Spirit - XE700

Repair Parts for Spirit XE700 700007

Brand: Spirit

Category: Residential Ellipticals

Type: Elliptical

Model Name: XE700

Serial Number Prefix: 700007

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Seats
  • Posts
  • Pins
  • Belt Related
  • Belt
  • Arm/pedal
  • Rollers and Rotating Parts
  •  Frame Components
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
188973 J260003-Z1 113 Washer split No Model Compatibility List $1.81 / Each

2
Bushing 188880 P060273-A1 81 Bushing No Model Compatibility List $8.74 / Each

8
Sleeve Rod End 188906 C080008-Z1 24 Sleeve Rod End No Model Compatibility List $5.91 / Each

3
Bolt Carriage 188907 C050035-Z3 23 Bolt Carriage No Model Compatibility List $24.99 / Each

2
Axle 188905 C140017 16 Axle Yes Model Compatibility List $49.99 / Each

8
Washer Flat 188959 J210001-Z1 104 Washer Flat No Model Compatibility List $2.91 / Each

2
189095 J367105-Z1 120 Screw Self Tapping No Model Compatibility List $2.91 / Each

2
Cord Power 110V 189031 E060001 58 Cord Power 110V Yes Model Compatibility List $44.99 / Each

4,5,6
Screw flat head socket 188923 J341008-Z1 123 Screw flat head socket No Model Compatibility List $2.91 / Each

2
Washer Flat 188971 J210017-Z1 94 Washer Flat No Model Compatibility List $2.91 / Each

2
Screw Self Tapping 189663 J514502-ZQ 121 Screw Self Tapping No Model Compatibility List $2.91 / Each

2,12,13,14
190143 BB040011-Q2 4 Crank Arm Left No Model Compatibility List $72.75 / Each

8,3
Module AC 190205 F030053 51 Module AC Yes Model Compatibility List $37.49 / Each

4,5,6
212275 F040004 40 Fan Assembly No Model Compatibility List $99.99 / Each

1
190450 F090204 35 850m/m_Handpulse W/Cable Assembly No Model Compatibility List $43.65 / Each

4,5,6,12,13,14
210059 F090351 43 Generator/Brake Controller Yes Model Compatibility List $224.99 / Each

7,8
191000 J010002-ZZ 103 Hex Head Bolt Yes Model Compatibility List $2.91 / Each

2
190394 J010503-Z1 68 Bolt No Model Compatibility List $2.74 / Each

2
190255 J011009-Z1 101 Screw No Model Compatibility List $2.91 / Each

2
191255 J011015A-Y3 112 Bolt Hex Head No Model Compatibility List $2.91 / Each

2
191007 J031009D-Z4 110 Bolt No Model Compatibility List $2.91 / Each

2
190417 J033008G-Z7 111 M8 40m/m_Socket Head Cap Bolt No Model Compatibility List $2.74 / Each

2,9
Nut 190740 J129021-Y3 134 Nut No Model Compatibility List $2.91 / Each

2
190404 J139062F-Z1 137 Nut Locking No Model Compatibility List $2.91 / Each

2
190354 J210022-Z1 165 Washer Flat No Model Compatibility List $2.91 / Each

2
190395 J250002-Z4 176 wave washer No Model Compatibility List $2.74 / Each

2
190401 J310001-Z4 130 025_C Ring (Blackfast) Yes Model Compatibility List $2.91 / Each

4,5,6
Bearing Rod End 190307 K056001 27 Bearing Rod End Yes Model Compatibility List $28.74 / Each

3
Transportation Wheel-062 190387 P050015-A1 56 Transportation Wheel-062 No Model Compatibility List $18.20 / Each

8
Button Head Plug-032(1.8T) 190392 P060253-A1 61 Button Head Plug-032(1.8T) Yes Model Compatibility List $13.93 / Each

1
Bushing 213838 P270003 59 Bushing No Model Compatibility List $10.93 / Each

8
211047 J210016-Z1 72 Fastener No Model Compatibility List $2.91 / Each

2
190205 F030053 1 Module AC Yes Model Compatibility List $37.49 / Each

4,5,6
Drive Belt (500J) (8 rib) 800188 N010002 30 1 Drive Belt (500J) (8 rib) Yes Model Compatibility List $59.99 / Each

15
800190 N040002 32 Magnet-O15xc3x977T No Model Compatibility List $14.99 / Each

Rubber Foot-O35 xc3x97 10m/m 800224 P060256-A1 72 2 Rubber Foot-O35 xc3x97 10m/m Yes Model Compatibility List $14.99 / Each

3
800252 J010505A-ZH 109 Fastener No Model Compatibility List $14.99 / Each

M8 xc3x97 170m/m_J Bolt 800263 J083012K-Z1 120 M8 xc3x97 170m/m_J Bolt Yes Model Compatibility List $22.49 / Each

2
800273 J517007-Z1 130 O3 xc3x97 20m/m_Tapping Screw No Model Compatibility List $14.99 / Each

800274 J310002-Z4 132 O17_C Ring (Blackfast) Yes Model Compatibility List $14.99 / Each

800277 J139461-Z1 135 Fastener No Model Compatibility List $14.99 / Each

800279 J139261-ZF 137 M8 xc3x97 7T_Nyloc Nut No Model Compatibility List $14.99 / Each

800322 J367114-Z1 86 5 ? 19m/m_Tapping Screw No Model Compatibility List $2.74 / Each

O45 ? O35 ? O26 ? 10T_Isolator 300636 P060271-A1 88 O45 ? O35 ? O26 ? 10T_Isolator Yes Model Compatibility List $18.06 / Each

9
300704 J210003-Z1 164 O3/8 No Model Compatibility List $4.18 / Each

300706 J210009-Z1 169 Fastener No Model Compatibility List $3.35 / Each

300710 J210011-Z1 173 O17 ? 23.5 ? 1T_Flat Washer No Model Compatibility List $3.35 / Each

O25_Wave Washer (Blackfast) 300712 J250001-Z4 175 O25_Wave Washer (Blackfast) Yes Model Compatibility List $9.69 / Each

2,3
ENDCAP BUTTON HEAD ~38 FT94/96/XT/SOLE/Z88/Z/XE/Z8 300850 P060070-A1 77 ENDCAP BUTTON HEAD ~38 FT94/96/XT/SOLE/Z88/Z/XE/Z8 Yes Model Compatibility List $12.05 / Each

9
300897 J011002-ZY 132 Fastener No Model Compatibility List $2.49 / Each

300908 J396915-Z1 144 4 ? 19m/m_Sheet Metal Screw XE195(195010)/XE195(195011) No Model Compatibility List $2.68 / Each

300930 J210010-Y3 170 Fastener No Model Compatibility List $2.74 / Each

301453 J210005-Z1 108 Fastener No Model Compatibility List $3.35 / Each

801149 J092002-Z1 68~3 M5 ? 12m/m_Phillips Head Screw No Model Compatibility List $5.03 / Each

Pulley Drive Belt 1270J 500J spir500J8 000146 27 1 Pulley Drive Belt 1270J 500J Yes Model Compatibility List $39.99 / Each

23
Left Footpad Support Plate Pedal (Used) 1029291 000155 62 1 Left Footpad Support Plate Pedal (Used) Yes Model Compatibility List $49.00 / Each

31
Right Footpad Support Plate Pedal (Used) 1029292 000837 14 1 Right Footpad Support Plate Pedal (Used) Yes Model Compatibility List $49.00 / Each

31
6005_Bearing 4000000 K056005 6005_Bearing No Model Compatibility List $21.24 / Each

45
4000001 K056203 6203_Bearing No Model Compatibility List $16.24 / Each

45
O330_Drive Pulley (P060090-A1) 4000002 P060090-A1 O330_Drive Pulley (P060090-A1) Yes Model Compatibility List $43.74 / Each

45
4000005 RP050026-03 Slide Wheel Urethane-(O78PU) (Assembly - includes bearings) No Model Compatibility List $43.74 / Each

45
4000007 J220002-Z1 3/8" 23 1.5T_Curved Washer XE195(195010)/XE195(195011) No Model Compatibility List $2.74 / Each

52
4000008 P060252 O25 O25 15T_Rubber Foot Pad No Model Compatibility List $11.24 / Each

52
4000042 J010502-Z1 5/16 X 3/4 Hex Head Bolt No Model Compatibility List $2.74 / Each

2
4000043 J092503-Z1 M6 15m/m_Phillips Head Screw No Model Compatibility List $2.74 / Each

2
4000080 F030158 300m/m_Sensor W/Cable No Model Compatibility List $31.24 / Each

4
4000114 J260006-Z1 1/4"_Split Washer No Model Compatibility List $2.74 / Each

52
4000150 J526810 SCREW SELF TAPPING 3.5 X 30MM No Model Compatibility List $2.74 / Each

2
4000240 M030002-Z0 TRACK ALUMINUM (3-HOLE) XE850XE300/700 No Model Compatibility List $41.24 / Each

52
