No Model Compatibility List $0.24 / Each

1
116926 100064 116926 81 RELEASABLE WIRE TIE No Model Compatibility List $2.45 / Each

2,4,5,6
116927 100262 116927 79 TIE CLAMP HOLDER - SCREW MOUNT No Model Compatibility List $2.49 / Each

2,4,5,6
117806 118348 117806 31 WHEEL BOLT Yes Model Compatibility List $5.86 / Each
2,8
112273 118201 # 8" RED WIRE JUMPER, M/F No Model Compatibility List $3.41 / Each

4,5,6
102820 118204 # 8" BLUE WIRE,M/F No Model Compatibility List $3.30 / Each

4,5,6
119038 104349 119038 . KEY/CLIP Yes Model Compatibility List $9.89 / Each

2,9
118346 119070 96 SPEED DISK No Model Compatibility List $0.13 / Each

1
123762 119375 67 INCLINE MOTOR BOLT No Model Compatibility List $0.92 / Each

2,10
122824 119779 85 REAR PLATFORM SCREW No Model Compatibility List $0.26 / Each

2
110001 120003 . 3/8" X 2" WHEEL BOLT No Model Compatibility List $1.95 / Each

2,8
123760 120243 33 RT REAR ROLLER ADJ BOLT No Model Compatibility List $1.84 / Each
Out Of Stock
2,8
012056 101661 012056 37 5/16" NYLON LOCKNUT No Model Compatibility List $0.48 / Each

2
120630 103901 120630 106 CONSOLE GROUND SCREW No Model Compatibility List $1.19 / Each

2,7
123763 120866 87 ELECTRONICS SCREW No Model Compatibility List $0.13 / Each

2
120867 104004 120867 90 SEAT RAIL FLANGE NUT No Model Compatibility List $3.75 / Each

2,9,12,13,14
105280 012096 60 ADJUSTMENT BLOCK NUT No Model Compatibility List $0.26 / Each

2
012149 100136 012149 42 3/8" HEX LOCK NUT No Model Compatibility List $1.79 / Each

2
156572 121712 . OWNER'S MANUAL No Model Compatibility List $3.68 / Each

1
122812 113293 122812 107 MOTOR WASHER No Model Compatibility List $1.53 / Each

2
123385 123764 123385 94 MOTOR BOLT CARRIAGE SCREW Yes Model Compatibility List $4.98 / Each

2
125819 101014 125819 103 LARGE STANDOFF Yes Model Compatibility List $0.34 / Each

2,1
121910 129168 104 SAFETY COVER SCREW No Model Compatibility List $0.26 / Each

2,9
013028 100265 013028 59 1" SCREW No Model Compatibility List $1.40 / Each

2,4,5,6
116234 013141 8 M5 X 16MM SCREW No Model Compatibility List $0.13 / Each

2
013162 101030 013162 48 M4 X 13MM SCREW Yes Model Compatibility List $1.26 / Each

2
013206 100358 013206 78 REAR ROLLER BOLT 1/4"-20X3" Yes Model Compatibility List $4.51 / Each

2,8
013547 100450 013547 41 IDLER ARM BOLT No Model Compatibility List $2.89 / Each

2,3,8
100561 014086 100 M10 WASHER No Model Compatibility List $0.36 / Each

2
014117 102446 014117 . 3/8" CONSOLE SUPPORT No Model Compatibility List $1.32 / Each

2
014127 104040 014127 23 1/4" WASHER No Model Compatibility List $1.20 / Each

2,3
014132 100263 014132 . IDLER WHEEL WASHER No Model Compatibility List $2.43 / Each

2,8
014157 100141 014157 105 #8 STAR WASHER Yes Model Compatibility List $1.17 / Each

2
016029 100321 016029 76 CLAMP, CABLE TIE 4" No Model Compatibility List $1.17 / Each

2,4,5,6
016057 100063 016057 77 8" CABLE TIE No Model Compatibility List $1.30 / Each

2,1,4
219170 100096 219170 # 3 TUBE LUBE KIT No Model Compatibility List $30.38 / Each

1,3,15
100094 356520 # ACCESSORY KIT No Model Compatibility List $42.89 / Each

4,5,6,1
View Drawing
