Life Fitness - CLSX Classic (CXX)

Repair Parts for Life Fitness CLSX Classic (CXX) CLSX-ALLCX-01

Brand: Life Fitness

Category: Commercial Ellipticals

Type: Elliptical

Model Name: CLSX Classic (CXX)

Exploded Diagrams

Click To See ALL Available Parts Diagrams For This Machine

Parts not in the list may no longer be available new, we may have it used - you can send us an inquiry support@hydrafitnessexchange.com

   Show All Selected Attributes
  • Fastener Related
  • Frame Components
  • Wires
  • Cables
  • Power
  • Circuit Boards
  • Rotating Parts
  • Plastic Parts
  • Motors
  • Grips & Handles
  • Seats
  • Posts
  • Pins
  • Belt Related
  • Accessories
  • Electronics
  • Motor
  • Other
    Views
Image  Catalog # MPN Part List Key Quantity On Model Part Description Notes Available Used Model Compatibility List New price
6V Battery Cyclon 500003 0017-00003-0685 - 6V Battery Cyclon Yes Model Compatibility List $47.71 / Each

1
Paint Spray Can - Arctic Silver 500100 0017-00008-0204 - Paint Spray Can - Arctic Silver No Model Compatibility List $64.18 / Each

1
5 oz Bottle - Arctic Silver 500101 0017-00008-0205 - 5 oz Bottle - Arctic Silver No Model Compatibility List $45.37 / Each

1
.33oz Pen - Arctic Silver 500102 0017-00008-0206 - .33oz Pen - Arctic Silver No Model Compatibility List $48.80 / Each

1
Paint: Shadow-Gray Touch Up: .6 OZ Bottle 500103 0017-00008-0210 - Paint: Shadow-Gray Touch Up: .6 OZ Bottle No Model Compatibility List $62.15 / Each

1
Paint: Shadow-Gray Touch Up: .6 OZ Bottle 500104 0017-00008-0211 - Paint: Shadow-Gray Touch Up: .6 OZ Bottle No Model Compatibility List $69.13 / Each

1
Alternator 500126 0017-00009-0841 - Alternator Yes Model Compatibility List $285.85 / Each

1,8
F-Type Panel Connector 500200 0017-00021-2846 - F-Type Panel Connector No Model Compatibility List $14.75 / Each

7
Viton O-ring 500210 0017-00041-0053 - Viton O-ring No Model Compatibility List $1.57 / Each

1
Front Transport Wheel 500220 0017-00042-0674 - Front Transport Wheel Yes Model Compatibility List $6.56 / Each

8
Hardware: Grommet 500221 0017-00042-0754 - Hardware: Grommet Yes Model Compatibility List $1.57 / Each

2
Push-on cap 500277 0017-00042-1066 - Push-on cap No Model Compatibility List $3.81 / Each

9
Hardware: Bushing 500284 0017-00042-1078 - Hardware: Bushing No Model Compatibility List $1.57 / Each

8
Hardware: Retaining Ring 1 500325 0017-00100-0152 - Hardware: Retaining Ring 1" No Model Compatibility List $1.57 / Each

1
Hardware: Screw 0.1875 500348 0017-00101-0314 - Hardware: Screw 0.1875" No Model Compatibility List $1.57 / Each

2
Hardware: Screw 0.3125 500349 0017-00101-0333 - Hardware: Screw 0.3125" No Model Compatibility List $1.57 / Each

2
Hardware: Alternator Pivot Bolt 4.5 500369 0017-00101-0964 - Hardware: Alternator Pivot Bolt 4.5" Yes Model Compatibility List $3.20 / Each

2,8
Hardware: Bolt 0.75 500373 0017-00101-0986 - Hardware: Bolt 0.75" No Model Compatibility List $1.57 / Each

2
Hardware: Phillips Pan Screw 0.75 500374 0017-00101-0991 - Hardware: Phillips Pan Screw 0.75 Yes Model Compatibility List $1.40 / Each

2
Hardware: Phillips Pan Screw 0.75 500402 0017-00101-1242 - Hardware: Phillips Pan Screw 0.75" No Model Compatibility List $1.57 / Each

2
Hardware: TORX Screw 0.375 500410 0017-00101-1282 - Hardware: TORX Screw 0.375" No Model Compatibility List $1.57 / Each

2
Hardware: Hex Bolt 1.25 500467 0017-00101-1551 - Hardware: Hex Bolt 1.25" No Model Compatibility List $1.57 / Each

2
Hardware: Hex Bolt 2.5 500475 0017-00101-1606 - Hardware: Hex Bolt 2.5" No Model Compatibility List $1.57 / Each

2
Hardware: Serrated Flange Hex Bolt 1 500495 0017-00101-1635 - Hardware: Serrated Flange Hex Bolt 1 Yes Model Compatibility List $3.81 / Each

2
Hardware: Bolt 500499 0017-00101-1645 - Hardware: Bolt Yes Model Compatibility List $1.57 / Each

2
Hardware: Bolt 4.25 500500 0017-00101-1646 - Hardware: Bolt 4.25" No Model Compatibility List $3.20 / Each

2
Hardware: Phillips Pan Screw 0.375 500502 0017-00101-1650 - Hardware: Phillips Pan Screw 0.375" No Model Compatibility List $1.40 / Each

2
Hardware: Intermediate Pulley Bolt 5.5 500503 0017-00101-1651 - Hardware: Intermediate Pulley Bolt 5.5" No Model Compatibility List $3.20 / Each

2,8
Hardware: Phillips Pan Screw 500529 0017-00101-1744 - Hardware: Phillips Pan Screw No Model Compatibility List $1.57 / Each

2
Hardware: Console Support Cap Screw 500531 0017-00101-1746 - Hardware: Console Support Cap Screw No Model Compatibility List $1.57 / Each

7,2,9,3
Hardware: Phillips Pan Screw 0.625 500573 0017-00101-1811 - Hardware: Phillips Pan Screw 0.625" No Model Compatibility List $1.57 / Each

2
Hardware: Screw 500586 0017-00101-1844 - Hardware: Screw No Model Compatibility List $1.57 / Each

2
Hardware: Locking Nut 1/4 500744 0017-00103-0019 - Hardware: Locking Nut 1/4" ID No Model Compatibility List $1.57 / Each

2
Hardware: Locking Nut 3/8 500745 0017-00103-0025 - Hardware: Locking Nut 3/8" ID No Model Compatibility List $1.57 / Each

2
500752 0017-00103-0117 - Hardware: Locking Nut 1/2" ID No Model Compatibility List $1.40 / Each

2
Hardware: Locking Nut 3/8 500756 0017-00103-0137 - Hardware: Locking Nut 3/8" ID No Model Compatibility List $1.57 / Each

2
Hardware: Flange Lock Nut 3/8 500762 0017-00103-0188 - Hardware: Flange Lock Nut 3/8" ID No Model Compatibility List $1.57 / Each

2
Hardware: Flat Washer 0.5 500831 0017-00104-0168 - Hardware: Flat Washer 0.5" OD No Model Compatibility List $8.15 / Each

2
Hardware: Flat Washer 0.813 500834 0017-00104-0192 - Hardware: Flat Washer 0.813" OD No Model Compatibility List $1.57 / Each

2
Hardware: Flat Washer 0.67 500880 0017-00104-0450 - Hardware: Flat Washer 0.67" OD No Model Compatibility List $1.57 / Each

2
Hardware: Flat Washer 1.62 500881 0017-00104-0454 - Hardware: Flat Washer 1.62" OD No Model Compatibility List $3.20 / Each

2
Plug 501254 0K14-01384-0000 - Plug No Model Compatibility List $1.57 / Each

1
Double-sided Tape 501443 0K39-01044-0001 - Double-sided Tape No Model Compatibility List $1.57 / Each

1
Square Key 501724 0K53-01122-0000 - Square Key Yes Model Compatibility List $1.57 / Each

9
Hardware: Pillow Block Bearing 501725 0K53-01181-0000 - Hardware: Pillow Block Bearing No Model Compatibility List $64.18 / Each

1
Belt: Poly-V; 32 501727 0K53-01447-0000 - Belt: Poly-V; 32 Yes Model Compatibility List $32.89 / Each

15
SHROUD: CUP HOLDER, PLASTIC 502034 0K61-01013-0201 FS-002 SHROUD: CUP HOLDER, PLASTIC No Model Compatibility List $21.52 / Each

9,12,13,14
502035 0K61-01027-0000 - Flywheel: 6.75" D No Model Compatibility List $31.40 / Each

8
Pedal Lever Clevis Shaft 502039 0K61-01076-0000 - Pedal Lever Clevis Shaft Yes Model Compatibility List $16.40 / Each

8,9,3
Shaft Split Collar 502044 0K61-01259-0000 - Shaft Split Collar No Model Compatibility List $16.40 / Each

1
Crank Arm Shaft Collar 502045 0K61-01260-0000 - Crank Arm Shaft Collar Yes Model Compatibility List $18.04 / Each

8,3
Stabilizer Cap 502062 0K61-01284-0204 LF-015 Stabilizer Cap Yes Model Compatibility List $6.00 / Each

9
Wheel Shaft 502068 0K61-01300-0000 - Wheel Shaft Yes Model Compatibility List $9.92 / Each

8
Hardware: Beveled Washer 502080 0K61-01356-0000 - Hardware: Beveled Washer No Model Compatibility List $1.57 / Each

2
Crankshaft w/plate 502082 0K61-01360-0002 - Crankshaft w/plate No Model Compatibility List $126.81 / Each

8
BRKT: ACCESS 502085 0K61-01373-0003 - BRKT: ACCESS No Model Compatibility List $29.59 / Each

4,5,6
Rocker Seal 502090 0K61-01410-0200 DS-053 Rocker Seal No Model Compatibility List $9.21 / Each

1,9
Crankshaft Plate 502092 0K61-02302-0001 - Crankshaft Plate No Model Compatibility List $8.15 / Each

8
Intermediate Bracket 502094 0K61-02400-0001 - Intermediate Bracket No Model Compatibility List $128.45 / Each

2,3,4,5,6
Poly-V Crank Pulley 502095 0K61-02409-0000 - Poly-V Crank Pulley No Model Compatibility List $83.97 / Each

8
Alternator Strap with Insert 502096 0K61-02601-0000 - Alternator Strap with Insert No Model Compatibility List $13.10 / Each

1
Arm Extension 502097 0K61-03004-0000 - Arm Extension Yes Model Compatibility List $32.48 / Each

3
Crank Cover 502101 0K61-03100-5104 DS-014 Crank Cover Yes Model Compatibility List $70.52 / Each

8,9
Roller Retainer Plate 502104 0K61-04114-0000 - Roller Retainer Plate Yes Model Compatibility List $16.40 / Each

8
Accessory Tray Pad Rubber 502110 0K61-05070-0700 UF-005 Accessory Tray Pad Rubber Yes Model Compatibility List $10.53 / Each

4,5,6,12,13,14
COVER PLATE: -06XX HEX YELLOW 502115 0K61-06012-0601 UF-015 COVER PLATE: -06XX HEX YELLOW No Model Compatibility List $20.71 / Each

9
COVER PLATE: -08XX PURPLE 502116 0K61-06012-0801 UF-015 COVER PLATE: -08XX PURPLE No Model Compatibility List $39.66 / Each

9
Console Cap 502117 0K61-06012-5101 UF-015 Console Cap No Model Compatibility List $11.98 / Each

7,9
Accessory Tray 502119 0K61-06013-0201 UF-007 Accessory Tray Yes Model Compatibility List $13.19 / Each

4,5,6
COVER TRAY: ACCESSORY; -05XX RED 502120 0K61-06013-0501 UF-007 COVER TRAY: ACCESSORY; -05XX RED No Model Compatibility List $25.84 / Each

9,4,5,6
Extrusion Cover 502125 0K61-06121-0008 - Extrusion Cover Yes Model Compatibility List $62.26 / Each

9
EXTRUSION, BOTTOM, YLW-06XX 502126 0K61-06121-0609 LF-004 EXTRUSION, BOTTOM, YLW-06XX No Model Compatibility List $86.64 / Each

1
Front Cover: Left 502134 0K61-06240-0003 LF-012 Front Cover: Left Yes Model Compatibility List $111.51 / Each

9
COVER: FRONT; LT; RED-05XX 502135 0K61-06240-0504 LF-010 COVER: FRONT; LT; RED-05XX No Model Compatibility List $43.08 / Each

9
Front Cover: Right 502138 0K61-06250-0003 LF-010 Front Cover: Right Yes Model Compatibility List $21.65 / Each

9
COVER: FRONT, RIGHT, RED-05XX 502139 0K61-06250-0504 LF-012 COVER: FRONT, RIGHT, RED-05XX No Model Compatibility List $43.08 / Each

9
Inside Cover: Left 502143 0K61-06300-0005 DS-044 Inside Cover: Left Yes Model Compatibility List $100.15 / Each

9
Cover: Link; Left; Inside (with On-SeRights) Red-05XX 502144 0K61-06300-0506 - Cover: Link; Left; Inside (with On-SeRights) Red-05XX No Model Compatibility List $143.56 / Each

9
Inside Cover: Right 502148 0K61-06320-0005 DS-045 Inside Cover: Right Yes Model Compatibility List $90.07 / Each

9
Cover: Link; Right; Inside (with On-SeRights) Red-05XX 502149 0K61-06320-0506 DS-045 Cover: Link; Right; Inside (with On-SeRights) Red-05XX No Model Compatibility List $143.56 / Each

9
Front Rocker Arm Cover 502153 0K61-06340-0004 DS-062 Front Rocker Arm Cover Yes Model Compatibility List $11.18 / Each

3,9
Cover: Boot; Front; Red-05XX 502154 0K61-06340-0505 - Cover: Boot; Front; Red-05XX No Model Compatibility List $28.71 / Each

9
Rear Rocker Arm Cover 502157 0K61-06341-0004 DS-061 Rear Rocker Arm Cover Yes Model Compatibility List $10.60 / Each

3,9
Cover: Boot; Rear; Red-05XX 502158 0K61-06341-0505 - Cover: Boot; Rear; Red-05XX No Model Compatibility List $28.71 / Each

9
Front Deadshaft Cover 502161 0K61-06350-0004 DS-064 Front Deadshaft Cover Yes Model Compatibility List $13.75 / Each

9
Dead Shaft Cover, Front; Red-05XX 502162 0K61-06350-0505 - Dead Shaft Cover, Front; Red-05XX No Model Compatibility List $39.04 / Each

9
Rear Deadshaft Cover 502165 0K61-06351-0004 DS-063 Rear Deadshaft Cover Yes Model Compatibility List $11.18 / Each

9
Dead Shaft Cover, Rear; Red-05XX 502166 0K61-06351-0505 - Dead Shaft Cover, Rear; Red-05XX No Model Compatibility List $38.98 / Each

9
Battery Door 502199 0K62-01026-0202 CN-019 Battery Door Yes Model Compatibility List $6.74 / Each

1
Bullhorn Grip 11.75 502220 0K62-01136-0002 - Bullhorn Grip 11.75" No Model Compatibility List $8.15 / Each

11
Decal 502223 0K62-01175-0001 - Decal No Model Compatibility List $74.03 / Each

7,3
502837 0K86-01003-0200 CN-011 iPod Holder No Model Compatibility List $2.80 / Each

1
iPod Cable Bracket 502838 0K86-01004-0200 CN-018 iPod Cable Bracket No Model Compatibility List $52.29 / Each

2,3,4,5,6
Reed Switch SPDT 504180 118E-00001-0140 - Reed Switch SPDT Yes Model Compatibility List $19.69 / Each

4,5,6
Heart Rate Receiver 504183 118E-00001-0244 - Heart Rate Receiver No Model Compatibility List $43.57 / Each

12,13,14
FFC 16 Pin 1.25mm 7 in. Cable 504186 118E-00001-0266 CBL-002 FFC 16 Pin 1.25mm 7 in. Cable No Model Compatibility List $6.70 / Each

4,5,6,12,13,14
Hardware: Holder Mounting Screw 506293 3223501 CN-007 Hardware: Holder Mounting Screw No Model Compatibility List $1.57 / Each

2
Paint: 4.5 oz Aerosol Spray 506479 3249313 - Paint: 4.5 oz Aerosol Spray No Model Compatibility List $31.79 / Each

1
Paint: 0.5 oz Brush 506480 3249413 - Paint: 0.5 oz Brush No Model Compatibility List $23.55 / Each

1
Paint: Hex Yellow Touch Up: 12 Oz Spray 510431 8809701 - Paint: Hex Yellow Touch Up: 12 Oz Spray No Model Compatibility List $98.01 / Each

1
Paint: Hex Yellow Touch Up: .6 Oz Bottle W/Applicator 510432 8809801 - Paint: Hex Yellow Touch Up: .6 Oz Bottle W/Applicator No Model Compatibility List $54.90 / Each

1
PCB: Non-Tread 511613 A084-92367-0000 CN-002 PCB: Non-Tread No Model Compatibility List $480.39 / Each

1
Coax Cable: 120 512668 AK32-00020-0002 - Coax Cable: 120 Yes Model Compatibility List $31.24 / Each

4,5,6
Power Extension Cable: 120 512684 AK32-00078-0001 - Power Extension Cable: 120 Yes Model Compatibility List $78.09 / Each

4,5,6
Headphone Jack Cable - 3.5 mm 512685 AK32-00124-0002 CBL 3 Headphone Jack Cable - 3.5 mm Yes Model Compatibility List $25.42 / Each

4,5,6
DC Power Cable 512955 AK47-00063-0001 CBL-007 DC Power Cable No Model Compatibility List $45.23 / Each

4,5,6
Leg Leveler 513615 AK61-00035-0000 - Leg Leveler Yes Model Compatibility List $32.56 / Each

1
Bullhorn HR cables 513621 AK61-00051-0000 - Bullhorn HR cables Yes Model Compatibility List $22.99 / Each

4,5,6,12,13,14
Lifepulse: User-Arm 513622 AK61-00051-0001 - Lifepulse: User-Arm Yes Model Compatibility List $37.05 / Each

3,12,13,14
Lifepulse Sensor Cable 513624 AK61-00052-0002 - Lifepulse Sensor Cable Yes Model Compatibility List $55.96 / Each

4,5,6,12,13,14
Intermediate Pulley Assembly 513630 AK61-00061-0000 - Intermediate Pulley Assembly Yes Model Compatibility List $0.00 / Each
8
Clevis Cover 513633 AK61-00062-0003 LF-013 Clevis Cover Yes Model Compatibility List $15.99 / Each

9
Crank Arm 513634 AK61-00064-0001 - Crank Arm Yes Model Compatibility List $166.93 / Each

8,3
Rocker-Arm Assembly; Purchased; Retro 513645 AK61-00094-0005 DS-057 Rocker-Arm Assembly; Purchased; Retro No Model Compatibility List $336.75 / Each

3
Rocker Arm: Right or Left 513646 AK61-00094-0007 DS-057 Rocker Arm: Right or Left No Model Compatibility List $250.91 / Each

3
ROCKER ARM ASSY: PURCH; PLANET FITNESS 513647 AK61-00094-0008 DS-057 ROCKER ARM ASSY: PURCH; PLANET FITNESS No Model Compatibility List $231.76 / Each

3
Resistor Bracket Assembly 513677 AK61-00127-0000 - Resistor Bracket Assembly Yes Model Compatibility List $157.06 / Each

2,3,4,5,6
Power Control Cable Assembly 513680 AK61-00135-0000 - Power Control Cable Assembly Yes Model Compatibility List $87.26 / Each

7,4,5,6
Main Cable 513681 AK61-00136-0000 - Main Cable Yes Model Compatibility List $61.61 / Each

4,5,6
PCB Assembly 513683 AK61-00145-0001 - PCB Assembly No Model Compatibility List $241.04 / Each

1
Crankshaft Assembly 513691 AK61-00157-0002 - Crankshaft Assembly No Model Compatibility List $272.99 / Each

8
REAR-COVER W/DECAL ASSY RED: MFG; RT 513700 AK61-00176-0003 - REAR-COVER W/DECAL ASSY RED: MFG; RT No Model Compatibility List $136.38 / Each

7,9,3
Rear-Cover with Decal Assembly Red: Mfg; Left 513701 AK61-00176-0004 - Rear-Cover with Decal Assembly Red: Mfg; Left No Model Compatibility List $136.38 / Each

7,9,3
Rear Cover w/Decal: Right 513702 AK61-00176-0005 LF-018 Rear Cover w/Decal: Right Yes Model Compatibility List $179.07 / Each

3,7,9
Rear Cover w/Decal: Left 513703 AK61-00176-0006 LF-017 Rear Cover w/Decal: Left Yes Model Compatibility List $108.30 / Each

3,7,9
Access Panel Assembly 513710 AK61-00190-0000 - Access Panel Assembly No Model Compatibility List $107.71 / Each

7,4,5,6
LINK COVER: W/XFER; DOM; CT; RT 513732 AK61-00214-0003 DS-037 LINK COVER: W/XFER; DOM; CT; RT No Model Compatibility List $177.46 / Each

9
LINK COVER: W/XFER; DOM; CT; LT 513733 AK61-00214-0004 DS-040 LINK COVER: W/XFER; DOM; CT; LT No Model Compatibility List $181.00 / Each

9
Link Cover w/Transfer Decal: Right 513734 AK61-00214-0005 DS-037 Link Cover w/Transfer Decal: Right Yes Model Compatibility List $72.83 / Each

7,9,3
Link Cover w/Transfer Decal: Left 513735 AK61-00214-0006 DS-040 Link Cover w/Transfer Decal: Left Yes Model Compatibility List $111.76 / Each

3,7,9
LINK COVER: DOM CT; RT; PLANET FITNESS 513736 AK61-00214-0009 DS-037 LINK COVER: DOM CT; RT; PLANET FITNESS No Model Compatibility List $81.97 / Each

9
LINK COVER: DOM CT; LT; PLANET FITNESS 513737 AK61-00214-0010 DS-040 LINK COVER: DOM CT; LT; PLANET FITNESS No Model Compatibility List $81.69 / Each

9
Hardware Bag 513740 AK61-00222-0000 - Hardware Bag No Model Compatibility List $31.19 / Each

1
Alternator w/Flywheel 513742 AK61-00250-0001 - Alternator w/Flywheel Yes Model Compatibility List $294.93 / Each

8
Upper Arm: Left 513746 AK61-00258-0002 HR-001 Upper Arm: Left No Model Compatibility List $194.06 / Each

3
Upper Arm: Right 513747 AK61-00258-0003 HR-009 Upper Arm: Right No Model Compatibility List $194.06 / Each

3
UPR-ARM GRIPS ASSY: LT; RETRO 513748 AK61-00258-0004 HR-001 UPR-ARM GRIPS ASSY: LT; RETRO No Model Compatibility List $202.46 / Each

3,11
UPR-ARM GRIPS ASSY: RT; RETRO 513749 AK61-00258-0005 HR-009 UPR-ARM GRIPS ASSY: RT; RETRO No Model Compatibility List $202.46 / Each

3,11
UPR-ARM GRIPS ASSY: LT PLANET FITNESS 513750 AK61-00258-0006 HR-001 UPR-ARM GRIPS ASSY: LT PLANET FITNESS No Model Compatibility List $258.40 / Each

3,11
UPR-ARM GRIPS ASSY: RT PLANET FITNESS 513751 AK61-00258-0007 HR-009 UPR-ARM GRIPS ASSY: RT PLANET FITNESS No Model Compatibility List $258.40 / Each

3,11
PEDAL-LEVER W/BEARING ASSY; RT SHADOW GREY 513753 AK61-00265-5200 DS-043 PEDAL-LEVER W/BEARING ASSY; RT SHADOW GREY No Model Compatibility List $305.55 / Each

8,9,3
PEDAL-LEVER W/BEARING ASSY; LT SHADOW GREY 513754 AK61-00265-5201 DS-042 PEDAL-LEVER W/BEARING ASSY; LT SHADOW GREY No Model Compatibility List $305.55 / Each

8,9,3
PEDAL-LEVER W/BEARING ASSY; RT R/C 513755 AK61-00265-5600 - PEDAL-LEVER W/BEARING ASSY; RT R/C No Model Compatibility List $305.55 / Each

8,9,3
PEDAL-LEVER W/BEARING ASSY; LT R/C 513756 AK61-00265-5601 - PEDAL-LEVER W/BEARING ASSY; LT R/C No Model Compatibility List $305.55 / Each

8,9,3
PEDAL-LEVER W/BEARING ASSY; RT R/C PERFORMANCE PURPLE 513757 AK61-00265-5800 DS-043 PEDAL-LEVER W/BEARING ASSY; RT R/C PERFORMANCE PURPLE No Model Compatibility List $305.55 / Each

8,9,3
PEDAL-LEVER W/BEARING ASSY; LT R/C PERFORMANCE PURPLE 513758 AK61-00265-5801 DS-042 PEDAL-LEVER W/BEARING ASSY; LT R/C PERFORMANCE PURPLE No Model Compatibility List $305.55 / Each

8,9,3
Console Support Assembly w/Handrings 513771 AK61-00505-0000 UF-010 Console Support Assembly w/Handrings No Model Compatibility List $382.08 / Each

7,3
CONSOLE SUPPORT ASSEMBLY: MFG; RETRO 513772 AK61-00505-0002 UF-010 CONSOLE SUPPORT ASSEMBLY: MFG; RETRO No Model Compatibility List $358.90 / Each

7,3
CONSOLE-SUPPORT ASSEMBLY: PLANET FITNESS 513773 AK61-00505-0003 UF-010 CONSOLE-SUPPORT ASSEMBLY: PLANET FITNESS No Model Compatibility List $358.90 / Each

7,3
Magnet-Standoff Assembly 513819 AK62-00186-0000 - Magnet-Standoff Assembly No Model Compatibility List $12.66 / Each

2,8
Polar Cable 514467 AK69-00157-0000 CN-004 Polar Cable Yes Model Compatibility List $18.60 / Each

4,5,6
TV Control: Non-Tread 514569 AK86-00002-0000 CBL-017 TV Control: Non-Tread Yes Model Compatibility List $151.23 / Each

4,5,6,7
iPod Console Cable: Non-Tread 514571 AK86-00003-0000 CN-008 iPod Console Cable: Non-Tread No Model Compatibility List $36.27 / Each

7,4,5,6
Console Case Assembly 514574 AK86-00024-0201 CN-020 Console Case Assembly No Model Compatibility List $45.56 / Each
Out Of Stock 		7
Headphone Jack 514575 AK86-00025-0201 CN-022 Headphone Jack No Model Compatibility List $37.09 / Each

4,5,6
Bezel and Overlay: English/Imperial 514597 AK86-00049-0000 CN-005 Bezel and Overlay: English/Imperial No Model Compatibility List $290.11 / Each

1
OVERLAY: BEZEL SWITCH; ASSY; IPOD HOLDER; RETRO INTEGRITY; CLSX 514598 AK86-00049-0600 CN-005 OVERLAY: BEZEL SWITCH; ASSY; IPOD HOLDER; RETRO INTEGRITY; CLSX No Model Compatibility List $346.14 / Each

4,5,6
OVERLAY: BEZEL SWITCH; ASSY; IPOD HOLDER; PLANET INTEGRITY; CLSX 514599 AK86-00049-0800 CN-005 OVERLAY: BEZEL SWITCH; ASSY; IPOD HOLDER; PLANET INTEGRITY; CLSX No Model Compatibility List $346.14 / Each

4,5,6
Bezel and Overlay: German/Metric 514600 AK86-00050-0000 CN-005 Bezel and Overlay: German/Metric No Model Compatibility List $354.14 / Each

1
Bezel and Overlay: French/Metric 514601 AK86-00051-0000 CN-005 Bezel and Overlay: French/Metric No Model Compatibility List $397.99 / Each

1
Bezel and Overlay: Spanish/Metric 514602 AK86-00052-0000 CN-005 Bezel and Overlay: Spanish/Metric No Model Compatibility List $294.17 / Each

1
Assembly: Decal; Crank Cover; Retro 514630 AK86-00085-0000 DS-014 Assembly: Decal; Crank Cover; Retro No Model Compatibility List $232.23 / Each

7,8,9,3
ASSY: DECAL; CRANK COVER; PLANET 514631 AK86-00086-0000 DS-014 ASSY: DECAL; CRANK COVER; PLANET No Model Compatibility List $232.23 / Each

7,8,9,3
OVERMOLDED IPOD CABLE; NON TREAD; INTEGRITY take from REP depot 514632 AK86-00087-0200 CBL-016 OVERMOLDED IPOD CABLE; NON TREAD; INTEGRITY take from REP depot No Model Compatibility List $28.01 / Each

4,5,6
NC INTEGRITY CLSX CROSS TRAINER CONSOLE ENG/ENG 515294 CLEDX-ENGEX-02N CN-001 NC INTEGRITY CLSX CROSS TRAINER CONSOLE ENG/ENG No Model Compatibility List $0.00 / Each
Out Of Stock 		7
NC INTEGRITY CLSX CONSOLE ENG/ENG PLANET FITNESS 515295 CLEDX-ENGEX-02P FN CN-001 NC INTEGRITY CLSX CONSOLE ENG/ENG PLANET FITNESS No Model Compatibility List $0.00 / Each
Out Of Stock 		7
NC INTEGRITY CLSX CONSOLE ENG/ENG RETRO FITNESS 515296 CLEDX-ENGEX-02R FN CN-001 NC INTEGRITY CLSX CONSOLE ENG/ENG RETRO FITNESS No Model Compatibility List $0.00 / Each
Out Of Stock 		7
NC CLSX DOM CROSS TRAINER CONSOLE ENG/MET 515302 CLEDX-ENGMX-02N CN-001 NC CLSX DOM CROSS TRAINER CONSOLE ENG/MET No Model Compatibility List $0.00 / Each
Out Of Stock 		7
Console: French/Metric 515304 CLEDX-FRNMX-01N CN-001 Console: French/Metric No Model Compatibility List $756.07 / Each

7
NC INTEGRITY CLSX DOM CROSS TRAINER CONSOLE SPN/MET 515311 CLEDX-SPNMX-02N CN-001 NC INTEGRITY CLSX DOM CROSS TRAINER CONSOLE SPN/MET No Model Compatibility List $0.00 / Each
Out Of Stock 		7
Console: German/Metric 515325 CLEDXH-GERMX-01 N CN-001 Console: German/Metric No Model Compatibility List $0.00 / Each
Out Of Stock 		7
Drive Linkage Assembly Kit 515984 GK61-00002-0020 - Drive Linkage Assembly Kit Yes Model Compatibility List $101.82 / Each

10
Roller 515987 GK61-00002-0026 - Roller Yes Model Compatibility List $83.23 / Each

8
Pedal Kit 515997 GK61-00002-0055 DS-047 Pedal Kit Yes Model Compatibility List $78.06 / Each

8,9
KIT: CROSS TRAINER BELT AND PULLEY 515998 GK61-00002-0056 - KIT: CROSS TRAINER BELT AND PULLEY No Model Compatibility List $129.85 / Each

8,15
KIT: INT CUPHOLDER W/ ORINGS 516042 GK63-00002-0080 FS-002 KIT: INT CUPHOLDER W/ ORINGS No Model Compatibility List $26.02 / Each

1
Handlebar Heart Rate Kit 516058 GK69-00002-0002 FS-026 Handlebar Heart Rate Kit No Model Compatibility List $95.95 / Each

11,12,13,14
Main Drive Belt 52 Inch LF520J10 0K61-02701-0000 1 Main Drive Belt 52 Inch Yes Model Compatibility List $44.79 / Each

15
Drive Belt - Used 000145 0K61-02701-0000 1 Drive Belt - Used Yes Model Compatibility List $22.39 / Each
15
16 Rib Main Drive Belt 52 0K53-01184-000 0K53-01184-000 16 Rib Main Drive Belt 52" No Model Compatibility List $55.99 / Each
Out Of Stock 		15
Accessory iPod Tray Kit Cup Holder 1003742 0K86-01003-0200 Accessory iPod Tray Kit Cup Holder Yes Model Compatibility List $24.99 / Each
Out Of Stock 		16
Leveling Foot Leveler 1003976 AK61-00035-0000 Leveling Foot Leveler Yes Model Compatibility List $19.99 / Each

1
Generator Alternator with Load Resistor 1003733 0017-00009-0841 Generator Alternator with Load Resistor Yes Model Compatibility List $133.87 / Each
28
Generator Alternator 1003743 AK63-00093-0000 Generator Alternator Yes Model Compatibility List $147.99 / Each
Out Of Stock 		1
Polar Wire Harness 1003736 AK69-00157-0000 Polar Wire Harness Yes Model Compatibility List $19.99 / Each

5
Roller Wheel Set 1004126 GK61-00002-0026 Roller Wheel Set Yes Model Compatibility List $67.99 / Each

1
Sealed Lead Rechrgeable Battery 1004125 0017-00003-0685 Sealed Lead Rechrgeable Battery Yes Model Compatibility List $46.99 / Each
1
Power Extension Cable Wire Harness 1004127 AK32-00078-0001 Power Extension Cable Wire Harness Yes Model Compatibility List $29.99 / Each

1
Tectrix Self Powered Elliptical Battery 1000183 0819-0012 Tectrix Self Powered Elliptical Battery Yes Model Compatibility List $75.99 / Each

1
Alternator W/Resistor 1000587 0017-00009-0841 Alternator W/Resistor Yes Model Compatibility List $129.00 / Each
10
Right Link Cover W Decal 1000892 AK61-00214-0005 Right Link Cover W Decal Yes Model Compatibility List $69.00 / Each

1
Left Inside Link Arm Plastic Cover 1000899 06300-0005 Left Inside Link Arm Plastic Cover Yes Model Compatibility List $54.99 / Each
Out Of Stock 		1,9
Lead Rechargeable Battery 1001960 ‎0017-00003-0685 Lead Rechargeable Battery Yes Model Compatibility List $24.99 / Each

20
Alternator Pulley Resistor 1003149 0017-00009-0841 Alternator Pulley Resistor Yes Model Compatibility List $199.99 / Each

1
View Drawing

general Info

Customer Service

About us

Address

6114 Madison Ct.
Morton Grove, IL 60053
847-309-2818

Hydra Fitness Exchange © 2024. All Rights Reserved.

Payment options
